Page 2 Summit Data Communications, Inc. All rights reserved. Symbol, the Symbol logo and Spectrum24 are registered trademarks of Symbol Technologies, Inc. The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by LXE, Inc. is under license.
Page 3: Revision Notice
Appendix B Regulatory Notices and Safety Information Note: A complete revision history is included in Appendix B, “Regulatory Notices and Safety Information”. Revision Notice VX7 User’s Guide Explanation Added new section. Update approvals for 802.11 a/b/g radio. Remove Summit Declaration of Compliance for consistency.
Page 5: Table Of Contents
The 95-key QWERTY Keyboard with Pointing Device ...13 Key Maps ...13 NumLock and the VX7... 13 CapsLock and the VX7... 13 Scroll Lock and the VX7 ... 14 Keyboard Backlight...14 Pointing device...14 The 60-key QWERTY Keyboard ...15 IBM 3270 Keypad Overlay ...15 IBM 5250 Keypad Overlay ...15...
Page 6 Mounting Dimensions ...34 Step 2 – Attach RAM Mount Ball to the VX7... 35 Step 3 – Assemble Optional Keyboard Brackets ... 36 Step 4 – Attach VX7 and Bracket Assembly to RAM Mount ... 38 Completed Assembly...40 U-Bracket Mount System ...41 Components...41...
Page 7 Connect Power Cable and Optional UPS Battery Pack ... 65 External Power Supply, Optional... 66 Vehicle 12-80VDC Power Connection ... 67 Power Adapter Cable... 73 Fuse Replacement for the VX7 ... 74 Strain Relief Cable Clamps ... 75 PERATION Powering On/Off... 77 Keyboard Backlight ...
Page 8 Key Map 101-Key Equivalencies...87 60-key Standard Keypad ... 88 Key Map 101-Key Equivalencies...88 IBM 3270 Keypad Overlay ...93 IBM 5250 Keypad Overlay ...93 PPENDIX EGULATORY Approvals ... 96 Revision History... 101 NDEX VX7 User’s Guide OTICES AND AFETY NFORMATION Table of Contents E-EQ-VX7OGWW-H...
Page 9 Figure 18 Small and Large Virtual Keyboards ...21 Figure 19 Input Panel Properties...22 Figure 20 Connect Vehicle RAM Mount Bracket to Vehicle...31 Figure 21 VX7 RAM Bracket - Mounting Dimensions (Not To Scale) ...32 Figure 22 RAM Clamp Mount Components...33 Figure 23 Assembled RAM Clamp Mount ...33 Figure 24 RAM Clamp Mount - Mounting Dimensions (Not To Scale) ...34...
Page 10 Figure 52 VX7 with Generic Barcode Scanner Attached ...60 Figure 53 Generic Barcode Scanner ...60 Figure 54 Connect Serial Cable to COM3 ...61 Figure 55 VX7 Ethernet/USB-H/USB-C Dongle Cables ...62 Figure 56 Connect Ethernet/USB Dongle Cable ...62 Figure 57 Connect USB Device to Dongle Cable...63 Figure 58 Connect Ethernet Cable to Adapter Cable...63...
Page 11: The Vx7 Vehicle Mount Computer
Microsoft Windows CE icons that the Windows CE operating system supports. An illuminated keyboard is available to facilitate use in dimly lit areas. The VX7 provides the power and functionality of a desktop computer in a vehicle mounted unit, with a wide range of options: •...
Page 12: Document Conventions
Available Uninterruptible Power Supply (UPS) Battery Pack • Available RAM Mount • Extended temperature version includes touchscreen heater Note: The “VX7 Reference Guide” contains VX7 technical information and advanced functions. Document Conventions This reference guide uses the following document conventions: ALL CAPS Menu|Choice “Quotes”...
Page 13: Environmental Specifications
-22°F to 140°F (-30°C to 60°C) [non-condensing] -22°F to 140°F (-30°C to 60°C) [condensing] IP66 per IEC60529 Up to 90% non-condensing at 104°F (40°C) 100% Based on MIL Std 810F 15 kV 32.8 feet (10 meters) Direct line of sight only VX7 User’s Guide...
Page 14: Quick Start
(e.g. antenna, external keyboard and/or barcode scanner) and a power source. Use this guide as you would any other source book -- reading portions to learn about the VX7, and then referring to it when you need more information about a particular subject. This guide takes you through installation and operation of the LXE VX7.
