Basic Operation
When the MV-5 is in Standby, pressing a Zone 2 input selection
button powers on the MV-5, selects the input in Zone 2, and turns
off the Main Zone.

7. ZONE 2 OFF BUTTON

Deactivates Zone 2. When Zone 2 is off, the Zone 2 OFF button on
the front panel lights red.

8. MAIN ZONE OFF BUTTON

Deactivates the Main Zone. When the Main Zone is off, the Main
Zone OFF button on the front panel lights red.
Note: Activating the Main Zone OFF button on the front panel turns off
the audio, however the video continues to be output through both the
analog and HDMI video outs. If using the HDMI Video In connection, only
the HDMI video is output. If the analog Video In is used, then both analog
and HDMI video is output. Main Zone OSD (On-Screen Display) menus
are also still available.

9. MUTE BUTTON

Mutes the Main Zone and Zone 2 volumes. Press the MUTE button to
mute the Main Zone volume level; "MUTE ON" appears in the 2-line
and OSD displays. Press the MUTE button again to restore the volume
to its original level. If a front panel Zone 2 input button is held down,
then pressing the MUTE button on the front panel will mute the Zone
2 output.
On the remote control, pressing the volume button once while the
volume is muted, turns off mute. Pressing and holding the Volume
button, while the sound is muted, resets to the original pre-mute
volume level and then increases or decreases the volume from that
point, turning off mute.
2-4
The LED in the MUTE button lights red when the Main Zone mute is
active, green when the Zone 2 mute is active, and amber when
both Zones are muted. The volume can also be muted by using the
MUTE button on the remote control, which functions in the same
manner. However, the remote only mutes Zone 2 if the touch
screen is in the "Zone 2" menu layer.

10. ON/STANDBY BUTTON

Toggles the MV-5 between On and Standby. The rear panel Power
Switch must be set to the ON position for the Standby button to be
active. When the MV-5 is in the standby mode, pressing the
Standby button turns the unit on and changes the light in the
Standby button from red to blue. Power is still supplied to the
MV-5 when standby mode is activated.
When the rear panel Power Switch is set to the ON position or AC
power is applied or restored, the MV-5 automatically enters the
standby mode.
Note: When taken out of standby, the MV-5 activates the Zone inputs
that were active in the previous operating session.
