AC301
Thermostatic Radiator Valve
Thermostatic Radiator Valves (TRVs) sense the air temperature around them and regulate the flow of
water through the radiator which they are fitted to.
They can be set at a level that gives you the room temperature you want. These settings may have to be
different in each room, and you can set the TRVs to suit each room and then leave them to do their job.
The device can be set temperature by manual or by gateway and schedule are created by gateway.
This product can be operated in any Z-Wave network with other Z-Wave certified devices from other
manufacturers. All mains operated nodes within the network will act as repeaters regardless of vendor to
increase reliability of the network.
Product Overview
LCD
display
LCD Display
Time
ROOM: Current
temperature
SET: Target
temperature
HEAT Mode
Heating active
Battery
cover
Valve
cap
Week
Temperature display
Key lock
ENERGY HEAT Mode
4
1
2
Button name
Function
1.
P button
For RF inclusion
2.
Power on/off
Turn on/off TRV
3.
M button
Mode select : HEAT/ ENERGY HEAT
4.
Down button
Reduce Target Temperature
5.
Up button
Increase Target Temperature
Installation
Mounting
Do not insert the batteries yet.
1.
Remove any existing control from the radiator valve
2.
Mount the TRV on the valve and tighten it by turning the Valve cap clockwise.
3.
You may need to use one of the adaptors supplied to fit your radiator valve:
5
3
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for EVERSPRING AC301
Summary of Contents for EVERSPRING AC301
- Page 1 AC301 Thermostatic Radiator Valve Thermostatic Radiator Valves (TRVs) sense the air temperature around them and regulate the flow of water through the radiator which they are fitted to. They can be set at a level that gives you the room temperature you want. These settings may have to be different in each room, and you can set the TRVs to suit each room and then leave them to do their job.
- Page 2 “HEAT” mode: This is a higher temperature level for indoor comfort and normally used when a room is occupied. “ENERGY HEAT” mode: This is the lower temperature level for energy saving, typically used The TRV can be mounted at various orientation as shown below: during sleeping or when a room is empty.
- Page 3 COMMAND_CLASS_BATTERY COMMAND_CLASS_NOTIFICATION_V8 COMMAND_CLASS_CONFIGURATION Z-Wave Plus Info COMMAND_CLASS_SENSOR_MULTILEVEL Role Type Node Type Installer Icon User Icon COMMAND_CLASS_APPLICATION_STATUS COMMAND_CLASS_THERMOSTAT_MODE_V3 Slave Sleeping Z-Wave Plus node Generic_Thermostat Generic_Thermostat COMMAND_CLASS_THERMOSTAT_SETPOINT_V3 Listening COMMAND_CLASS_PROTECTION COMMAND_CLASS_CLOCK Association Command Class Group Max Node Basic Command Class...
- Page 4 (This procedure should only be used 2. Within 1 second of step 1, press the button P again and hold for 5 seconds. www.everspring.com when the controller is inoperable.) 50 Sect. 1 Zhonghua Rd Tucheng New Taipei City 236 Taiwan..
