Summary of Contents for Vents Micra 110

  • Page 1 USER'S MANUAL Micra 110 Micra 110 V1 Micra 110 ERV Micra 110 V1 ERV Air handling unit...
  • Page 2: Table Of Contents

    Warranty card ....................................19 This user’s manual is a main operating document intended for technical, maintenance, and operating staff. The manual contains information about purpose, technical details, operating principle, design, and installation of the Micra 110 (V1) (ERV) unit and all its modifications.
  • Page 3 Do not use the unit in a hazardous or explosive environment containing spirits, gasoline, insecticides, etc. Do not close or block the intake or extract vents in order to ensure the efficient air flow. Do not sit on the unit and do not put objects on it.
  • Page 4: Purpose

    Micra 110 (V1) (ERV) PURPOSE The unit is designed to ensure continuous mechanical air exchange in residential premises, offices, hotels, cafés, conference halls, and other public spaces as well as to recover the heat energy contained in the air extracted from the premises to warm up the filtered stream of supply air.
  • Page 5: Technical Data

    The unit design is constantly being improved, thus some models may be slightly different from those described in this manual. PARAMETER MICRA 110 MICRA 110 V1 MICRA 110 ERV MICRA 110 V1 ERV Speed Maximum air flow [m Supply voltage, 50 (60) Hz [V] 1~ 230...
  • Page 6 Micra 110 (V1) (ERV) MICRA 110 (ERV) ØD MICRA 110 V1 (ERV) ØD Dimensions [mm] Model Ø D Micra 110 (ERV) Micra 110 V1 (ERV) — — www.ventilation-system.com...
  • Page 7 Mounting plate for MICRA 110 V1 (ERV) Dimensions [mm] www.ventilation-system.com...
  • Page 8 The frost protection mode of the heat exchanger is deactivated at an air temperature above +7 ˚С. Frost protection is only possible in heat recovery mode. The Micra 110 (ERV) units provide for the installation of an exhaust spigot (Ø 100 mm) for servicing another room. The spigot is included in the delivery set.
  • Page 9: Mounting And Set-Up

    READ THE RELEVANT USER MANUALS WHILE INSTALLING THE UNIT ENSURE CONVENIENT ACCESS FOR SUBSEQUENT MAINTENANCE AND REPAIR. Micra 110 (ERV) The delivery set includes a mounting template for marking the holes. Fix the mounting template at the required level on the wall.
  • Page 10 If an optional exhaust spigot is installed, install a magnetic plug on the exhaust grille. For Micra 110 units it is recommended to use a condensate drain pipe heater (not included in the delivery set). The heater must be installed before fixing the unit to the wall (see the heater installation manual).
  • Page 11 MICRA 110 V1 (ERV) The Micra 110 V1 (ERV) units are designed for built-in wall mounting. Before installation, it is necessary to fix the mounting plate in the niche. If FlexiVent air ducts are to be used, prepare the necessary cavities for the air ducts in the solid wall beforehand.
  • Page 12 Cut off the protruding air duct parts to be flush with the wall surface. For Micra 110 V1 units it is recommended to use a condensate drain pipe heater (not included in the delivery set). The heater must be installed before fixing the unit to the mounting plate (see the heater installation manual).
  • Page 13 Install the protective and the decorative panels. WARNING! When installing the decorative panel, make sure it hooks into the brackets to prevent it from falling off. Mount an outer ventilation hood (not included in the delivery set). www.ventilation-system.com...
  • Page 14: Connection To Power Mains

    Micra 110 (V1) (ERV) CONNECTION TO POWER MAINS POWER OFF THE POWER SUPPLY PRIOR TO ANY OPERATIONS WITH THE UNIT. THE UNIT MUST BE CONNECTED TO POWER SUPPLY BY A QUALIFIED ELECTRICIAN. THE RATED ELECTRICAL PARAMETERS OF THE UNIT ARE GIVEN ON THE MANUFACTURER’S LABEL.
  • Page 15: Control

    CONTROL Ventilation units are controlled via a sensor control panel on the unit casing. 1 – Switching the unit on/off. If the unit is on, the indicator 4 lights up. 2 - button for switching speeds. The indicators 5-7 indicate the current operating speed. 3 - button for switching operating modes.
  • Page 16: Technical Maintenance

    Micra 110 (V1) (ERV) TECHNICAL MAINTENANCE Maintenance operations of the unit are required 3-4 times per year. Maintenance includes periodic dust removal from surfaces, cleaning or replacement of filters (when necessary) and dry cleaning of fans. Maintenance includes general cleaning of the unit and the following operations: 1.
  • Page 17: Troubleshooting

    TROUBLESHOOTING PROBLEM POSSIBLE REASONS TROUBLESHOOTING The fan(s) do(es) not get Make sure that the unit is properly connected to the power No power supply. started. mains and make any corrections, if necessary. Extract filter clogging. Clean or replace the extract filter. Check the heat exchanger for icing.
  • Page 18: Manufacturer's Warranty

    Micra 110 (V1) (ERV) MANUFACTURER’S WARRANTY The product is in compliance with EU norms and standards on low voltage guidelines and electromagnetic compatibility. We hereby declare that the product complies with the provisions of Electromagnetic Compatibility (EMC) Directive 2014/30/EU of the European Parliament and of the Council, Low Voltage Directive (LVD) 2014/35/EU of the European Parliament and of the Council and CE-marking Council Directive 93/68/EEC.
  • Page 19: Certificate Of Acceptance

    CERTIFICATE OF ACCEPTANCE Unit Type Air handling unit Model Serial Number Manufacture Date Quality Inspector’s Stamp SELLER INFORMATION Seller Address Phone Number E-mail Purchase Date This is to certify acceptance of the complete unit delivery with the user’s manual. The warranty terms are acknowledged and accepted.
  • Page 20 V250EN-01...
