INPUT SETUP

Selecting the SETUP menu INPUT SETUP option opens the INPUT SETUP menu, a two-screen menu which sets up the input type and name, the
digital and analog inputs for both audio and video, the listening mode, and other advanced input settings.
MAIN MENU
SETUP
AUDIO CONTROLS DISPLAY SETUP
VIDEO STATUS
SPEAKER/EQ SETUP
SETUP

INPUT SETUP

SURROUND CONFIG
DOLBY CONFIG
MUTE LEVELS
POWER ON SETTINGS
INPUT
INPUT
SETUP INPUT SETUP
Selects between the twelve different inputs available. The input
selected in this parameter identifies the input that is currently being
setup or modified. Inputs can be scrolled through and modified
without leaving the input setup menu. However, most input setup
changes do not take affect until after the OSD menu is exited.
Note: Selecting a different input in the input setup menu will also change
the front panel input selection to match. For example, if the Tuner input is
selected on the front panel and you change the Input parameter to HD,
the front panel HD input is also selected.
Most of the inputs are interchangeable, with the exception of the
Dock and PC inputs. These two inputs are "hard-wired" and do not
allow for user selection of the Audio In parameters. For more infor-
mation on these two inputs, refer to Section 5: PC & Dock Controls.
INPUT SETUP 2
INPUT SETUP 1
MODE FAMILY: STEREO
INPUT: HD
NAME: ________
MODE: 2-CHANNEL
VIDEO IN: HDMI 1
DEFAULT SUR: USE LAST
V-PROCESS: FAROUDJA
A/D SAMPLE RATE: 48kHz
VIDEO OUT: AUTO
A/V SYNC DELAY: 0 ms
DIG AUDIO: HDMI 1
ADVANCED VIDEO
ANLG AUDIO: NONE
DIG/ANLG AUTO: ON TRIGGER 2: ON
ZONE-2 OUT: ANALOG
Note: When a source is active, changing some audio or video parameters
may cause the Main Zone audio to briefly mute the incoming source. If
Zone 2 is set to DOWN MIX, the Zone 2 audio will also briefly mute.
NAME
SETUP
Allows the user to customize the name of the selected input. Custom
input names can include up to eight characters.
Note: A custom name cannot be assigned to the Tuner input.
To Customize the Name of the Selected Input:
1. Select the input and enter the Input Setup menu.
2. Select the Name parameter. Note that a blinking square appears in
ADVANCED VIDEO 1
INPUT TYPE: VCR
SHARPNESS: 32
NOISE REDUCTION: ON
X-COLOR SUPPRESS: ON
DCDi INTERPOL: ON
FILM DETECTION: ON
FILM EDIT DETECT: ON
INPUT SETUP NAME
the first letter position.
Setup
ADVANCED VIDEO 2
FLESHTONE NR: ON
COMPNT ENHANCE: ON
BRIGHTNESS: 100
CONTRAST: 100
COLOR: 100
