MIKRODEV RTU Series Hardware Manual

Hide thumbs Also See for RTU Series:

Advertisement

Quick Links

RTU300
HARDWARE MANUAL
• RTU301
• RTU310
• RTU320
• RTU330
• RTU340
RTU Series
MIKRODEV_HM_RTU300_EN
04 / 2022
v1.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RTU Series and is the answer not in the manual?

Questions and answers

Summary of Contents for MIKRODEV RTU Series

  • Page 1 RTU300 HARDWARE MANUAL • RTU301 • RTU310 • RTU320 • RTU330 • RTU340 RTU Series 04 / 2022 MIKRODEV_HM_RTU300_EN v1.2...
  • Page 2: Table Of Contents

    CONTENTS FIGURES LIST ..........................2 Preface ............................3 About Mikrodev ..........................4 WARNING! ............................5 Mounting Information ........................6 RTU300 GENERAL INFORMATION ..............7 GA1 Board Type Physical Interface .............. 7 GA2 Board Type Physical Interface .............. 8 GA4 Board Type Physical Interface .............. 9 GA5 Board Type Physical Interface .............10...
  • Page 3: Figures List

    FIGURES LIST Figure 1 DIN Rail Mounting ..................6 Figure 2 Expansion Module Mounting ............... 6 Figure 3 GA1 Board Type Connector and Physical Interface ......... 7 Figure 4 GA2 Board Type Connector and Physical Interface ......... 8 Figure 5 GA4 Board Type Connector and Physical Interface ........10 Figure 6 GA5 Board Type Connector and Physical Interface ........11 Figure 7 GA6 Board Type Connector and Physical Interface ........12 Figure 8 GA7 Board Type Connector and Physical Interface ........12...
  • Page 4: Preface

    SCADA or control center software via IEC 60870, DNP3 and MODBUS TCP protocols. With its easy, flexible and fast programming capabilities and expandable I/O capability up to 1024 points, Mikrodev RTU products are preferred for electrical applications. Mikrodev RTU300 Series RTUs are programmed mainly using Function Block Diagram - FBD language which is defined in IEC 61131-3 standard.
  • Page 5: About Mikrodev

    MIKRODEV is one of the few companies in the world that has its own designed IEC 61131- 3 compliant library for its programmable logic control devices.
  • Page 6: Warning

    ✓ Make sure that the environment in which your device is being used is free of moisture, electric shock, vibration and dust. ✓ Pay attention to the supply voltage and the connections of the product. Mikrodev is not responsible for any issues due to power failure since there is no auxiliary supply (UPS) on the device.
  • Page 7: Mounting Information

    Mounting Information DIN Rail Mounting First, the upper part of the device is mounted on the DIN rail. Then, with the help of the springs behind the device, when a lightly force is applied to the lower part, the device locates into the DIN rail easily and the montage is completed (See Figure 1).
  • Page 8: Rtu300 General Information

    RTU300 GENERAL INFORMATION 1.1 GA1 Board Type Physical Interface Figure 3 GA1 Board Type Connector and Physical Interface Digital Input GND Connection Device Power (V+) Connection Analog Output Connections Device Power (V-) Connection Analog GND Connection Ethernet Port Analog Input Connection USB Port RS485 Connections Relay Status Information LED...
  • Page 9: Ga2 Board Type Physical Interface

    1.2 GA2 Board Type Physical Interface Figure 4 GA2 Connector and Physical Interface Digital Input GND Connection Device Power (V+) Connection Analog Input Connection Device Power (V-) Connection Analog Input GND Connection Ethernet Port RS485 GND Connections USB Port RS485 Port 1 Connections Digital Output Status Information LED RS485 Port 2 Connections Digital Input Status Information LED...
  • Page 10: Ga4 Board Type Physical Interface

    1.3 GA4 Board Type Physical Interface Figure 5 GA4 Board Type Connector and Physical Interface Digital Input GND Connection Device Power (V+) Connection Analog Output Connections Device Power (V-) Connection Analog GND Connection Ethernet Port Analog Input Connection USB Port RS485 Connections Relay Status Information LED Digital Output Status Information LED...
  • Page 11: Ga5 Board Type Physical Interface

    1.4 GA5 Board Type Physical Interface Figure 6 GA5 Board Type Connector and Physical Interface Digital Input GND Connection Device Power (V+) Connection Device Power (V-) Connection Ethernet Port USB Port RS485 Connections Relay Status Information LED RS232 GND Connections Digital Output Status Information LED RS232 TX-RX Connections Digital Input Status Information LED...
  • Page 12: Ga6 Board Type Physical Interface

