RX2 Reference Guide
Copyright © April 2007 by LXE Inc.
All Rights Reserved
E-EQ-RX2RG-B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RX2 and is the answer not in the manual?

Questions and answers

Summary of Contents for LXE RX2

  • Page 1 RX2 Reference Guide Copyright © April 2007 by LXE Inc. All Rights Reserved E-EQ-RX2RG-B...
  • Page 2 Java® and Java-based trademarks and logos are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. or other countries, and are used under license. The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by LXE, Inc. is under license.
  • Page 3 License Statements: The RX2 Software Update Manager uses the OpenNETCF library under the following license terms: OpenNETCF.org Shared Source License ----------------------------------- This license governs use of the accompanying software (“Software”), and your use of the Software constitutes acceptance of this license.
  • Page 4 Chapter 3 – Power Supply Chapter 4 – System Configuration Chapter 5 – Application Development Chapter 6 – Wireless Network Configuration Appendix C – RX2 Battery Charger Note: A complete revision history is included in Appendix A, “Technical Specifications”. Revision Notice RX2 Reference Guide Explanation Updated Trademarks.
  • Page 5: Table Of Contents

    On Mode ...11 Off Mode ...11 Physical Controls... 12 Power Switch ...12 Restart Sequence ...12 External Connectors ... 13 USB-C Connector...13 USB Host Cable ...13 Pinout ... 13 ActiveSync... 13 COM3/RS-232 Connector ...14 E-EQ-RX2RG-B Table of Contents AYOUT RX2 Reference Guide...
  • Page 6 Synchronizing ...23 Explore...23 Disconnect ...23 Cold Boot and Loss of Host Re-connection ...24 Software Update Manager ... 25 Configuring the RX2 for the Software Update Manager...25 FTP Server Settings...25 Maintaining Files on the FTP Server...26 Directory Structure ...26 Operation ...26 Log Files...27...
  • Page 7 Reader Output ... 49 Filters...50 Parameters... 50 Read...52 Power...52 Output Power ... 53 Modulation... 53 Power Management ... 53 Firmware ...53 Firmware Upgrade ... 54 Reboot Reader... 54 Format ...55 Scanner ...56 Main ...57 Keys...57 COM Ports...58 E-EQ-RX2RG-B RX2 Reference Guide...
  • Page 8 Menu Options ... 72 Connection ... 73 Execution ... 74 Server Contact... 75 Startup/Shutdown... 76 Scan Config... 77 Display ... 77 Shortcuts ... 78 Adapters ... 79 Status... 82 HAPTER PPLICATION EVELOPMENT Introduction ... 83 RX2 Reference Guide Table of Contents E-EQ-RX2RG-B...
  • Page 9 Class 0 Commands ...86 Class 1 Commands ...86 Gen 2 Commands ...87 Data Format Commands...87 Power Commands ...87 LXE RFID Get Data Commands ...87 Tag Orientation and the RX2... 88 Hat Encoding... 89 Decimal - Hexadecimal Chart... 91 HAPTER IRELESS ETWORK Introduction ...
  • Page 10 Start Menu Program Options ... 131 Software Applications ...131 Inbox...131 Internet Explorer ...131 Media Player ...132 Transcriber ...132 Remote Desktop Connection...132 Control panel Options ... 133 Accessibility ...133 Battery...133 Bluetooth Manager ...133 RX2 Reference Guide PTIONS Table of Contents E-EQ-RX2RG-B...
  • Page 11 Introduction ... 139 Operation ... 139 Technical Specifications ... 140 NDEX Illustrations Figure 1-1 RX2 Connector Panel...2 Figure 1-2 RX2 Components ...2 Figure 1-3 Power Switch...5 Figure 2-1 Hardware ...9 Figure 2-2 Location of the Power Switch ...12 Figure 2-3 USB Type A to Serial Port Cable Pinout ...13 Figure 2-4 The RS/232 Serial Connector (COM3) ...14...
  • Page 12 Figure 3-17 RFID Properties / Format Tab ...55 Figure 3-18 Scanner Properties / Main Tab ...57 Figure 3-19 Scanner Properties / COM1 Port Settings ...58 Figure 3-20 Scanner Properties / COM3 Port Settings ...58 Figure 3-21 System / General tab...59 Figure 3-22 System / Memory ...60...
  • Page 13 Figure 5-31 Profile Properties Screen ...123 Figure 5-32 Select Profile ...123 Figure 5-33 Login Screen...124 Figure 5-34 ACU Status Tab...124 Figure B-1 Power Schemes...137 Figure C-1 RX2 Battery Charger ...139 Figure C-2 RX2 Battery Charger and Cables...140 E-EQ-RX2RG-B RX2 Reference Guide...
  • Page 14 Table of Contents RX2 Reference Guide E-EQ-RX2RG-B...
  • Page 15: Chapter 1 Introduction

    RFID tag reading and writing. The RX2 transmits information using a 2.4 GHz radio. The RX2 is a headless design (meaning no keyboard or monitor is attached to the RX2). A USB connector and ActiveSync utility provide for the configuration of the RX2.
  • Page 16: Components

    Circularly Polarized (RHCP) RFID antenna. RX2 Reference Guide Power Switch (Battery Powered Units Only) Input Power/Battery Charger Connector USB Client Connector COM3/RS232 Connector Figure 1-1 RX2 Connector Panel RX2 Computer Enclosure Fork Truck Mounting Bracket Power LED Antenna Enclosure Figure 1-2 RX2 Components...
  • Page 17: When To Use This Guide

    When to Use This Guide When to Use This Guide As the reference for LXE’s RX2 computer, this guide provides detailed information on its features and functionality. Use this reference guide as you would any other source book – reading portions to learn about the device and its capabilities, and then referring to it when you need more information about a particular subject.
  • Page 18: Document Conventions

    Note: CAUTION WARNING DANGER RX2 Reference Guide All caps are used to represent disk directories, file names, and application names. Rather than use the phrase “choose the Save command from the File menu”, this guide uses the convention “choose File | Save”.
  • Page 19: Getting Started

    On when DC power is connected. The power switch is located on the side of the RX2. When the RX2 has a charged internal battery or is connected to DC power, flipping the power switch to On turns on the RX2.
  • Page 20: Quick Configuration

