This is the Current panel. The top number indicates the current
that is currently passing through the chamber. The bottom number
is the Current Limit. During operation the device will apply the Set
Voltage unless the current exceeds the Current Limit. If that is the
case the Voltage will decrease such that the Current Limit is not
exceeded. If an invalid Current Limit is input, a sound will play and
the value will go to the maximum allowable value.
Note: The amount of heat generated is dependent on the power of
the electrophoresis. Exceeding the recommended values can
increase the thermal load too much and lead to overheating.
This is the Timer panel. The number indicates the current time
remaining on the timer when using the Timed Shutdown function.
The number displays in HH:MM format. To change the Timer, enter
in the desired value in the keypad and then press the "Set" button.
If an invalid Timer value is input, a sound will play and the value
will go to the maximum allowable value.
This is the Keypad. The number at the top is the current value
stored in the keypad. Pressing the numbers will modify this value.
The "Clear" button will erase that value, and the "Back" button will
erase the last number entered.
This is the main functions panel. The "Auxiliary Power" button will
turn on the liquid pump, sample rotation and sample mixing. Note:
Do not turn on the Auxiliary Power unless there is liquid in the
tank. Doing so with a dry tank could damage the pump.
The "Electrophoresis" button turns on the Electrophoresis Power.
It cannot be turned on unless the Auxiliary Power is already turned
on.
The "Timed Shutdown" button will activate the timed shutdown
based on the value shown in the Timer panel. It will count down
the timer, and upon reaching 00:00 will turn off the Electrophoresis
Power. The Auxiliary Power will remain on to keep the sample
cups hydrated.
