MIKRODEV RTU Series Hardware Manual

Hide thumbs Also See for RTU Series:

Advertisement

Quick Links

RTU100
HARDWARE MANUAL
• RTU100
RTU Series
03 / 2023
MIKRODEV_HM_RTU100_EN
v1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RTU Series and is the answer not in the manual?

Questions and answers

Summary of Contents for MIKRODEV RTU Series

  • Page 1 RTU100 HARDWARE MANUAL • RTU100 RTU Series 03 / 2023 MIKRODEV_HM_RTU100_EN v1.0...
  • Page 2: Table Of Contents

    CONTENTS FIGURES LIST ....................... 2 Preface ......................... 3 About Mikrodev ..................... 4 WARNING! ......................5 RTU100 GENERAL INFORMATION ..............6 GB0 Board Type Physical Interfaces ............. 6 General Device Specifications ..............7 INSTALLATION INFORMATION ................8 Rail Installation ..................8 Expansion Installation ................
  • Page 3: Figures List

    FIGURES LIST Figure 1 GB0 Board Type Connector and Physical Interface ......... 6 Figure 2 Mounting ....................8 Figure 3 Expansion Installation ................9 Figure 4 Power Connection Diagram ................10 Figure 5 Digital Input Connection Diagram ...............11 Figure 6 Digital Output Connection Diagram .............12 Figure 7 Analog Input Connection Diagram ..............13 Figure 8 RS485 Serial Port Connection Diagram ............14 RTU100 SERIES –...
  • Page 4: Preface

    SCADA or control center software via IEC 60870, DNP3 and MODBUS TCP protocols. With its easy, flexible and fast programming capabilities and expandable I/O capability up to 1024 points, Mikrodev RTU products are preferred for electrical applications. Mikrodev RTU100 Series RTUs are programmed mainly using Function Block Diagram - FBD language which is defined in IEC 61131-3 standard.
  • Page 5: About Mikrodev

    MIKRODEV is one of the few companies in the world that has its own designed IEC 61131- 3 compliant library for its programmable logic control devices. In addition, the open, flexible, programmable SCADA solution developed by MIKRODEV is also available to customers.
  • Page 6: Warning

    ✓ Make sure that the environment in which your device is being used is free of moisture, electric shock, vibration and dust. ✓ Pay attention to the supply voltage and the connections of the product. Mikrodev is not responsible for any issues due to power failure since there is no auxiliary supply (UPS) on the device.
  • Page 7: Rtu100 General Information

    RTU100 GENERAL INFORMATION 1.1 GB0 Board Type Physical Interfaces Figure 1 GB0 Board Type Connector and Physical Interface Ethernet Port Antenna Connection USB Port Digital Input Connections System Power /Running LED SIM Card Slot Digital Input Status Information Analog Input Connections Digital Output Status Information Digital Output Connections Protocol Data Transfer LED...
  • Page 8: General Device Specifications

    1.2 General Device Specifications SPECIFICATION ITEM DESCRIPTION Processor Architecture ARM Cortex M4 Processor Adressing Architecture Little Endian Addressing Supply 24 VDC (12-36VDC) Electrical Power <10W @ 24V DC Real Time Clock Integrated Board Type Digital Input 4 Channel, PNP Input / Output 4 Channel, 0.5A@24VDC per Channel, Digital Output* Analog Input...
  • Page 9: Installation Information

    INSTALLATION INFORMATION 2.1 Rail Installation DIN Rail Mountage First, the upper part of the device is mounted on the DIN rail. Then, with the help of the springs behind the device, when a lightly force is applied to the lower part, the device locates into the DIN rail easily and the montage is completed.
  • Page 10: Expansion Installation

    2.2 Expansion Installation The RTU100 product and its extensions are mounted by sliding over the rail in such a way that the connectors correponds. Figure 3 Expansion Installation RTU100 SERIES – HARDWARE MANUAL...
  • Page 11: Connection Diagrams

    CONNECTION DIAGRAMS 3.1 Supply Connection Board Type: Supply: 12-36 VDC, Protected Power: < 13 W Figure 4 Power Connection Diagram RTU100 SERIES – HARDWARE MANUAL...
  • Page 12: Digital Inputs

    3.2 Digital Inputs Board Type: Module Input: 4 Channel, PNP Voltage Range: 0-36 VDC ON Voltage Level: 12-36 VDC OFF Voltage Level: 0-10 VDC Input Impedance: >2M Isolation: Optical OFF to ON Response: 20 us ON to OFF Response: 90 us Fast Counter Inputs: DI0, DI1, DI2, DI3 Fast Counter Inputs Max.
  • Page 13: Digital Outputs

    3.3 Digital Outputs Board Type: Module Output: 4 Channel, Mosfet Output Voltage Range: 12-36V DC Max. Output Current: 0.5A@24VDC per Channel Isolation: Optical Pulse Width Modulation Output and Pulse DO0, DO1, DO2, DO3 Train Output: Pulse Train Output Max. Frequency(PTO): 50 kHz Pulse Width Modulation Output Max.
  • Page 14: Analog Inputs

    3.4 Analog Inputs Board Type: Module Input: 2 Channel Analog Input Type 0-20 mA, 4-20 mA Analog Input Resolution: 12 Bit Analog Input Precision: %1 Precision Common Input GND: 1 GND (4 Point / Common) Figure 7 Analog Input Connection Diagram RTU100 SERIES –...
  • Page 15: Rs485 Serial Port

    3.5 RS485 SERIAL PORT Board Type: RS485 Port Count: 1 Port Maximum Slave Counts: Limited to Hardware Isolation: ESD Protection, 8 KV Direct, 25 kV Air Discharge Communication Distance: 1000 m Data Bits: Stop Bits: Parity: None-Even-Odd Baudrate: 300 bps to 200 kbps Figure 8 RS485 Serial Port Connection Diagram RTU100 SERIES –...