    The following instructions relate to initial setup of ActiveSync. USB Connection By default, the RX2 is configured for a USB connection. Once the RX2 has finished booting, connect the ActiveSync cable to the RX2 and the PC. Cable for initial ActiveSync Configuration: USB Client to PC/Laptop ActiveSync starts automatically and establishes the connection between the RX2 and the PC.
  • Page 21: Getting Help

    You can also check the LXE ServicePass website for the latest manual releases. You can also get help from LXE by calling the telephone numbers listed on the LXE Manuals CD, in the file titled “Contacting LXE”. This information is also available on the LXE ServicePass website.
  • Page 22 Getting Help RX2 Reference Guide E-EQ-RX2RG-B...
  • Page 23: Chapter 2 Physical Description And Layout

    Chapter 2 Physical Description and Layout Hardware Configuration The RX2 hardware configuration is shown in the following figure. E-EQ-RX2RG-B INPUT 12-16 VDC USB-C COM3/RS-232 Figure 2-1 Hardware Charger DC Power Connection Adapter Cable Serial Cable RX2 Reference Guide...
  • Page 24: Central Processing Unit

    Any flash remaining beyond the Windows CE .NET image is formatted for use as a persistent memory drive (which appears in My Computer as the folder “System”). Any programs or data stored in this folder will be preserved if the power fails or the RX2 is coldbooted. There are no user accessible CF slots.
  • Page 25: Power Modes

    • DC power connection is removed If the power switch (if present) is set to On, the RX2 boots up when the battery charger is disconnected. If there is no power switch, the RX2 boots up when DC power is applied.
  • Page 26: Physical Controls

    Flipping the switch to Off powers off the RX2. The RX2 is also powered off if the charger is connected regardless of switch position. If the RX2 does not have a power switch, the RX2 is On whenever DC power is present. It is Off when DC power is not present.
  • Page 27: External Connectors

    To reset to factory default values, please refer to Chapter 3 “System Configuration” section titled “Utilities”. External Connectors USB-C Connector A D9 connector, labeled “USB-C” is provided on the RX2. Via the proper adapter cable, this connector provides a USB Type A Client connection for use with ActiveSync. USB Host Cable MX3XA069CBLD9USBCLNT...
  • Page 28: Com3/Rs-232 Connector

    COM3/RS-232 Connector A D9 connector, labeled “RS2/COM3” is provided on the RX2. This serial connection can be used for FTP connections to another computer. ActiveSync. Pinout Signal +5VDC Shell CGND Serial Cable RX2 Reference Guide The serial connection cannot be used for...
  • Page 29: Power Connector

    Charge the optional internal battery when connected to the RX2 Battery Charger. The RX2 can accept DC input voltages in the range of 10 to 16 Volts. When the RX2 detects that a charger is connected via Pin 3, the RX2 is Off regardless of the position of the power switch.
  • Page 30: Audio

    An internal beeper/speaker. Buzzer The buzzer is located on the back (driver’s side) of the RX2 enclosure. The buzzer has a loudness of at least 74 dB (2700 Hz) at 200 cm measured from the front of the unit. By default, the buzzer emits a On-Off buzzing pattern when the battery level is low. This feature can be disabled using the Control Panel “Volume &...
  • Page 31: Power Supply Options

    When the battery status switches from good to low, there is approximately 30 minutes of power left in the RX2 battery. Until the point the battery is exhausted the RX2 and its RFID reader function normally. If the battery is not recharged before it is depleted, the RX2 automatically shuts down.
  • Page 32: Rx2 Input Power Specifications

    In order to prevent loss of data when the battery low signal is observed, shut the RX2 Off and recharge the RX2’s internal battery. The internal battery is not user serviceable and should last five years with normal use before it requires replacement.
  • Page 33: Battery Charger

    Battery Charger Battery Charger For information on the RX2 Battery Charger, please refer to Appendix C, “RX2 Battery Charger”. Charging the Internal Battery Use the RX2 battery charger to charge the RX2’s internal battery. The RX2 battery charger charges the internal battery in less than 6 hours.
  • Page 34: Vehicle 12Vdc Direct Connection

    Correct electrical polarity is required for safe and proper installation. Connecting the cable to the RX2 with the polarity reversed will cause the power cable’s fuse to be blown. See the following figure titled “Vehicle Connection Wiring Color Codes” for additional wire color-coding specifics.
  • Page 35: Chapter 3 System Configuration

    Cable for initial ActiveSync Configuration: USB Client to PC/Laptop The D9 female end of the cable connects to the D9 male connector (labeled USB-C) on the RX2. The USB-A end of the cable connects to a USB port on a desktop or laptop PC.
  • Page 36: Activesync Remote Display

    Also, try disconnecting the cable from the RX2. From Microsoft ActiveSync on the PC, select File | Get Connected | Next. Reconnect the RX2 end of the cable as the PC is trying to connect. If this does not help, try the connection again, with a known good cable.
  • Page 37: Synchronizing

    ActiveSync and the RX2 ATTENTION: The remainder of this chapter assumes: • The RX2 is connected to a PC via ActiveSync • ActiveSync Remote Display is running on the PC Synchronizing Also, using Microsoft ActiveSync you can synchronize information on your desktop computer with the mobile device and vice versa.
  • Page 38: Cold Boot And Loss Of Host Re-Connection

    If the mobile device is associated with a second host, changing the name will destroy that partnership as well. This can cause some confusion when re-establishing partnerships with hosts. RX2 Reference Guide ActiveSync and the RX2 E-EQ-RX2RG-B...
  • Page 39: Software Update Manager

    The Manager requires an FTP server. The LXE software is stored on the FTP server and compared to the version of the software loaded on the RX2. If the FTP server contains a different version that is loaded on the RX2, the version on the FTP server is downloaded and installed on the RX2.
  • Page 40: Maintaining Files On The Ftp Server

    The Manager operates at boot up on the RX2. If ActiveSync Remote Desktop has been started, the process of the Manager can be viewed via the status window on the RX2. If it is not practical to view the Manager’s operation, a log file is maintained as discussed later in this section.
  • Page 41: Log Files

    Log Files The Manager maintains a log file on the RX2. The log file can be viewed while the RX2 is connected to a PC via ActiveSync Remote Desktop or can be copied to a PC for later viewing via the ActiveSync “Explore”...
  • Page 42: Figure 3-2 Sample Software Update Manager Log File

