CacheVault Module Specifications

The following table lists the specifications for the CVFM and CVPMs. Design your system with an airflow that allows the
CacheVault device to operate within the operating temperature range listed in the following table.
Table 2: Specifications for the CacheVault Modules
Specification
Technology
Operating temperature (ambient)
Storage temperature
Humidity (storage and operating)
Mechanical (form factor)
The following figure shows the CVPM02 and CVPM05 module form factor information.
Figure 11: CVPM Dimensions
Broadcom
CacheVault Flash Module 04
On-board ONFI flash module
2.087 in. × 1.378 in.
CVPM02, CVPM05 Power Modules | CVFM04 Cache Module
0°C to 55°C
–40°C to 70°C
5% to 95% noncondensing
CacheVault Power Module 02
CacheVault Power Module 05
Remote supercapacitor pack
See Figure 11, CVPM
Dimensions.
