1.11 Relay Outputs

Board Type:
Module Output:
Relay Contact Outputs:
Contact Max. Current:
Isolation
17
Figure 12 RTU300 Relay Connection Diagram
GA1, GA4, GA5
4 Channel
NO(Normally Open) Contact
3A@30VDC – 5A@250VAC
Dry Contact
RTU300 SERIES – HARDWARE MANUAL