    Figure 3-2 Sample Software Update Manager Log File In the above example, the RX2 connects to the FTP server. There is one new software package which is downloaded to the RX2, copied to the proper location and installed. The RX2 is then warmbooted.
  • Page 43: Test Mode

    If max_iterations is not present, the following entry is used instead: TEST MODE: Iteration 1 If the delay parameter is present, the following entry appears at the end of the current iteration: TEST MODE: Sleeping seconds before next check... E-EQ-RX2RG-B RX2 Reference Guide...
  • Page 44: Windows Ce .Net 4.2

    All 2.4GHz radio configuration is included in Chapter 5, “Wireless Network Configuration”. Custom Applications A custom application can be loaded on the RX2. If the custom application is structured properly, the RX2 can automatically load and run the application. Additionally, the Software Update Manager can be used to load updates to the custom application.
  • Page 45: Taglogger

    The read interval affects battery life expectancy. A shorter read interval decreases expected battery life. This application writes tag data in the \System folder in a file named RFIDLOG.TXT. This file can be viewed on the RX2 using WordPad or transferred to a PC via ActiveSync or FTP for viewing. E-EQ-RX2RG-B...
  • Page 46: Log File Format

    Log format: sgtin:0829160.064304.240060097 Note: The <Header> field is not displayed. SGTIN-64 Standard format: <FilterValue>.<CompanyPrefixIndex>.<ItemReference>.<SerialNumber> Log format: “sgtin:”<CompanyPrefixIndex>.<ItemReference>.<SerialNumber> Examples Standard: 4.0080878.45980.30424 Log format: sgtin:0080878.45980.30424 Note: The <Header> field is not displayed. RX2 Reference Guide Installed Software 8/26/2005 10:07:53 AM 8/26/2005 10:07:55 AM E-EQ-RX2RG-B...
  • Page 47: Wavelink Avalanche Enabler (Optional)

    The RX2 has the Avalanche Enabler installation files loaded, but not installed, on the mobile device when it is shipped from LXE. The installation files are located in the System folder on CE devices. The installation application must be run manually the first time Avalanche is used.
  • Page 48: Desktop

    It contains the standard Windows menu options: Programs, Favorites, Documents, Settings, Help, and Run. The Start Menu Shutdown option found on most desktop PC’s is not present. Instead the RX2 provides an orderly shutdown when the power switch (if present) is flipped to Off.
  • Page 49: My Computer Folders

    Internal ATA Card (128 Meg total, 30 Meg free for User installed / created applications) Mounted network drive Operating System in ROM Applications Data saved by running applications Storage for downloaded files / applications Location for temporary files Preserved upon Reboot? RX2 Reference Guide...
  • Page 50: Start Menu Program Options

    Connection Transcriber Wavelink Avalanche Windows Explorer Because of the RX2’s headless design, these items are of limited functionality. Please see Appendix B, “Additional Configuration Options”, for more information on these items. RX2 Reference Guide Set Cisco radio / network parameters (See Chapter 5, “Wireless Network Configuration”...
  • Page 51: Communication

    Start FTP Server / Stop FTP Server The \System folder is the default directory for the FTP server on the RX2. The FTP server can be launched by selecting Start | Programs | Communication | Start FTP Server. The server defaults to Off (for security) unless it is explicitly turned on from the menu.
  • Page 52: Taskbar

    Windows Taskbar options. Note: The auto hide option should not be used on the RX2. Although pressing the Ctrl key then the Esc key makes the Start menu appear, the host PC’s Start menu also appears with this key press.
  • Page 53: Control Panel Options

    Please click the “?” box to get Help when changing Control Panel options. Because the RX2 is a headless design, many of the options have limited or no effect on the RX2. However, items such as the display options do change the appearance of the RX2 desktop when connected to a PC using ActiveSync and ActiveSync Remote Display.
  • Page 54: About

    Storage Manager Stylus System Volume and Sounds Because of the RX2’s headless design, these items are of limited functionality. Please see Appendix B, “Additional Configuration Options”, for more information on these items. About Access: Start | Settings | Control Panel | About Displays hardware and software details.
  • Page 55: Identifying Software Versions

    Control Panel Options Identifying Software Versions The “Versions” tab displays the versions of the LXE software installed. The LXE Image line displays the revision of the system software installed. Please refer to the last three digits to determine the revision level (i.e.: in the example below, the revision level is 2Cb).
  • Page 56: Date/Time

    Set Date, Time, Time Zone, and Daylight Savings after cold boot or at anytime. The RX2 uses the GrabTime utility to set the date and time from a time server automatically after booting (Internet access must be available to the RX2). This eliminates the need to establish an ActiveSync Remote Display connection to verify the date and time are correct after rebooting.
  • Page 57: Network And Dialup Connections

    Create a dialup, direct, or VPN connection on the mobile device. The RX2 is effectively limited to wireless (Summit or Cisco) and USB connections. Double click the Summit or Cisco icon (or select File | Properties while the Summit or Cisco icon is highlighted).
  • Page 58: Owner

    Identification Notes There is no change from general desktop PC Owner Properties display. Enter the information and click the OK box to save the changes. The changes take effect immediately. RX2 Reference Guide Blank Blank Figure 3-9 Owner Properties Control Panel Options...
  • Page 59: Password

    Click the Power On checkbox to set whether the user types a password at Power On. Click the Screen Saver checkbox to set whether the user types a password to clear the screensaver. If there is no screensaver chosen, this checkbox is ignored. Note: Screensavers are not installed by LXE. E-EQ-RX2RG-B Blank Disabled...
  • Page 60: Pc Connection

    RX2. Change …. DO NOT use the Change… button to select a different connection method. The RX2 can only connect via USB. If a different connection method is chosen, the RX2 must be returned to LXE for repair. Regional Settings...
  • Page 61: Remove Programs

    Firmware File These setting affect the LXE APIs, but can also be controlled by LXE APIs as well. For example, if a Separator is set in the Control Panel, it affects the format of the data returned by the LXERFIDTag1Read() API. However, the user application can also call the LXERFIDSetSeparator() API to change the separator.
  • Page 62: Tags