Page 15: Troubleshooting
AppLock is installed and running on the mobile device. AppLock restricts User access to running programs. Changes or modifications require Administrator access. Refer to AppLock in the VX7 Reference Guide for setup and processing information. Tap File | Exit to close the RFTerm application.
Page 16: Components
When the internal antenna option is ordered, the internal antenna is mounted on the inside of the Access Panel Cover. VX7 User’s Guide Figure 1 VX7 Components, Top View Figure 2 VX7 Components, Front View Components 1. Access Panel Cover (See...
Page 17: Figure 3 Vx7 Components, Bottom View
COM1 / SCANNER Note: COM1 is configured with Pin 9 +5V. COM3 is labeled “COM2/3” and is configured with Pin 9 RI. Please see the VX7 Reference Guide for details. E-EQ-VX7OGWW-H CAUTION: For continues protection against risk of fire, IP66 THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.
Page 18: Figure 6 Vx7 Access Panel
Note: The tethered access panel cover is not shown in the illustration above. VX7 User’s Guide CF ATA PCMCIA A PCMCIA B Figure 6 VX7 Access Panel Components 1. SD Memory Card Slot 2. Compact Flash ATA Hard Drive 3. PCMCIA Slots...
Page 19: The Full-Screen Display
PCMCIA, ATA and SD Slots The VX7 has two PCMCIA slots. These slots are intended for use with Type I or II cards, such as LXE’s 802.11 radios. These slots are hot swappable per PCMCIA specifications. The Compact Flash (CF) slot contains the Compact Flash ATA hard drive. This drive contains the Operating System and the Documents and Settings.
Page 20: Applock And The Vx7
AppLock. Multi Application AppLock A checkmark indicates applications currently active or available for Launching by the user. When Keyboard is selected, the VX7 default input method (Input Panel, Transcriber, or custom input method) is activated. Note: If “Keyboard”...
Page 21: Using The Keypad
The previous application continues to run in the background. End-user key presses affect the application in focus only. See the VX7 Reference Guide for AppLock setup instruction. E-EQ-VX7OGWW-H VX7 User’s Guide...
Page 22: The Keyboards
• A standard PS/2 keyboard via an adapter cable attached to the “Keyboard/MOUSE” port on the VX7. The adapter cable also provides a connector for a PS/2 mouse. • A USB keyboard via a dongle cable attached to the “Ethernet/USB” connector is available on certain VX7’s.
Page 23: The 95-Key Qwerty Keyboard With Pointing Device
Designed for ease of use with the Windows CE operating system, the 95-key keyboard with pointing device connects via a cable to the keyboard port on the VX7. Additional Windows keys (the Windows logo key and the Application key) and an integrated pointing device are provided for use with Windows CE operating system.
Page 24: Scroll Lock And The Vx7
Scroll Lock and the VX7 For the 95-key keyboard, the Scroll Lock key is backlit Scroll Lock is on, the backlight for the Scroll Lock key is amber. The default values for CapsLock and Scroll Lock are Off. Keyboard Backlight The 95-key keyboard backlights each key with an LED.
Page 25: The 60-Key Qwerty Keyboard
IBM 3270 Keypad Overlay CAPS CTRL Attn SysReq SHIFT The 60-key keypad is available with an IBM 3270 overlay designed to allow the user to enter terminal emulator commands when running LXE’s RFTerm™ program. IBM 5250 Keypad Overlay CAPS CTRL Attn SysReq SHIFT The 60-key keypad is available with an IBM 5250 overlay designed to allow the user to enter terminal emulator commands when running LXE’s RFTerm™...
Page 26: Key Maps
The hidden keys supported by the VX7 are listed in Appendix A, “Key Maps”. Unused Key Functions There are several key functions on the 60-key keyboard that are not used on the VX7. These include: • <2nd> <F3> – The Resume/Suspend function is not used, as the VX7 does not support these power management modes.
Page 27: Numlock And The Vx7
The 60-key keyboard does not have a NumLock indicator or key. NumLock can be toggled On or Off using the <2 The default value for NumLock is On. The warmboot behavior of NumLock can be configured. Please refer to the “VX7 Reference Guide” for more information. Keyboard Backlight The LXE keyboard keys are backlit with LEDs.
