取扱説明書
Ver 1.00
FES-195
ランドロックM アイボリー
オプションセッ ト

Advertisement

loading
Need help?

Need help?

Do you have a question about the FES-195 and is the answer not in the manual?

Questions and answers

Summary of Contents for Snow Peak FES-195

  • Page 1 取扱説明書 Ver 1.00 FES-195 ランドロックM アイボリー オプションセッ ト...
  • Page 2 このたびは、 スノーピーク製品をお買い上げ頂きま して、 誠に有り難う ございます。 安全にご使用頂く ためにも本取扱説明書を必ずお読みく ださい。 取扱説明書は大切に保管してく ださい。 注意事項 フ ィ ールドでは予測不可能な事態が突発的に発生し、 時にはプロダクツの性能を超えるよ う な状況に直面する 場合もあり ます。 以下の説明がすべての危険な状況を説明している訳ではあり ません。 プロダクツの性能をよく 理解した う えで安全なキャ ンプをお楽しみく ださい。 火気厳禁 ●本製品の素材は難燃性ではあ り ません。 本製品内では燃焼式のラ ンタ ンやコ ンロ、 ヒーターな どの熱源や、 マ ッ チ、 ローソク、...
  • Page 3 ■下記の場所は製品構造上シーム処理ができない為、 水が侵入する可能性があ り ます。 下記の  場所及び浸水が確認さ れた箇所の外側ミ シン目にシームグ リ ッ プ剤を塗布 し糸目か らの水の  侵入を防いで く だ さ い。 1.ループや ト グルを縫いとめている ミ シン目Ⓐ 2.ファスナー レールを縫い込んでいる外側ミ シン目Ⓑ Ⓐ ミ シン目 ト グル ×6 ドアパネル上部 ト グル 6 ケ所。 (反対側も同様です。 ) Ⓑ ■セッ...
  • Page 4 ■各部名称 A フ レーム A フ レーム リ ッ ジポール ベンチレーシ ョ ン A フ レーム Cフ レーム Cフ レーム メ ッ シュ窓 センターフ レーム ドアパネル サイ ド ドアパネル 設営の手順 よ り安全に設営するためにも必ず2人以上で設営してく ださい。 本体裾部につ く ビルディ ングテープ3本 ①本体を設営しよ う とする場所に広 ラ...
  • Page 5 ③本体の裾部にある紺色紐が付いた リ ングピン を持ち A フ レームに差 し込みます。 ( 4 ケ所)  両側のセンター リ ングのテープのテンシ ョ ン を調節 し ます。 この時に A フ レーム上部の  プラスチッ ク フ ッ ク をあ ら か じめ付けておき ます。 紺色シール 注) リ ングピンを A フ レーム端部に入れる時は、 フ レーム端部を しっかり と動かない様に 持ち、...
  • Page 6 ⑥A フ レーム/C フ レーム/センターフ レームに各々上か ら下へ順々にプラスチッ ク フ ッ ク を掛けます。  クロス フ レーム部はベルクロ付テープを O リ ングに通 して固定 し ます。 Aフ レーム ※クロス  フ レーム部 プラスチッ ク フ ッ ク Cフ レーム フ レーム Oリ ング ⑦裾部リ ングピンに付いている、 ペグダウン用ループ及びテープにジュラ ピンペグを通し、 全て室内側でペグダウンを します。 また、 付属の張り綱ロープも、...
  • Page 7 ⑧必要に応じて最後にビルディ ングテープのバッ クルをはず センター ビルディ ングテープ し、 テープをポケッ トに収納して く ださい。 ( 設営後にビル ディ ングテープを外す場合は、 必ず室内側にペグダウン Y字型 ビルディ ングテープ を してテンシ ョ ンを室内側にかけて く だ さ い。 ) ビルディ ングテープポケッ ト Y字型 ビルディ ングテープ ■インナーテントの設営 ※イ ンナーテン トは、 ラン ドロ ッ ク本体のサイ ド ドアが無い側の室内に吊り下げます。  ...
  • Page 8 ②イ ンナーテン ト各ボ トムコーナーに付く フ ッ ク・ゴムループを本体 (フライ) のO リ ング、 ペグに引っ掛けます。 A フ レーム ペグダウ ン フ ッ ク付 テープ 紺色テープ イ ンナーボ トム ペグダウ ン ループ (紺色) A フ レーム 後部2ケ所に付くペグダウン Oリ ング テープは、 本体 (フライ) を留 めるペグに引っ掛けます。 センターフ...
  • Page 9 ■セーフティーリングの活用 本製品には、 強風時に側面か らの風に対 して安定性を保つセーフティ ー リ ングを備えています。 セン ターフ レーム内側にお手持ちのロープを下図のよ う にセ ッ ティ ング し ます。 警告 あ く までも補助対策です。 あ らゆる悪天候に耐え られる ものではあ り ません。 一時的な強風時 や、 即座に撤収が困難な場合にのみご使用く だ さ い。 セーフティ ー リ ングに体重をかけるな ど し ないで...
  • Page 10 ■ルーフシートの設営  ■ランドロック本体へのフッキング位置 センターフ レーム上部フ ッ クの Aフ レーム上部フ ッ クの テープ接続部へフ ッ キング テープ接続部へフ ッ キング Aフ レーム上部フ ッ クの テープ接続部へ フ ッ キング Cフ レーム上部フ ッ クの テープ接続部へフ ッ キング ※図は片面のみにフ ッ キング した状態 接続フ ッ ク 本体 (フライ) 側 ルーフ...
  • Page 11 ①設営は2人以上で行って く だ さ い。  ルーフ シー ト裏面を上に して広げます。 ②ラン ドロック本体片側のCフレーム、 Aフレーム、 センターフレームの上部フ ッ クのテープ接続部に、 ルーフ シー ト接 続フ ッ ク、 自在金具付きロープを それぞ れ引っ掛けます。   (左図■ラ ン ドロ ッ ク本体へのフ ッ キ ン グ 位置参考) ③2人で、 反対側の端のコー ドを持ち、 ラン ドロ ッ クに被せます。 ④Cフレームに被せてルーフシー...
  • Page 12 ■収納時の注意事項 □十分に乾燥 してか ら収納 して く だ さ い。 □設営後ビルディ ングテープを外した場合は、 撤収の前にビルディ ングテープのY字型とI字型のバッ クルをセ ッ ト します。 次回設営時にペグダウ ンの位置が決ま りやす く な り ます。  ※Y、 I字型部のペグダウンを本体の外側か ら行なった場合本体が広がり、 撤収時に再セッ ト しに く く な り ますので室内  側でペグダウ ン さ れる こ と をお勧め し ます。 □フ...