    Start | Settings | Control Panel | RFID | Tags tab Note: RX2 is restricted to 95% for Modulation. LXE recommends using the default setting of ID2 for Class 0 Singulation. A pop up option box is displayed if the user attempts to deselect all tag types. At least one class must be selected before the user can continue.
  • Page 63: Tag Types To Read

    Control Panel Options Tag Types to Read On the RX2, tag types to read is controlled by the APIs the user application calls. Therefore the Tag Types to Read check boxes have no effect on the RFID reader. However, the number of attempts does affect the LXE read APIs.
  • Page 64: Filters

    Start | Settings| Control Panel | RFID | Filters tab These options affect the LXE APIs. However, there are LXE APIs that can set filters. Click the Restore Defaults button to set the parameters in the Filters to their factory default setting.
  • Page 65 For example, suppose the following three tags exist: • c80507a000819530 • c80507a00081a1df • c80507a00081a985 Only the tags that end in “81a” are wanted. Two filter examples to identify the “81a” tags might be: Field Name Filter 1 Filter 2 E-EQ-RX2RG-B Offset Mask Value c80507a00081a RX2 Reference Guide...
  • Page 66: Read

    Start | Settings | Control Panel | RFID | Read tab Only the Beep once on Tag and Buzz during read cycle are applicable to the RX2. However due to the volume of the internal beeper, these audio signals are of limited use in a noisy environment.
  • Page 67: Output Power

    Click the Restore Defaults button to set the parameters to their factory default setting. Click OK to save changes or X to ignore any changes and return to the Control Panel. Note: RX2 is restricted to 95% for Modulation. Output Power Provides configuration for the output power applied during Read (or Write) operations. The range is 16 settings from +15dBm to +30dBm.
  • Page 68: Firmware Upgrade

    If an application gets installed by a .cab file, rename the .cab file to a different extension. 3. Warmboot the RX2 if changes had to be made in step 2 and re-establish the ActiveSync Remote Display session. 4. Open RFID the Control Panel. (Access: Start | Settings | Control Panel | RFID).
  • Page 69: Format

    Click the Restore Defaults button to set the parameters to their factory default setting. Click OK to save changes or X to ignore any changes and return to the Control Panel. E-EQ-RX2RG-B Figure 3-17 RFID Properties / Format Tab RX2 Reference Guide...
  • Page 70: Scanner

    Access: Start | Settings | Control Panel | Scanner The scanner panels have limited effect on the RX2. COM1 is connected to the RFID reader and parameters cannot be edited by the user. COM3 is an external RS-232 serial port.
  • Page 71: Main

    Control Panel Options Main The RX2 has two ports. The internal COM1 port is connected to the RFID reader. An external COM3 port is located on the side of the RX2. Do not connect a tethered scanner to the USB labeled port: Keys The Keys tab has no affect on the RX2.
  • Page 72: Com Ports

    The external serial port is COM3. Use this tab to make any necessary changes to establish a serial connection to another device. Barcode / Advanced The RX2 is not designed for a barcode scanner. RX2 Reference Guide Control Panel Options...
  • Page 73: System

    Device Description Copyrights Note: The default Device Name and Device Description may vary depending on the software revision loaded on the RX2. General System: This screen is presented for information only. The System parameters cannot be changed by the user.
  • Page 74: Memory

    Input Panel and click OK to save the changes. The changes take effect immediately. Copyrights This screen is presented for information only. The Copyrights information cannot be changed by the user. RX2 Reference Guide Figure 3-22 System / Memory Figure 3-23 System / Device Name Control Panel Options...
  • Page 75: Volume And Sounds

    Start | Settings | Control Panel | Volume & Sounds Icon Set volume parameters and assign sound wav files to CE .NET events. Due to the design of the RX2, the internal beeper (which plays most sound events) cannot be heard in noisy environments. Factory Default Settings...
  • Page 76: Utilities

    The CAB file can update the registry as desired and cause the unpacked file(s) to be placed in the appropriate location. The registry information needed is under the key HKEY_LOCAL_MACHINE \ SOFTWARE \ LXE \ Persist, as follows. The main subkey is any text, and is a description of the file. Then 3 values...
  • Page 77 “FileName”=“\SYSTEM\RFTERM.CAB” “FileCheck”=“\WINDOWS\LXE\RFTERM.EXE” “Order”=dword:10 ; this key installs JAVA [HKEY_LOCAL_MACHINE\SOFTWARE\LXE\Persist\Java] “FileName”=“\SYSTEM\JEODE.CAB” “FileCheck”=“\WINDOWS\EVM.EXE” “Order”=dword:30 CAB files for options not purchased are not loaded e.g. JAVA or RFID. If a CAB file is missing, please contact your LXE Representative. E-EQ-RX2RG-B RX2 Reference Guide...
  • Page 78 ; this key runs the APPLOCK main app [HKEY_LOCAL_MACHINE\SOFTWARE\LXE\Persist\AppLock] “FileName”=“\WINDOWS\APPLOCK.EXE” “FileCheck”=“\dummy” “Order”=dword:63 ; Autoexec [HKEY_LOCAL_MACHINE\SOFTWARE\LXE\Persist\AUTOEXEC] “FileName”=“\SYSTEM\AUTOEXEC.BAT” “FileCheck”=“dummy” “Order”=dword:50 ; these keys run the Avalanche Enabler [HKEY_LOCAL_MACHINE\SOFTWARE\LXE\Persist\Avalanche] “FileName”=“\SYSTEM\LXEAVA.CAB” “FileCheck”=“\SYSTEM\AVALANCHE\MODEL.DAT” “Order”=dword:4 “Installed”=dword:0 “PCMCIA”=dword:0 “Delay”=dword:0 [HKEY_LOCAL_MACHINE\SOFTWARE\LXE\Persist\AvaLaunch] “FileName”=“\SYSTEM\AVALANCHE\AVAINIT.EXE” “FileCheck”=“dummy” “Order”=dword:5 “Delay”=dword:0 “PCMCIA”=dword:0 “Installed”=dword:0 RX2 Reference Guide E-EQ-RX2RG-B Utilities...
  • Page 79 "FileName"="\PROGRAM FILES\LXE\CSTM\CSTMRX2.EXE" "FileCheck"="dummy" "Order"=dword:00000040 Denotes entries which have no effect on an RX2. For example, the RX2 does not support a Symbol radio, AppLock, RFTerm When you are installing your custom CAB file to the mobile device’s operating system, refer to the default image segments that are commented with “…...
  • Page 80: Launch.exe And Persistent Storage