Page 28: Secondary Keys Led
The default value of CapsLock is “Off”. CapsLock after a reboot, please refer to the “VX7 Reference Guide”. Secondary Keys LED The keyboard is equipped with several secondary keys. These keys are identified by the superscripted text found on the keyboard keys. The secondary keys are accessible by using two (2) keystrokes: the <2...
Page 29: Control Keys
<F4> and <F5>keys are not used as the display brightness is adjusted via the buttons on the control panel. The 2 functions of the <F6>, and <F7> keys are not used as the VX7 has TFT LCD screen with no provision for contrast adjustments. The 2 functions of the <F8>...
Page 30: Custom Key Maps
The System Administrator can create custom key maps. Details are in the VX7 Reference Guide. General Windows CE Keyboard Shortcuts Use the keyboard shortcuts in the chart below to navigate with any VX7 keyboard. These are standard keyboard shortcuts for Windows CE applications.
Page 31: Usb Keyboard/Mouse
The Keyboards USB Keyboard/Mouse A standard USB keyboard and/or mouse can be attached to the VX7 using the appropriate dongle cable. The dongle cable attaches to the VX7 and provides a USB connector. Please refer to documentation provided with the USB keyboard and mouse for more information on their operation.
Page 32: Enabling The Input Panel
The Input Panel is disabled by default. To enable the Input Panel, select Start | Settings | Control Panel |Input Panel icon. Make sure the “Allow applications to change the input panel state” checkbox is checked and warmboot the VX7. VX7 User’s Guide...
Page 33: Power Supply
Power Supply Power Supply Vehicle power input for the VX7 is 12V to 80V DC and is accepted without the need to perform any manual adjustments within the VX7. See the section titled “Installation”, sub-section titled “Vehicle 12-80V DC Direct Connection”. An optional Uninterruptible Power Supply (UPS) battery pack is available for the vehicle power supply connection.
Page 34: Getting Help
LXE Manuals CD or logon information for the ServicePass web pages. You can also get help from LXE by calling the telephone numbers listed on the LXE Manuals CD, in the file titled “Contacting LXE”. This information is also available on the LXE website.
Page 35 Cable, PC, D9 to D9 Power Cables Cable, Input Power, 12 FT, VX5 VX6 VX7 Adapter Cable, VX1 VX2 VX4 Power Cable to VX5 VX6 VX7 Power Supplies Power Supply, External, AC, W/US Power Cord VX5 VX6 VX7 Power Supply, External, AC, No Power Cord VX5 VX6 VX7...
Page 36 Scanner, Powerscan, XLR, Low Temp, 8’ Cbl Scanner, Powerscan, XLR, Low Temp, 12’ Cbl Scanner, LS3408 Fuzzy Logic SR, D9 Interface Cable, 8ft Scanner, LS3408 Extended Range, D9 Interface Cable, 8ft VX7 User’s Guide Manuals and Accessories 9000A076CBLHEADSET1 HX1A501SINGHEADSET HX1A502DUALHEADSET...
Page 37 Manuals and Accessories Bluetooth Scanner and Accessories LXE Bluetooth module with laser ring scanner, battery, two hand/wrist straps (large and small) LXE Bluetooth module with 1D/2D imager ring scanner, battery, two hand/wrist straps (large and small) Li-Ion Spare Battery for LXE Bluetooth Ring Scanner...
Page 38 Manuals and Accessories VX7 User’s Guide E-EQ-VX7OGWW-H...
Page 39: Installation
(5.64±.56 N/m). Note: Torquing tool is not supplied by LXE. Bolts, washers, and wrench needed when attaching the bottom mounting bracket to the vehicle are not supplied by LXE. Several types of mounting systems are provided for the VX7: •...
Page 40: Ram Mount System
RAM Mount System Components RAM Mounting Assembly RAM Integrated Keyboard Mount VX7 User’s Guide The RAM mounting assembly consists of the following parts: - or - The optional RAM integrated keyboard mount consists of the following parts: Install Mounting Brackets...
Page 41: Torque Measurements
Determine the position for mounting the RAM ball base. Be sure to position the RAM bracket to allow access to the switches and ports on the bottom of the VX7. Attach the RAM ball base to the vehicle mounting surface using four 1/4 bolts (or equivalent) fasteners.
