INSTALLATION IS TO BE IN ACCORDANCE WITH INSTALLATION AND OPERATING INSTRUCTIONS PROVIDED WITH THE DEHUMIDIFIER.
1. PLACEMENT
18"
MIN
OUTLET
2. HANGING
MODEL A210V1
INSERT BRACKET INTO
OPENINGS ON BOTTOM OF UNIT (4 PLACES)
ROTATE BRACKET INTO
PLACE AND SECURE
WITH SCREWS
Model A210V1 & A320V1/V3 Dehumidifier
Quick Start Guide
THE QUICK START GUIDE IS TO BE USED AS REFERENCE ONLY.
18"
MIN
OUTLET
90-2474
MODEL A320V1/V3
90-2397
90-2398
OUTLET
HVAC RETURN
OUTLET
INLET
AIRFLOW
DIRECTION
INSERT BRACKET
INTO OPENINGS ON BOTTOM
OF UNIT (4 PLACES)
ROTATE BRACKET
INTO PLACE AND SECURE
WITH SCREWS PROVIDED
AVOID
INLET
INLET
OUTLET
HVAC SUPPLY
90-2475
90-2476
90-2435
90-2436
1
Advertisement
Table of Contents
Related Manuals for Anden A210V1
Summary of Contents for Anden A210V1
- Page 1 Model A210V1 & A320V1/V3 Dehumidifier Quick Start Guide THE QUICK START GUIDE IS TO BE USED AS REFERENCE ONLY. INSTALLATION IS TO BE IN ACCORDANCE WITH INSTALLATION AND OPERATING INSTRUCTIONS PROVIDED WITH THE DEHUMIDIFIER. 1. PLACEMENT AVOID INLET INLET OUTLET...
- Page 2 ROD SIZE (1/4", 3/8", 1/2") WASHER HANGING BRACKET WASHER 90-2477 90-2478 5. DRAIN CONNECTIONS MODEL A210V1 CONSTANT DOWNWARD FLEXIBLE TUBE SLOPE 1/8" PER FOOT (MIN.) 3/4" MNPT X 3/4" SLIP FIT PVC RIGID PIPE 90-2479 MODEL A320V1/V3 – DO NOT DOUBLE TRAP PRIME TRAP 3/4"...
- Page 3 6A. WIRING AND SET-UP – MODEL A77 CONTROL The Model A77 will measure the relative humidity and turn the dehumidifier on and off to control the humidity level to the desired setting. The humidity setting can be adjusted from the control, while the display allows easy access and monitoring of the humidity level in the space. It is recommended that the Model A77 be mounted at/near canopy height.
- Page 4 Insufficient Capacity High Temperature Thermistor Failure Low Temperature Thermistor Failure Float Switch Open Inlet Air Temperature Out of Range B2208490B • 10013947 • 1.22 © 2022 Anden | anden.com | 800.972.3710 Anden reserves the right to change specifications without notice.