    • AppMgr • Desktop • Favorites • Fonts • Help • Programs • Recent Note: Files in the Startup folder are executed, but only from \System\Startup. They are not copied to another directory. RX2 Reference Guide Utilities E-EQ-RX2RG-B...
  • Page 81: Regedit.exe

    GRABTIME.EXE The RX2 does not have a battery to power the real time clock when the unit is off. The GrabTime utility runs every time the RX2 is booted. This ensures the RX2 always has the correct time and date. The RX2 must have access to the Internet to reach a time server.
  • Page 82: Reflash The Mobile Device

    Reflash the Mobile Device How To When booting, the RX2 looks for a file named ‘reflash.tag’ in the \System folder. When this file is encountered, the RX2 loads a new bootloader image (eboot.nb0) into the boot flash. The tag file is deleted and the RX2 is rebooted to begin using the new boot loader.
  • Page 83: Wavelink Avalanche Enabler Configuration

    6. Click the OK button to save the changes. 7. Reboot the device if necessary. Update Monitoring Overview There are three methods by which the Enabler on an LXE device can communicate with the Agent running on the host machine. E-EQ-RX2RG-B...
  • Page 84: Mobile Device Wireless And Network Settings

    The Enabler running on LXE Windows CE devices will attempt to access COM1, COM2, and COM3. “Agent not found” will be reported if the agent is not located or a serial port is not present or available (COM port settings can be verified using the LXE scanner applet in the Control Panel).
  • Page 85: Enabler Configuration

    The Settings option under the File menu allows the user to access the control panel to locally configure the Enabler settings. The Enabler control panel is, by default, password protected. The default password is system. The password is not case-sensitive. Help Adapter Info About RX2 Reference Guide...
  • Page 86: Avalanche Update Settings

    Access: Start | Avalanche | File | Settings Use these menu options to setup the Avalanche Enabler on the mobile device. LXE recommends changing and then saving the changes (reboot) before connecting to the network. Alternatively, the Agent on the Wavelink Avalanche Management Console can be disabled until needed (refer to the Wavelink Avalanche Manager User Guide for details).
  • Page 87: Connection

    This option allows the user to configure Enabler settings using a special barcode that is created by the Avalanche Management Console. Not currently supported by LXE. Set up the Windows display at startup, on connect and during normal mode. The settings can be adjusted by the user.
  • Page 88: Execution

    Auto-Execute Selection Select Auto-Execute App Delay before execution RX2 Reference Guide Wavelink Avalanche Enabler Configuration Figure 3-27 Execution Options (Dimmed) An application that has been installed with the Avalanche Management system can be run automatically following each boot.
  • Page 89: Server Contact

    If the time interval for periodic contact with the Agent occurs, a mobile device that is in Suspend Mode can ‘wakeup’ and process updates. Reboot mobile device before attempting to contact Agent. RX2 Reference Guide...
  • Page 90: Startup/Shutdown

    Monitor and launch Enabler Manage Taskbar (Lock or Hide) Program Shutdown (Continue or Stop monitoring) RX2 Reference Guide Wavelink Avalanche Enabler Configuration Figure 3-29 Startup / Shutdown Options When the device boots, do not launch the Enabler application and do not attempt to connect to the Agent.
  • Page 91: Scan Config

    Scan Config Note: Scan Config functionality is a standard option of the Wavelink Avalanche System but is not currently supported by LXE on Windows CE. Display Update Window Display The user interface for the Enabler can be configured to dynamically change based on the status of the connection with the Agent.
  • Page 92: Shortcuts

    Configure shortcuts to other applications on the mobile device. Shortcuts are viewed and activated in the Programs panel. This limits the user’s access to certain applications when the Enabler is controlling the mobile device display. RX2 Reference Guide Wavelink Avalanche Enabler Configuration Figure 3-32 Application Shortcuts...
  • Page 93: Adapters

    Wavelink Avalanche Enabler Configuration Adapters Note: LXE recommends the user review the network settings configuration utilities and the default values in Chapter 5 before setting All Adapters to Enable in the Adapters applet. Manage Network Setting Manage Wireless Settings Current Adapter...
  • Page 94: Figure 3-34 Avalanche Network Profile Displayed

    Use Manual Settings Properties Icon Note: A reboot may be required after enabling or disabling these options. RX2 Reference Guide Wavelink Avalanche Enabler Configuration Selecting the Avalanche Icon will access the Avalanche Network Profile tab which will display current network settings.
  • Page 95: Figure 3-35 Manual Settings Properties Panels

    Wavelink Avalanche Enabler Configuration Network Wireless Figure 3-35 Manual Settings Properties Panels E-EQ-RX2RG-B RX2 Reference Guide...
  • Page 96: Status

    For descriptions of these Enabler parameters, refer to Chapter 5 “Wireless Network LXE does not recommend enabling “Manage Wireless Settings” for Summit Client devices. When you download a profile that is configured to manage network and wireless settings, the Enabler will not apply the manage network and wireless settings to the adapter unless the global Manage wireless settings and Manage network settings options are enabled on the Adapters panel (see Figure titled Adapters Options –...
  • Page 97: Chapter 4 Application Development

    The status can be queried by an SNMP Manager. Based on Microsoft’s SNMP architecture, the RX2 Agent is an extension agent. It resides in the \System folder and is named RX2Agent.dll. The complete RX2 branch of the LXE Private MIB is illustrated below.
  • Page 98: Lxeproductswincerx2Idagentver

    This variable is a read only integer that reports the status of the RX battery as follows: 1 = Good 2 = Low RX2 Reference Guide OBJECT IDENTIFIER ::= { lxeProductsWinCERX2 2 } OBJECT IDENTIFIER ::= { SNMP E-EQ-RX2RG-B...
  • Page 99: Apis

    Two APIs are available to deal specifically with the RX2 battery. RFID reader APIs are also available for applications to execute on the RX2. Both types of APIs can be called by including the lxeapi.h file, which is a part of RX2 SDK. Battery APIs LXEBatteryLife() The LXEBatteryLife() API can be used to return the status of the RX2 battery.
  • Page 100: Rfid Driver Apis

