Anden A210V1 Quick Start Manual

Model A210V1 & A320V1/V3 Dehumidifier
Quick Start Guide
The Quick Start Guide is to be used as reference only. Installation is to be in accordance with Installation and Operating Instructions provided with the dehumidifier.
1. PLACEMENT
18"
MIN
OUTLET
AVOID
OUTLET INLET
HVAC RETURN
OUTLET
INLET
AIRFLOW
DIRECTION
2A. HANGING – A210V1
INSERT BRACKET INTO
OPENINGS ON BOTTOM
OF UNIT – 4 PLACES
18"
MIN
OUTLET
90-2474
OUTLET INLET
HVAC SUPPLY
90-2475
90-2476
90-2397
ROTATE BRACKET INTO
PLACE AND SECURE WITH
SCREWS PROVIDED
90-2398
2B. HANGING – A320V1/V3
INSERT BRACKET INTO
OPENINGS ON BOTTOM
OF UNIT – 4 PLACES
90-2435
ROTATE BRACKET
INTO PLACE AND SECURE
WITH SCREWS PROVIDED
90-2436
3. NUT & WASHER
4. LEVEL
NUT AND WASHER SIZES BASED ON
ROD SIZE (1/4", 3/8", 1/2")
NUT
WASHER
HANGING
BRACKET
WASHER
NUT
90-2477
90-2478