    1.5 GA6 Board Type Physical Interface Figure 7 GA6 Board Type Connector and Physical Interface Digital Input GND Connection Device Power (V+) Connection Device Power (V-) Connection Analog GND Connection Ethernet Port Analog Input Connection USB Port RS485 Connections RS232 GND Connections Digital Output Status Information LED RS232 TX-RX Connections Digital Input Status Information LED...
  • Page 13: Ga7 Board Type Physical Interface

    1.6 GA7 Board Type Physical Interface Figure 8 GA7 Board Type Connector and Physical Interface Digital Input GND Connection Device Power (V+) Connection Device Power (V-) Connection Analog GND Connection Ethernet Port Analog Input Connection USB Port RS485 Connections Digital Output Status Information LED RS485(2) Connections Digital Input Status Information LED System Power LED...
  • Page 14: General Device Specifications

    1.7 General Device Specifications SPECIFICATION ITEM DESCRIPTION Processor ARM Cortex M4 Architecture Processor Internal 196 KB Processor CPU Speed 168 MHz Adressing Little Endian Addressing Architecture Supply 24 VDC (12-36VDC) Electrical Power <13W @ 24V DC Real Time Clock Integrated Board Type GA1, GA4 GA6, GA7...
  • Page 15: Power Connection Diagram

    1.8 Power Connection Diagram 1.8.1 Supply Connection Board Type: GA1, GA2, GA4, GA5, GA6, GA7 Supply: 12-36 VDC, Protected Power: <13 W Figure 9 RTU300 Power Connection Diagram RTU300 SERIES – HARDWARE MANUAL...
  • Page 16: Digital Inputs

    1.9 Digital Inputs Board Type: GA1, GA2, GA4, GA5, GA6, GA7 Module Input: 16 Channel, PNP Voltage Range: 0-36V DC ON Voltage Level: 12-36V DC OFF Voltage Level: 0-10V DC Input Impedance: >2M Isolation: Optical OFF to ON Response: 20 us ON to OFF Response: 90 us Figure 10 RTU300 Digital Input Connection Diagram...
  • Page 17: Digital Outputs

    1.10 Digital Outputs Board Type: GA1, GA2, GA4, GA5, GA6, GA7 Module Output: 8 Channel, Mosfet Output Module Output Type: PNP Transistor Voltage Range: 12-36V DC Max. Output Current: 2A @ 30V DC Isolation: Optical Figure 11 RTU300 Digital Output Connection Diagram RTU300 SERIES –...
  • Page 18: Relay Outputs

    1.11 Relay Outputs Board Type: GA1, GA4, GA5 Module Output: 4 Channel Relay Contact Outputs: NO(Normally Open) Contact Contact Max. Current: 3A@30VDC – 5A@250VAC Isolation Dry Contact Figure 12 RTU300 Relay Connection Diagram RTU300 SERIES – HARDWARE MANUAL...
  • Page 19: Analog Inputs

    1.12 Analog Inputs Board Type: GA1, GA4 GA6, GA7 Module Input: 4 Channel 8 Channel 4 Channel Analog Input Type: 0-20 mA, 4-20 mA 0-20 mA, 4-20 mA 0-20 mA, 4-20 mA Analog Input Resolution: 16 Bit 16 Bit 12 Bit Analog Input Precision: %1 Precision %1 Precision...
  • Page 20: Analog Outputs

    1.13 Analog Outputs Board Type: GA1, GA4 Module Output: 2 Channel Analog Output Type: 0-20 mA, 4-20 mA Analog Output Resolution: 12 Bit Current Output Precision: %1 Precision Common Output GND: 1 GND (2 Point / Common) Figure 14 RTU300 Analog Output Connection Diagram RTU300 SERIES –...
  • Page 21: Serial Ports

    1.14 Serial Ports 1.14.1 RS485 Serial Port Board Type: GA1, GA5, GA6 GA4,GA7 RS485 Port Count: 1 Port 2 Port RS485 or 1 Port 2 Port RS485 and 1 Port RS422 Maximum Slave Count Limited to Hardware Isolation: ESD Protection, 8 kV Direct, 25 kV Air Discharge Communication Distance: 1000 m Data Bits:...
  • Page 22 1.14.2 RS232 Serial Port Board Type: GA1, GA5, GA6 RS232 Port Count: 1 Port 1 Port (with flow control) Communication Distance: 10 m Data Bits: Stop Bits: Parity: None-Even-Odd Baudrate: 300 bps to 200 kbps Figure 16 RTU300 RS232 Serial Port Connection Diagra RTU300 SERIES –...