    RFID Driver APIs For the development of applications to execute locally on the RX2 device, API support for the functions described supplement the current RX2 APIs documented in the “LXE CE API Programming Guide” (available on the LXE Manuals CD or the LXE ServicePass website).
  • Page 101: Gen 2 Commands

    SET_PREAMBLE GET_POSTAMBLE SET_POSTAMBLE GET_SEPARATOR SET_SEPARATOR Power Commands READER_POWER_TIMEOUT LXE RFID Get Data Commands Get_Data E-EQ-RX2RG-B Kill Class 1 tag Retrieves the currently set read parameters (RF power level and Modulation depth). Set read parameters (RF power level and Modulation depth)
  • Page 102: Tag Orientation And The Rx2

    Tag Orientation and the RX2 The RX2 contains an RHCP (right hand circularly polarized) antenna. Tags orientation by rotation on the “Z” axis does not decrease the range of the RX2’s RFID reader. However, changing tag orientation by rotating on the “X” axis or “Y” axis can reduce the range of the RX2’s RFID reader.
  • Page 103: Hat Encoding

    Hat Encoding Hat Encoding The RX2 supports only 7-bit hat encoding which means only ^@ through ^_ (underscore) are supported. Desired ASCII Value DC1 (XON) DC3 (XOFF) ^_ (Underscore) Figure 4-3 Hat Encoded Characters Hex 00 through AD E-EQ-RX2RG-B Desired...
  • Page 104: Figure 4-4 Hat Encoded Characters Hex Ae Through Ff

    Ê Ë Ì Í Î Ï Ð Ñ Ò Ó Ô Õ Ö Figure 4-4 Hat Encoded Characters Hex AE through FF RX2 Reference Guide Desired Encoded ASCII ~. (Period) × Ø ~0 (Zero) Ù Ú Û Ü Ý Þ...
  • Page 105: Decimal - Hexadecimal Chart

    0x7B 0x7C 0x7D 0x7E 0x7F 0x80 0x81 0x82 0x83 0x84 0x85 0x86 0x87 0x88 0x89 0x8A 0x8B 0x8C 0x8D 0x8E 0x8F 0x90 0x91 0x92 0x93 0x94 0x95 0x96 0x97 0x98 0x99 0x9A 0x9B 0x9C 0x9D 0x9E 0x9F RX2 Reference Guide...
  • Page 106: Figure 4-6 Decimal - Hexadecimal Chart (160 To 255 Decimal)

    Figure 4-6 Decimal - Hexadecimal Chart (160 to 255 Decimal) RX2 Reference Guide 0xA0 0xC8 0xA1 0xC9 0xA2 0xCA 0xA3 0xCB 0xA4 0xCC 0xA5 0xCD 0xA6 0xCE 0xA7 0xCF 0xA8 0xD0 0xA9 0xD1 0xAA 0xD2 0xAB 0xD3 0xAC 0xD4 0xAD...
  • Page 107: Chapter 5 Wireless Network Configuration

    Chapter 5 Wireless Network Configuration Introduction The RX2 computer is equipped with either a Summit or Cisco radio. The Summit radio is an 802.11b/g radio. The Cisco radio is an 802.11b radio. The radio can be configured for no encryption, WEP encryption or WPA security.
  • Page 108: Summit Radio

    The WZC utility has an icon in the toolbar that looks like networked computers with a red X through them, indicating that Wireless Zero Config application is enabled but the connection is inactive at this time (the RX2 is not connected to a network). •...
  • Page 109: Main Tab

    Select ThirdPartyConfig in the Active Config drop down list as the active profile. Warmboot the RX2. The Summit Client Utility passes control to Wireless Zero Config and the WZC Wireless Information control panel. Using the options in the Wireless Zero Config panels, setup radio and security settings.
  • Page 110: Admin Login

    Access additional troubleshooting features on the Diags tab. After Admin login, the use can also: • Create, edit, rename and delete profiles on the Config tab • Edit global parameters on the Global Setting tabs RX2 Reference Guide Figure 5-3 Admin Password Entry Summit Radio E-EQ-RX2RG-B...
  • Page 111: Config Tab

    A string of 1 to 32 alphanumeric characters, name of the Config or Profile Default: Default SSID A string of up to 32 alphanumeric characters, the Service Set Identifier (SSID) of the WLAN to which the radio connects Default: Blank E-EQ-RX2RG-B Figure 5-4 SCU – Config Tab RX2 Reference Guide...
  • Page 112 Set the Auth Type radio parameter is set to “Open” for all configurations unless using LEAP (not WPA) and the AP is configured for network EAP only. In this case, set the Auth Type radio parameter to “LEAP”. RX2 Reference Guide Summit Radio E-EQ-RX2RG-B...
  • Page 113 – The settings for Auth Type, EAP Type and Encryption depend on the security type chosen. determine the proper settings for the security type implemented on the wireless LAN. E-EQ-RX2RG-B Please refer to “Summit Wireless Security”, later in this chapter, to RX2 Reference Guide...
  • Page 114: Status Tab

    After completing radio configuration, it is a good idea to review this screen to verify the radio has associated (no encryption, WEP) or authenticated (LEAP, WPA), as indicated above. RX2 Reference Guide Figure 5-5 SCU – Status Tab Summit Radio...
  • Page 115: Diags Tab

    Diagnostic Output box. If a fixed IP address has been assigned to the radio, this is also noted in the Diagnostic Output box. Note that the current IP address is displayed above this button. E-EQ-RX2RG-B Figure 5-6 SCU – Diags Tab RX2 Reference Guide...
  • Page 116: Global Settings Tab

    Main only = Main antenna only Aux only = Aux antenna only On = Use diversity Default: Preamble Type of radio preamble or header for packets. Options: Auto, Short, Long Default: Auto RX2 Reference Guide Figure 5-7 SCU – Global Settings Tab Summit Radio E-EQ-RX2RG-B...
  • Page 117 Access Point. Options: 0 to 2347 Default: 2347 Ping Payload Maximum amount of data to be transmitted on a ping. Options: 32, 64, 128, 256, 512, 1024 bytes Default: E-EQ-RX2RG-B RX2 Reference Guide...
  • Page 118 Certs Path A valid directory path, of up to 64 characters, where WPA Certificate Authority and User Certificates are stored on the mobile device. LXE suggests ensuring the directory path currently exists before assigning the path in this parameter. Note: The RX2 does not support authentication methods requiring certificates.
  • Page 119 Summit Radio CCX Features Use of Cisco Compatible Extensions (CCX) radio management and AP specified maximum transmit power features. Options: On, Off Default: Use of Wi-Fi Multimedia extensions. Options: On, Off Default: E-EQ-RX2RG-B RX2 Reference Guide...
  • Page 120: Summit Wireless Security