  • Page 13 ③長方形になった本体 (フライ) を本体収納ケースサイ ズ ④イ ンナーテン ト ドアパネル下部のファスナー を空けておき に入る幅にたたみます。 ます。 ⑤本体 (フライ) 同様に、 本体収納ケースサイ ズに入る様 ⑥ケース幅になった本体 (フライ) を裾部に向かって空気 にたたみます。 を出す様に巻いていきます。 イ ンナーテン トは④で開け ておいたファスナーに向かって、 空気を出す様に巻い ていき ます。 イ ンナーテン ト 本体 (フライ) ⑦本体 (フライ) と イ ンナーテン ト とルーフシー ト を ま とめて、 ⑧フ...
  • Page 14 ■グランドシートのセッティング方法 ①グラ ン ド シー ト を敷き ます。 ②出入口側はラ ン ドロ ッ ク本体と ③リ ビ ング側はラ ン ドロ ッ ク本体の    一緒にペグダウ ン して く だ さ い。  リ ングにフ ッ ク を掛けて く だ さ い。 ※光沢のあるPUコー ト面が表面にな り ます。 リ...
  • Page 15 メンテナンス ・ 保管 ●本製品はポリ エステル生地を組み合わせて使用 しています。 生地の特性を考慮 し、 でき る限り色移り し難い加工 と配色パターンを採用 していますが、 保管状態な どによ り、 色移り が発生する場合があ り ます。 ご了承く だ さ い。 ま た、 濡れたま まの保管は避けて く だ さ い。 ●濡れたま ま保管する と、 カ ビや悪臭、 生地の色移り、 生地の劣化な どの トラ ブルの原因にな り ますので、 使用後は 風通...
  • Page 16 単位はcm 品質表示 FES-195 ラン ドロッ クM アイボリ ー オプシ ョ ンセッ ト フラ イ本体材質/ 150Dポリエステルオッ クス ・ PUコーティ ング耐水圧 1,800mmミ ニマム (ルーフ部) 、 UVカ ッ ト加工、 テフロ ン 撥水加工 ・ 150Dポリ エステルオ ッ クス ・ PUコーティ ング 耐水圧1,800mmミ ニマム (ウ ォ ール部) 、 UVカ ッ ト加工、...
  • Page 17 Product Manual : Ver 1.00 FES-195 Land Lock M Ivory Option Set...
  • Page 18 Thank you for purchasing this Snow Peak Product. To ensure your safety when using this product, please read these instructions carefully before use.Please be sure to keep this manual in a safe place for future reference.If you find anything in the instruction manual that is difficult to understand, or if you find a defect with the product, stop using it immediately and contact the dealers where you purchased the product or Snow Peak Customer Service.
  • Page 19 ■Due to the product’s structure, seam processing is not possible in the following places, which may give way for water penetration. Apply a seam sealer on the outer stitching where you find a risk of water penetration to prevent water from entering through the seams. 1.
  • Page 20 ■Part Names A pole A pole Ridge pole ベンチレーシ ョ ン A pole C pole C pole Mesh window Center Pole Door panel Side door panel Setup procedure Make sure that two or more people take part in the setup. Three building tapes attached to the hem of the main body ①Spread the main body on a flat Land Lock main body...
  • Page 21 ③Hold the ring pin with the dark blue peg down loop on the hem of the body and insert it into the A pole. (4 places) Adjust the tension of the tape by pulling the belt with center rings on both sides. At this time, please hook the plastic hook in the upper part of the A pole beforehand.
  • Page 22 ⑥Please hook the plastic hooks from top to bottom to the A pole / C pole / center pole. Fix the crossing part of poles with tape with Velcro through the o-ring. A pole * Crossing part pole Plastic hook C pole Pole O-ring...
  • Page 23 ⑧If necessary, unbuckle the building tape and store Center building tape the tape in the pocket. If you remove the building tape after setting up, be sure to peg down inside and Y-Shaped building tape apply tension. Building tape pocket Y-Shaped building tape ■Setting up the inner tent * Please hang the inner tent in the room on the side of the Land Lock without the side door.
