IMPORTANT SAFETY INFORMATION
PLEASE READ AND FOLLOW THESE IMPORTANT
INSTRUCTIONS FOR THE SAFETY OF YOUR HOME AND
OF THE PEOPLE LIVING IN IT.
Save this Manual for local electrical inspector's use.
Read and save these instructions for future reference.
Observe all governing codes, ordinances and regulations.
WARNING!
If the information in this manual is not followed
exactly, a fire or explosion may result causing
property damage, personal injury or death.
‐ Do not store or use gasoline or other flammable
substances in the vicinity of this or any other appliance.
‐ WHAT TO DO IF YOU SMELL GAS
Do not light any appliance.
Do not touch any electrical switch.
Do not use any phone in your building.
Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
If you cannot reach your gas suppliers, call the fire
department.
‐ Installation and service must be performed by a
qualified installer, service agency or the gas supplier
In Massachusetts: All gas products must be installed by a
"Massachusetts" licensed plumber or gasfitter. A "T"
handle type manual gas valve must be installed in the gas
line connected to this appliance.
Warning
This range can tip. Injury to persons could result.
Install anti-tip device shipped with range. See
Installation Instructions.
!
Read this instruction booklet before installing and using
the appliance.
The manufacturer will not be responsible for any
damage to property or to persons caused by incorrect
installation or improper use of the appliance.
The manufacturer reserves the right to make changes to
its products when considered necessary and useful,
without affecting the essential safety and operating
characteristics.
This appliance has been designed for non‐professional,
domestic use only.
Do not use this appliance to heat a room.
Do not place any pot or pan on the open oven door. The
door is made of glass and it can break if loaded with a
weight.
Before beginning installation, please read these
instructions completely and carefully.
Do not remove permanently affixed labels, warnings, or
plates from the product. This may void the warranty. ‐
Please observe all local and national codes and
ordinances.
Please ensure the range is properly grounded.
The installer should leave these instructions with the
consumer who should retain for local inspector's use and
for future reference.
The plug should always be accessible.
Installation must conform with local codes or in the
absence of codes, the National Fuel Gas Code ANSI
Z223.1 / NFPA 54. Electrical installation must be in
accordance with the National Electrical Code,
ANSI/NFPA70 ‐ latest edition and/or local codes. IN
CANADA: Installation must be in accordance with the
current CAN/CGA‐B149.1 National Gas Installation Code
or CAN/CGA‐B 149.2, Propane Installation Code and/or
local codes. Electrical installation must be in accordance
with the current CSA C22.1 Canadian Electrical Codes
Part 1 and/or local codes.
Installation of any gas‐fired equipment should be made
by a licensed plumber. A manual gas shut‐off valve must
be installed in the gas supply line ahead of the oven in
the gas flow for safety and ease of service.
This appliance shall not be installed with a ventilation
system that blow air downward toward the
range/rangetop/cooktop; this type of ventilation system
may cause ignition and combustion problem with the gas
appliance resulting in a personal injury or unintended
operation
An
air
curtain
range/rangetop/cooktop hood, which operates by
blowing
a
downward
range/rangetop/cooktop, shall not be used/installed in
conjunction with this gas range/rangetop/cooktop,
1
WARNING!
WARNING
WARNING
or
other
airflow
onto
overhead
a