    • On the Main tab, click the Admin Login button and enter the password. • LXE recommends editing the default profile with the parameters for your network. Select the Default profile from the pull down menu. • Make any desired parameter changes as described in the applicable following section determined by network security type and click the Commit button to save the changes.
  • Page 121: No Security

    Once configured, click the Commit button. Ensure the correct Active Config is selected on the Main tab and warmboot. The SCU Main tab shows the device is associated after the radio connects to the network. E-EQ-RX2RG-B Figure 5-9 No Security RX2 Reference Guide...
  • Page 122: Wep

    Once configured, click the Commit button. Ensure the correct Active Config is selected on the Main tab and warmboot. The SCU Main tab shows the device is associated after the radio connects to the network. RX2 Reference Guide Figure 5-10 WEP Encryption Figure 5-11 WEP Keys...
  • Page 123: Leap Without Wpa Authentication

    If the Cisco/CCX certified AP is configured for open authentication, set the Auth Type radio parameter to Open. If the AP is configured for network EAP only, set the Auth Type radio parameter to LEAP. Figure 5-12 LEAP Configuration RX2 Reference Guide...
  • Page 124: Figure 5-13 Leap Credentials

    Once configured, click the Commit button. Ensure the correct Active Config is selected on the Main tab and warmboot. The SCU Main tab shows the device is associated after the radio connects to the network. RX2 Reference Guide Figure 5-13 LEAP Credentials Summit Radio...
  • Page 125: Wpa/Leap

    Click OK then click Commit. Ensure the correct Active Config is selected on the Main tab and warmboot. The SCU Main tab shows the device is associated after the radio connects to the network. E-EQ-RX2RG-B Figure 5-14 WPA/LEAP Figure 5-15 WPA/LEAP Credentials RX2 Reference Guide...
  • Page 126: Eap-Fast

    RADIUS server. The RADIUS server must have auto provisioning enabled to send the PAC provisioning credentials to the client device. Please refer to the “LXE Security Primer” for more information on the RADIUS server configuration.
  • Page 127: Figure 5-17 Eap-Fast Credentials

    The SCU Main tab shows the device is associated after the radio connects to the network. Note: Once authenticated, there is a file stored in the \System directory with the PAC credentials. If the username is changed, that file must be deleted. The filename is autoP.00.pac. E-EQ-RX2RG-B Figure 5-17 EAP-FAST Credentials RX2 Reference Guide...
  • Page 128: Wpa Psk

    Once configured, click the Commit button. Ensure the correct Active Config is selected on the Main tab and warmboot. The SCU Main tab shows the device is associated after the radio connects to the network. RX2 Reference Guide Figure 5-18 WPA/PSK Encryption Figure 5-19 PSK Entry...
  • Page 129: Cisco Radio

    Cisco Radio Cisco Radio The RX2 computer uses a Cisco radio. The radios can be configured for no encryption, WEP encryption or WPA security. Because there is no display or keyboard on the RX2, WPA choices are limited. All configuration items in this chapter assume that an ActiveSync Remote Display connection has been made.
  • Page 130: Profiles Tab

    Authentication Types Select an active profile to manage. Peer to peer (ad hoc) mode is not supported on the RX2. Infrastructure Mode must be set to Yes. See “No Security”, WEP” or “LEAP” for details on completing the Profiles screen.
  • Page 131: No Security

    • Network security must be set to LEAP. • The following parameters are accessible when LEAP is selected. Please enter the appropriate information. User Name User Password User Domain (optional) E-EQ-RX2RG-B Figure 5-22 Cisco ACU, WEP Keys RX2 Reference Guide...
  • Page 132: Wpa For The Cisco Radio

    WPA/LEAP requires the Cisco supplicant and Cisco ACU configuration tool. Other WPA authentications are not supported. Installing Radio drivers The system load on the RX2 contains two Cisco drivers. Since either driver supports WPA/LEAP and WPA-PSK, LXE recommends leaving the default driver installed. RX2 Reference Guide...
  • Page 133: Wireless Network Configuration For Psk

    From the “Select Active Profile” pull down list, select <External Settings>. Click OK and warmboot since the radio card cannot be removed from the RX2 After booting up, the Microsoft Zero Config tool should start. If it does not, start configuring the wireless connection by clicking on the icon on the task bar shown in below.
  • Page 134: Figure 5-26 Wireless Information Screen

    Make sure the “Use Windows to configure my wireless settings” box is checked. Set the “Networks to access” drop down box to “Only access points”. Peer to peer (ad hoc) mode is not supported on the RX2. Make sure Only access points is selected.
  • Page 135: Figure 5-28 Wpa Psk Configuration

    Enter an ASCII network key in the text field. Hex keys do not work in the Microsoft Zero Config utility at this time. There is no server authentication when using WPA-PSK. Click the OK button to complete the configuration. E-EQ-RX2RG-B Figure 5-28 WPA PSK Configuration RX2 Reference Guide...
  • Page 136: Wpa/Leap

    Start the Cisco ACU by clicking the icon on the desktop or navigate to Start | Programs | Cisco | ACU. Click on the Profile tab. Click the Rename button. Name the profile. Click the Edit . . . button. RX2 Reference Guide Figure 5-29 ACU Profile Tab Figure 5-30 Renaming Profile Cisco Radio E-EQ-RX2RG-B...
  • Page 137: Figure 5-31 Profile Properties Screen

    Enter the SSID and Client Name in the correct fields. Set the Network Security Type to LEAP(WPA). Click the OK button. Use the drop down box to choose the profile just configured. Click OK. E-EQ-RX2RG-B Figure 5-31 Profile Properties Screen Figure 5-32 Select Profile RX2 Reference Guide...
  • Page 138: Figure 5-33 Login Screen

    The mobile device associates and displays the sign on screen. Click the Status tab to display status. RX2 Reference Guide Figure 5-33 Login Screen Figure 5-34 ACU Status Tab Cisco Radio E-EQ-RX2RG-B...
  • Page 139: Appendixa Technical Specifications

