1.8 Power Connection Diagram

1.8.1 Supply Connection
Board Type:
Supply:
Power:
14
Figure 9 RTU300 Power Connection Diagram
GA1, GA2, GA4, GA5, GA6, GA7
12-36 VDC, Protected
<13 W
RTU300 SERIES – HARDWARE MANUAL