Page 42: Mounting Dimensions
Install Mounting Brackets Mounting Dimensions Note: Drill and tap holes for 1/4 bolts. 60º 60º 3.69" / 93.73 mm 2.75" / 69.85 mm 120º 120º Figure 21 VX7 RAM Bracket - Mounting Dimensions (Not To Scale) VX7 User’s Guide E-EQ-VX7OGWW-H...
Page 43: Step 1B - Mount Vehicle Ram Clamp Mount
Align the bolts with the holes in the lower clamp piece. Place the nylon locking nuts (D) on the bolts and tighten the bolts. E-EQ-VX7OGWW-H Figure 22 RAM Clamp Mount Figure 23 Assembled RAM Clamp Mount Components VX7 User’s Guide...
Page 44: Mounting Dimensions
Mounting Dimensions Figure 24 RAM Clamp Mount - Mounting Dimensions (Not To Scale) VX7 User’s Guide Install Mounting Brackets 2.56” (65.02 mm) 1.84” (46.74 mm) Varies depending on bolt length E-EQ-VX7OGWW-H...
Page 45: Step 2 - Attach Ram Mount Ball To The Vx7
Place the VX7 face down on a stable surface. Position the RAM ball bracket on the rear of the VX7, aligning the curved edge on the RAM mount bracket with the curved edge on the VX7. Attach with four 1/4-20x5/8 bolts, using one flat washer and one locking washer per bolt.
Page 46: Step 3 - Assemble Optional Keyboard Brackets
RAM mounting bracket with three 1/4-20x5/8 bolts, using one flat washer and one locking washer per bolt. Place the locking washer on the bolt before the flat washer. VX7 User’s Guide Figure 26 Attach Keyboard Mounting Bracket Install Mounting Brackets...
Page 47: Figure 27 Attach Keyboard To Mounting Plate
Excess keyboard cable length can be looped around the hooks on the bottom of the keyboard mounting plate. E-EQ-VX7OGWW-H For the 95 key keyboard, use four 8-32x5/8 screws For the 60 key keyboard, use four 10-32x5/8 screws Figure 27 Attach Keyboard to Mounting Plate VX7 User’s Guide...
Page 48: Step 4 - Attach Vx7 And Bracket Assembly To Ram Mount
If the optional integrated keyboard bracket is not used, slip the RAM arm over the ball on the vehicle RAM ball bracket. Insert the ball of the RAM mount bracket into the RAM arm. Adjust the VX7 to the desired position and tighten the knob on the RAM arm using the supplied RAM wrench.
Page 49: Figure 29 Ram Assembly With Keyboard
RAM arm over the ball on the vehicle RAM mount bracket. Insert the ball of the RAM mount bracket into the RAM arm. Adjust the VX7 to the desired position and tighten the knob on the RAM arm using the supplied RAM wrench.
Page 50: Completed Assembly
Install Mounting Brackets Completed Assembly RAM Mount RAM Mount with Integrated Keyboard Mount Figure 30 Completed RAM Mount Assembly Note: RAM ball base shown. VX7 User’s Guide E-EQ-VX7OGWW-H...
Page 51: U-Bracket Mount System
Back Bracket without Keyboard Mount Back Bracket with Keyboard Mount E-EQ-VX7OGWW-H This bracket is mounted to the vehicle. The VX7 can be mounted to the bottom mounting bracket with or without an integrated keyboard mounting bracket. Additionally, the UPS battery pack may be mounted to the bottom mounting bracket.
Page 52: Mounting Positions
Torque all screws and bolts according to the following table: For these screws and bolts… #6 screws #8 screws 1/4 bolts VX7 User’s Guide Figure 31 Suggested Mounting Positions Torque to 8.0±.5 in/lb (0.9±.05 N/m) 16.0±1 in/lb (1.8±.11 N/m) 50.0±5 in/lb (5.64±.56 N/m)
Page 53: Procedure
IMPORTANT: Mount to the most rigid surface available. After the bottom bracket has been attached to a rigid surface, you are ready to assemble the VX7 bracket configuration. Mounting Dimensions Figure 33 VX7 Bracket - Mounting Dimensions (Not To Scale)
Page 54: Step 2 - Attach Rear Bracket Vx7
Place the VX7 face down on a stable surface. Align the rear bracket with the holes on the back of the VX7. Attach with four 1/4- 20x5/8 bolts, using one flat washer and one locking washer per bolt. Place the locking washer on the bolt before the flat washer.