    128 MB Flash 128MB of SDRAM None Sirit IN-210 Accepts Type I, II and III, PCMCIA 2.01 compliant RX2 with Internal Battery DB-9 Connector, USB-C DB-9 Connector, COM3/RS232 DC input or Charger Connection 4000 mAh NiMH Comments 32 bit CPU (with on-chip cache)
  • Page 140: Cable Specifications

    Cable Pinouts and Diagrams MX3XA069CBLD9USBCLNT – CBL, USB D9F to USB Type A Receptacle ActiveSync: Connect from mobile device USB-C port to USB Type A Host. E.g. laptop/desktop PC. RX2 Reference Guide Appendix A Technical Specifications Plug Receptacle USB A RS232...
  • Page 141: Environmental Specifications

    Vibration Shock RFID Antenna Specifications Antenna Type Frequency Band See Also: RX2 Environmental Specifications. E-EQ-RX2RG-B -4°F to 122°F (-20°C to 50°C) (non-condensing) -22°F to 158°F (-30°C to 70°C) (non-condensing) IEC IP66 Up to 90% non-condensing at 104°F (40°C) Based on MIL Std 810F 8 kV air, 4kV contact 14G, 10ms, ½...
  • Page 142: Radio Specifications

    Operating Temperature Storage Temperature Connectivity Antenna RX2 Reference Guide Appendix A Technical Specifications Compact Flash via a PCMCIA adapter 2.4 - 2.4897 GHz IEEE 802.11b 802.11g DSSS OFDM 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54 Mbps...
  • Page 143: Revision History

    Chapter 3 – Power Supply Chapter 4 – System Configuration Chapter 5 – Application Development Chapter 6 – Wireless Network Configuration Appendix C – RX2 Battery Charger E-EQ-RX2RG-B Explanation Updated Trademarks. Revised “Accessories” listing. Revised “PCMCIA Slot” and “Charging the Internal Battery” sections.
  • Page 144 Appendix A Technical Specifications RX2 Reference Guide E-EQ-RX2RG-B...
  • Page 145: Appendixb Additional Cofiguration Options

    Appendix B Additional Cofiguration Options Introduction This appendix details programs loaded on the RX2 and configuration options that are of limited value on the RX2 due to its headless design. All configuration items in this chapter assume that an ActiveSync Remote Display connection has been made.
  • Page 146: Media Player

    Windows PC Microsoft Media Player options. Click the “?” button to access Media Player Help. Transcriber Access: Start | Programs | Transcriber The Transcriber is not supported on the RX2 as there is no touchscreen for input. Remote Desktop Connection Access: Start | Programs | Remote Desktop Connection There are few changes in the CE .NET version of Remote Desktop Connection as it relates to the...
  • Page 147: Control Panel Options

    Certificates Access: Start | Settings | Control Panel | Certificates Certificates are not practical for the RX2 since the RX2 does not maintain the real time clock when powered off and certificates are date sensitive. Dialing Access: Start | Settings | Control Panel | Dialing The RX2 does not include or support a modem.
  • Page 148: Display

    Start | Settings | Control Panel | Display Icon Set background graphic, color scheme appearance, and power scheme properties. Although the RX2 does not have a display, changes made to these options change the RX 2 desktop displayed using ActiveSync Remote Display.
  • Page 149: Internet Options

    Changes to the keyboard panel have no effect on the RX2. Mixer Access: Start | Settings | Control Panel | Mixer Icon Changes to the Backlight tab have no effect on the RX2 as the RX2 does not support a microphone. Mouse Access: Start | Settings | Control Panel | Mouse Set the double-click sensitivity for mouse clicks.
  • Page 150: Pcmcia

    Access: Start | Settings | Control Panel | PCMCIA Note: Radio card in Slot 0, Internal ATA in Slot 2. Card slots are not user accessible on the RX2. Factory Default Settings Slot 0 Disable slot now Power slot during sleep (3.3v)
  • Page 151: Power

    IMPORTANT: Do not change the Switch to Suspend to any option other than Never. If the RX2 enters suspend, the only way to wake from suspend is to reboot. suspend is enabled, reboot and change the value back to Never.
  • Page 152: Storage Manager

    Start | Settings | Control Panel | Stylus Set double-click sensitivity properties As the RX2 has no touchscreen, the Calibration tab has no effect. Double Tap Follow the instructions on the screen and click the OK box to save the changes. The changes take effect immediately.
  • Page 153: Appendixc Rx2 Battery Charger

    Operation The RX2 battery charger accepts AC power input. The charger can be used to charge an internal RX2 battery in less than six hours. The battery changer can operate in environments from 32°F to 104°F (0°C to 40°C). The charger has a •...
  • Page 154: Technical Specifications

    The battery charger cabling incorporates a breakaway connector on the charger end. Please refer to the RX2 User’s Guide for information on installing the cabling necessary for the charger. Technical Specifications Operating Temperature Storage Temperature Input Charging Time RX2 Reference Guide...
  • Page 155: Index

    0 - 159 ...91 160 - 255 ...92 Desktop...34 Device Name and description...60 Disable slot now ...136 Diversity Receive...102 Transmit ...102 Document Conventions ...4 Environmental Specifications...127, 140 Expand Control Panel...38 External Connectors Battery Charger ...15 Power ...15 Serial ...14 USB-C...13 RX2 Reference Guide...
  • Page 156 Recycle Bin...34 Inbox Outlook ...131 Internet Explorer Radio card and ISP required ...131 Internet Options ...135 LEAP Summit Radio ...109 RX2 Reference Guide Loss of Host Re-connection...24 MAC Address...41 Main...56 Manuals ...7 Media Player...132 Memory ...59 allocate for programs or storage...60 Memory installed...59...
  • Page 157 When to use this guide...3 Windows CE. NET on-line Help ...30 Windows Explorer...37 Windows version ...59 Wire Color Cable Wiring...20 Supported Authentications ...118 Summit Radio...94 System Requirements...118 WPA/LEAP Summit Radio ...111, 112 WPA-PSK Summit Radio ...114 Zero Config Utility, Microsoft ...119 RX2 Reference Guide...
  • Page 158 Index RX2 Reference Guide E-EQ-RX2RG-B...

Table of Contents
