MV-5 MENU OVERVIEW
When the remote control touch screen is in the
"LEX" or "ZONE 2" menu layers, pressing
MENU or SELECT on the MV-5 remote control
accesses the menu controls for the MV-5
Processor. The MAIN MENU is the root
directory of the MV-5 menu structure and has three branches: AUDIO
CONTROLS, VIDEO STATUS, and SETUP.
Note: The DVD menu layer of the touch screen controls the Lexicon RT-20
and RT-10, if installed.
The AUDIO CONTROLS menu controls the audio-specific parameters,
such as treble and bass, as well as providing an audio status menu.
Refer to Section 4: Audio Controls & Video Status for more
information.
The VIDEO STATUS menu is an information-only menu identifying
the current video status of the MV-5 Processor. For more infor-
mation, refer to Section 4: Audio Controls & Video Status.
The SETUP menu controls all aspects of setting up the MV-5 Processor.
Refer to Section 3: Setup for more information.
The MV-5 menu structure can be viewed on the OSD (On-Screen
Display), which is a 480i or 480p video output signal to your monitor,
or on the front panel 2-line display, which displays the menus one line
at a time using the remote control navigation controls. The front panel
2-line display can also be viewed on the OSD, in 480i resolution only.
Note: When the MV-5 menu structure is entered, most front panel buttons
and the remote control buttons are disabled until the menu structure is
exited. The exceptions are the Volume Knob and Standby Button on the
front panel and the remote control Volume, Mute, and OFF buttons. Note
also that the disabled condition of the remote control only affects the
"LEX" and "ZONE 2" menu layers.
MENU NAVIGATION
Use the remote control arrow buttons to navigate the MV-5 menu
MAIN MENU
structure, shown in detail in Appendix B. The Command Matrix
AUDIO CONTROLS
Table located later in this chapter indicates the navigation
VIDEO STATUS
commands that the remote control buttons perform when the MV-
SETUP
5 command bank is activated by selecting the "LEX" or "ZONE 2"
options on the remote control touch screen.
Arrow
SELECT
MENU
EXIT
Navigation Functions
(for "LEX" and "ZONE2" menu layers)
When a menu is open, press the remote control
select the highlighted menu parameter. The menu parameter
will blink to indicate that it is selected.
When a menu is open, press the
menu and, in most cases, open the previous menu. Subsequent
presses continue to close the current menu and open the
previous menu until the MAIN MENU is closed.
When a menu is open, press the
and
upward and downward through the complete list of menu param-
eters. The highlighted menu item appears in the front panel
display. All menu items appear in the OSD. The cursor
automatically wraps to the next menu parameter when the first or
last menu item is passed.
When a menu parameter is selected and blinking, press the
arrow buttons to scroll through the available parameter
options.
Press the SELECT button to open the menu structure, open a
menu branch, or select a menu parameter.
Press the MENU button to open the menu structure.
When the menu is open, press the EXIT button to leave the menu.
Unlike the
arrow button which closes a menu layer, the EXIT
button completely closes the menu structure.
Basic Operation
arrow to
arrow to close the current
arrow buttons to scroll
and
2-9
