Summary of Contents for NTI XTENDEX ST-FO4K18GB-RSLA-LCV2
- Page 1 ® XTENDEX Series ST-FO4K18GB-RSLA-LCV2 4K 18Gbps HDMI Extender with Stereo Audio And Local HDMI Loop-Through via One LC Singlemode or Multimode Fiber Optic Cable Installation and Operation Manual Front View (Remote Unit) and Rear View (Local Unit) MAN423 Rev Date 8/10/2022...
- Page 2 TRADEMARK XTENDEX and the NTI logo are registered trademarks of Network Technologies Inc in the U.S. and other countries. All other brand names and trademarks or registered trademarks are the property of their respective owners. COPYRIGHT Copyright © 2022 by Network Technologies Inc. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written consent of Network Technologies Inc, 1275 Danner Drive, Aurora, Ohio 44202.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction..................................1 Materials ..................................2 Features and Functions..............................3 Connections..................................5 Technical Specifications..............................6 Warranty Information............................... 7... -
Page 4: Introduction
NTI XTENDEX 4K 18GBps Extender via Fiber Optic Cable INTRODUCTION The XTENDEX® 4K 18Gbps HDMI Extender via Fiber Optic Cable locates an Ultra-HD 4Kx2K 60Hz 4:4:4 HDMI display, IR, stereo audio, and RS232 up to 6.21 miles (10 km) away from a 4K HDMI source using a single LC singlemode fiber optic strand and 984 feet (300 meters) using OM3 multimode fiber optic cable. -
Page 5: Materials
NTI XTENDEX 4K 18GBps Extender via Fiber Optic Cable MATERIALS Materials supplied with this kit One transmitter unit with fiber transmitter module installed One receiver unit with fiber receiver module installed Two IR emitters Two IR receivers ... -
Page 6: Features And Functions
NTI XTENDEX 4K 18GBps Extender via Fiber Optic Cable FEATURES AND FUNCTIONS LABEL CONNECTOR/LED DESCRIPTION POWER Red LED Illuminates to indicate proper power to the unit FIBER Green LED Illuminates solid to indicate the Local and Remote units have a normal signal... - Page 7 NTI XTENDEX 4K 18GBps Extender via Fiber Optic Cable LABEL CONNECTOR/LED DESCRIPTION Red LED Illuminates to indicate proper power to the unit POWER Green LED Illuminates to indicate the Local and Remote units have a proper signal FIBER connection HDMI...
-
Page 8: Connections
NTI XTENDEX 4K 18GBps Extender via Fiber Optic Cable CONNECTIONS See below connections made in a typical application. -
Page 9: Technical Specifications
NTI XTENDEX 4K 18GBps Extender via Fiber Optic Cable TECHNICAL SPECIFICATIONS Local Unit Connections One female HDMI connector for source. One female HDMI connector for local display. Two female 3.5mm ports for connecting an IR emitter and receiver (included). -IR frequency: 20KHz to 60KHz One female 3.5mm port for stereo audio input. -
Page 10: Warranty Information
NTI XTENDEX 4K 18GBps Extender via Fiber Optic Cable IR Receiver and Blaster Pinout WARRANTY INFORMATION The warranty period on this product (parts and labor) is two (2) years from the date of purchase. Please contact Network Technologies Inc at (800) 742-8324 (800-RGB-TECH) or (330) 562-7070 or visit our website at http://www.networktechinc.com...
