EVERSPRING AD126 Manual

AD126 LAMP MODULE
This plug-in Lamp Module is a transceiver which is a Z-Wave
and is fully compatible with any Z-Wave
TM
devices displaying the Z-Wave logo can also be used with it regardless of the
manufacturer, and ours can also be used in other manufacturer's Z-Wave
enabled networks. Inclusion of the Lamp module on other manufacturer's
Wireless Controller menu allows remote On/Off control and dimming of lamps
connected. Each module is designed to act as a repeater.
re-transmit the RF signal to ensure that the signal is received by its intended
destination by routing the signal around obstacles and radio dead spots.
TM
Adding to Z-Wave Network
In the front casing, there is an On/Off/Dim knob which is used to carry out inclusion,
exclusion or association. Put
inclusion/exclusion mode, press the knob on the Module to complete the
inclusion/exclusion process.
Installation
1. Plug this Lamp module into a wall outlet near the lamp to be controlled.
2. Plug the lamp into the Lamp Module. There are two outlets at different sides of
AD126. The lamp plugged into the controllable outlet can be controlled by the
On/Off/Dim knob and remote controller, its maximum load is 300 watts. The
other side acts as a pass-through outlet which is non-controlled by the
On/Off/Dim knob and remote controller.
3. Make sure the total load of both outlets cannot exceed 1500 watts which
means if the load of controllable outlet is changed; the other pass-through will
be altered accordingly. For instance, if the load of controllable outlet is about
TM
enabled device
TM TM
enabled network. Z-Wave
Repeaters will
TM
a Z-Wave Wireless Controller
Controllable outlet
Pass-through outlet
On /Off / Dim knob
300 watts, the other should be 1200 watts. When the load of controllable outlet
consumes as 0 watts, the other will be 1500 watts.
4. Turn the knob or switch on the lamp to the ON position.
enabled
5. To manually turn ON the AD126 Lamp Module, press and release the
On/Off/Dim knob. The red indicator LED will turn ON, and the lamp plugged
TM
into the AD126 Lamp Module will also turn ON.
6. To manually turn OFF the AD126 Lamp Module, simply press and release the
On/Off/Dim knob. The red indicator LED will turn OFF and the lamp plugged
into the AD126 Lamp Module will also turn OFF.
7. To manually dim the AD126 Lamp Module, press and hold the On/Off/Dim
knob until the desired lighting level has been reached.
Note: Dimming an inductive load, such as a motor or a transformer, could
into
impair the dimmer and load attached as well.
Programming
The On/Off/Dim knob allows the user
- Turn on, off or dim the lamp attached
- Include or exclude the module from the Z-Wave
- Control other Z-Wave
Advanced Operation
As long as any Z-Wave
command
(ALARM_REPORT, Alarm Type == 0x01, Alarm Level == 0x11)
to the AD126 Lamp Module will enable its red indicator LED and the load plugged
into the AD126 Lamp Module to be on and off intermittently for 10 seconds
simultaneously.
Troubleshooting
Symptom
The Module not working and
LED off
1
TM
system
TM
enabled devices
TM
enabled device that can send below mentioned alarm
Cause of Failure Recommendation
1. The Module is not 1. Check power connections
plugged into the 2. Don't open up the Module and