Page 55: Step 3 - Attach Vx7 Assembly To Bottom Mounting Bracket
Back bracket without integrated keyboard mount shown. Loosely tighten each bolt as it is inserted. Important: Loosen the hex bolts on both sides to adjust the viewing angle of the mounted VX7. Torque the hex bolts to 50±5 in/lb (5.64±.56 N/m). Note: Test the torque on the bolts frequently during operation and re-tighten if necessary to 50±5 in/lb (5.64±.56 N/m).
Page 56: Step 4 - Assemble Optional Keyboard Brackets
95-key keyboard. Use four 10-32x5/8 screws to attach the 60-key keyboard. Note: 95-key keyboard shown. Note Excess keyboard cable length can be looped around the hooks on the bottom of the keyboard mounting plate. VX7 User’s Guide Figure 36 Attach Rear Bracket and Keyboard to VX7 Install Mounting Brackets E-EQ-VX7OGWW-H...
Page 57: Figure 37 Attach Keyboard Assembly To Vx7
Attach the keyboard mounting plate to the side mount brackets using the two adjusting knobs. Adjust the angle of the keyboard by loosening the two adjusting knobs, adjusting the keyboard angle and then tightening the adjusting knobs, E-EQ-VX7OGWW-H Figure 37 Attach Keyboard Assembly to VX7 VX7 User’s Guide...
Page 58: Step 5 - Complete Assembly
UPS Battery Pack, then through the 1” aluminum spacer and into the mounting bracket. Connect all cables to the VX7. Secure the cables with the strain relief cable clamps, ensuring a slack loop remains between the cable clamp and the accessory connector.
Page 59: Completed Assembly
Install Mounting Brackets Completed Assembly Vehicle Mount Bracket Bracket with Integrated Keyboard Mount Figure 39 VX7 in Vehicle Bracket E-EQ-VX7OGWW-H VX7 User’s Guide...
Page 60: Install Stylus Tether And Sleeve
Install Stylus Tether and Sleeve The LXE stylus kit includes the stylus, tether and sleeves. The tether allows the stylus to be mounted to the VX7 and the sleeve provides storage for the stylus when not in use. How To Install Stylus Tether and Sleeves 1.
Page 61: Install/Remove Touchscreen Protective Film
Install Mounting Brackets Install/Remove Touchscreen Protective Film LXE offers a replaceable touchscreen protective film to protect the touchscreen when the VX7 is used in an abrasive environment. How To Install Touchscreen Protective Film 1. Make sure both the touchscreen and protective film are clean and dry before installation.
Page 62: Remote Lxe Keyboard Bracket Assembly
Remote LXE Keyboard Bracket Assembly Equipment Needed: Phillips screwdriver, torque wrench. Place the keyboard face down on a flat, stable surface. Position the bracket on the keyboard base, aligning the four screw holes in the keyboard with the four mounting holes in the bracket flanges. When positioned correctly, the bracket should overlap at the top of the keyboard.
Page 63: Remote Keyboard Mounting Dimensions
Install Mounting Brackets Remote Keyboard Mounting Dimensions The overall space required for the keyboards are: • LXE 95-key keyboard: 5.75” (146.05mm) x 13.40” (340.40mm) • LXE 60-key keyboard: 4.40” (111.50mm) x 11.90” (302.00mm) E-EQ-VX7OGWW-H Figure 44 Remote Keyboard - Mounting Dimensions 1.
Page 64: Ups Battery Pack Remote Mount
The optional UPS battery pack must be mounted remotely when using the RAM mount system or a U-bracket designed for a previous model LXE computer. The remote mount can also be used with the VX7 U-bracket assembly if it is not convenient to mount the UPS battery pack to the U- bracket.
Page 65: Connect Keyboard
Connect Keyboard Connect Keyboard LXE Keyboard The VX7 has an external 9-pin connector for the keyboard. All LXE keyboards are connected in a similar fashion. The keyboard is attached to the connector labeled “KEYBOARD”. The keyboard receives power from the VX7.
Page 66: Ps/2 Keyboard And Mouse
5. Attach a PS/2 keyboard and/or PS/2 mouse to the appropriately labeled PS/2 connector on the dongle cable. 6. Turn the VX7 on. Note: The PS/2 keyboard and mouse cannot be hot swapped. The VX7 must be turned off to connect or disconnect PS/2 devices. VX7 User’s Guide Figure 48 VX7 PS/2 Keyboard/Mouse Dongle Cable...
