prisma VENT AQUA – Quick Start Guide
1
5
1: Display of humidification stages
2: Current humidification value
3: Display of the alarms and the
operating mode
Configuration help
Attention! This quick start guide does not replace the instructions for use! The
medical or hospital specifications will take precedence over these recommendations!
All warnings and guidelines in the operating instructions must be strictly observed.
Too much condensate = Reduce the humidification
Operation modes
RAL 9006 white aluminum metallic
Display
RAL 9006 white alluminum metallic
filled circle means LED is lit
filled circle with rays means LED is flashing
2
4: Muting the alarm, switching on the
5: Setting the humidification levels as
Term
Operation mode
without inspiratory heating wire and
NHW
without temperature probe
with inspiratory heating wire,
HWC
but without temperature probe
with inspiratory heating wire and
HWT
with temperature probe
prisma VENT AQUA
treatment interruption under normal
operation mode
three levels
M 1:1 | all measures in mm
02.08.2017 | AWO
3
4
