Sino Wealth SH69P55A Manual

Otp/mask 8k 4-bit micro-controller with lcd driver & 10-bit sar adc

Advertisement

Quick Links

Features
SH6610D-Based Single-Chip 4-bit Micro-Controller With
LCD Driver & 10-bit SAR ADC
OTP ROM: 8K X 16 bits (SH69P55A)
MASK ROM: 8K X 16 bits (SH69K55A)
RAM: 515X 4 bits
- 99 System Control Register
- 376 Data Memory
- 40 LCD RAM
Operation Voltage: 2.4V - 5.5V
- f
= 30k- 4MHz, V
OSC
- f
= 30k - 8MHz, V
OSC
42 CMOS Bi-directional I/O Pins (Including one
open-drain output PortC.3)
Built-in Pull-high Resistor For PORTA - PORTK
8-Level Stack (Including Interrupts)
Two 8-bit and One 16-bit Auto Re-loaded Timer/Counter
LCD Driver:
- 16 SEG X 8 COM (1/8 Duty, 1/4 Bias)
- 18 SEG X 6 COM (1/6 Duty, 1/3 Bias)
- 20 SEG X 4 COM (1/4 Duty, 1/3 Bias)
LED Driver:
- 8 SEG X 6 COM (1/6 Duty)
- 8 SEG X 5 COM (1/5 Duty)
- 8 SEG X 4 COM (1/4 Duty)
Powerful Interrupt Sources:
- Timer0 Interrupt
- Timer1 Interrupt
- Timer2 Interrupt
- External Interrupts (PORTB & PORTC Falling Edge
Interrupts, A/D Interrupt, Key Scan Interrupt)
General Description
SH69P55A/69K55A is a single-chip 4-bit micro-controller. This device integrates a SH6610D CPU core, RAM, ROM, timer,
LCD/LED driver, I/O ports, watchdog timer, 10 channels 10-bit resolution ADC, low voltage reset, automatic key scan, PLL
and Zero Cross Detect function. The SH69P55A/69K55A is suitable for washing machine and micro-wave oven etc.
application.
= 2.4V - 5.5V
DD
= 4.5V - 5.5V
DD
OTP/MASK 8K 4-Bit Micro-controller
With LCD Driver & 10-bit SAR ADC
Oscillator (Code Option)
- Crystal Oscillator: 32.768kHz, 400kHz - 8MHz
- Ceramic Resonator: 400kHz - 8MHz
- External RC Oscillator: 400kHz - 8MHz
- Internal RC Oscillator: 4MHz ±5%
One Built-in PLL Oscillator (1, 2, 4, 8MHz)
Instruction Cycle Time (4/f
10 Channels 10-Bit Resolution Analog/Digital Converter
(ADC)
2 Channel Tone Generators
Built-in Automatic Key Scanner
Zero Cross Detect Function for AC Power Line
Read ROM Data Table Function (RDT)
One Channel 8+2Bit PWM Output
Reset
- Built-in Watchdog Timer (WDT) [(Code Option)]
- Built-in Power-on Reset (POR)
- Built-in Low Voltage Reset (LVR) [(Code Option)]
Two-Level Low Voltage Reset (LVR) (Code Option)
Two Low Power Operation Modes: HALT and STOP
OTP Type/Code Protection (SH69P55A)
MASK Type (SH69K55A)
28-pin SOP package; 44-pin QFP package; 32-pin DIP
package
1
SH69P55A/K55A
)
OSC
V2.2
