1.12 Analog Inputs

Board Type:
Module Input:
Analog Input Type:
Analog Input Resolution:
Analog Input Precision:
Common Input GND:
Figure 13 RTU300 Analog Input Connection Diagram
18
GA1, GA4
4 Channel
0-20 mA, 4-20 mA
16 Bit
%1 Precision
1 GND (4 Point /
Common)
GA2
8 Channel
0-20 mA, 4-20 mA
16 Bit
%1 Precision
2 GND (8 Point /
Common)
RTU300 SERIES – HARDWARE MANUAL
GA6, GA7
4 Channel
0-20 mA, 4-20 mA
12 Bit
%1 Precision
1 GND (4 Point /
Common)