  • Page 24 ②Hook the hooks and rubber loops on each bottom corner of the inner tent to the O-rings and pegs on the main body (fly). Peg tape A pole Dark blue tape with hook Inner bottom Peg down loop O-ring on (dark blue) The peg-down tape at the rear two A pole...
  • Page 25 ■Use of safety rings This product has a safety ring that maintains stability during strong winds. Set up your rope inside the center pole, as shown below. WARNING The safety ring is only a supplementary measure and cannot withstand all bad weather. Please use this product only when there is a temporary strong win or when it is difficult to disassemble immediately.
  • Page 26 ■How to set up the Roof sheet ■The hooking position on the main body of the Land Lock. Hook to the tape connection part on the Hook to the tape hook at the top of the Center Pole. connection part on the hook at the top Hook to the tape of the A Pole.
  • Page 27 ①Make sure that two or more people take part in the set-up. Spread the Roof sheet with the back side up. ②Hook the Roof sheet connection hook and the Rope with Rope Tensioner to the tape connection part of the upper hooks on the C Pole, A Pole, and Center Pole on one side of the Land Lock main body.
  • Page 28 ■Precautions for disassembly / storage ●Before storage, the product should be cleaned and dried sufficiently. ●If you remove the building tape after setting up, connect the Y-shaped and I-shaped buckles of the building tape before taking it down. This will make it easier to position the pegs for the next time you set up.
  • Page 29 ③Fold the rectangular main body (fly) to a width that fits ④Leave the zipper at the bottom of the inner room door into the carry bag. panel open to allow air to escape easily. ⑤As with the main body (fly), please fold it to fit into the ⑥After reaching the width of the carrying bag, roll up the carry bag.
  • Page 30 ■How to set up the Ground sheet ①Spread the Ground sheet. ②Peg down the back side ③The living side should be together with the main hooked to the ring on the   ※The glossy PU coated surface will be the surface. body of the Land Lock.
  • Page 31 Snow Peak makes every effort to ensure our products are free from defects or flaws for proper function and longevity. If you feel this product is defective or needs repair, please contact Snow Peak or go to the Snow Peak dealer where you purchased this product.If the cause is defective manufacturing, we will repair or replace the product free of charge.In all other cases, we will repair it at an appropriate price.The decision to...
  • Page 32 FES-195 Land Lock M Ivory Option Set Fly / 150D Polyester Oxford, PU coating Waterproof rating: 1,800mm minimum(Roof), UV protection treatment, Teflon water-repellent finish, 150D Polyester Oxford, PU coating Waterproof rating / 1,800mm minimum(Wall), UV protection treatment, Teflon water-repellent finish Pole / A6061 (dia 19mm(0.7”) + dia 16mm (0.6”))