Page 67: Connect Antenna
External Antenna Note: VX7’s are equipped with a radio and require an antenna. Some VX7’s may be equipped with a dual antenna option. For these VX7’s, an external antenna must be connected to each antenna connector.
Page 68: Internal Antenna
9±1 inch pounds force (1.016±.11 N m). The screws must be fastened to 9 inch pounds each. The screws require a Phillips size 1 driver head. VX7 User’s Guide Figure 50 Internal Antenna Cables Connect Antenna...
Page 69: Connect Serial Barcode Scanner
Use of a shielded cable is required to maintain FCC and CISPR22 emissions compliance. Power off the VX7 before connecting the scanner cable to the VX7. Seat the connector firmly over the pins and turn the thumbscrews in a clockwise direction.
Page 70: Figure 52 Vx7 With Generic Barcode Scanner Attached
When you have finished using the scanner, remove it from the VX7 and store the scanner in a closed container or bag. Figure 52 VX7 with Generic Barcode Scanner Attached VX7 User’s Guide 1. Good Scan LED (or equivalent) 2. Trigger 3.
Page 71: Connect Serial Printer Or Pc
Pin 9 of COM3 (labeled “COM2/3”) is configured to provide RI. To change Pin 9 the port, please refer to the “VX7 Reference Guide”. The printer or PC cable requires a nine-pin D-shell female connector for the VX7. The printer or PC cable is attached to the connector labeled “COM2/3”.
Page 72: Ethernet And Usb Ports
An Ethernet port and different types of external USB ports are available via a dongle cable attached to the port labeled “ETHERNET/USB”, located on the bottom of the VX7. Please refer to th illustrations below for the different USB connectors available via dongle cable.
Page 73: Usb Mouse
To remove the Ethernet cable, press the release tab on the cable end. USB Mouse The USB port may be used to connect a USB mouse to the VX7, however the mouse pointer may not always be visible. Please see “Touchscreen and Mouse” later in this manual for more details.
Page 74: Connect External Headset
The audio jack accepts a headset with a 2.5mm plug, such as a mono headset with microphone or a stereo headset. Please refer to the VX7 Reference Guide for information on configuring the audio port for a mono headset with microphone or a stereo headset.
Page 75: Connect Power Cable And Optional Ups Battery Pack
- or - to an AC adapter. (See the following section titled “External Power Supply”.). Several possibilities are available for routing the vehicle power to the VX7. See the following section titled “Vehicle 12-80VDC Direct Connection” for details. All plugs and receptacles are keyed and care must be used when connecting the cables.
Page 76: External Power Supply, Optional
External Power Supply, Optional The LXE-approved AC Power Adapter is only intended for use in a 25ºC (77ºF) maximum ambient temperature environment. In North America, this unit is intended for use with a UL Listed ITE power supply with output rated 12 – 80 VDC, minimum 75W. Outside North America, this unit is intended for use with an IEC certified ITE power supply with output rated 12 –...
Page 77: Vehicle 12-80Vdc Power Connection
Note: Correct electrical polarity is required for safe and proper installation. Connecting the cable to the VX7 with the polarity reversed will cause the VX7’s fuse to be blown. See the E-EQ-VX7OGWW-H For proper and safe installation, the input power cable must be connected to a fused circuit on the vehicle.
Page 78: Figure 64 Vehicle Connection Wiring Color Codes
“Vehicle Connection Wiring Color Codes” for additional wire color-coding specifics. How To: Connect Vehicle 12-80VDC Connection The VX7 must be turned off and the power cable must be UNPLUGGED from the VX7. While observing the fuse requirements specified above, connect the power cable as close as possible to the actual battery terminals of the vehicle.
Page 79: Figure 65 Direct Connection (No Ups Battery Pack)
Connect the power cable to the vehicle’s electrical system as described in “Connect Vehicle 12-80VDC Connection”. Connect the power cable to the VX7 by aligning the water-tight connector pins to the power connector on the bottom of the VX7; push down on the water-tight connector and twist it to fasten securely.
Page 80: Figure 66 Integrated Mount Ups Battery Pack Connection
Connect the output cable (labeled “To Computer”) from the UPS battery pack to the power connector on the bottom of the VX7 by aligning the water-tight connector to the power connector; push down on the water-tight connector and twist it to fasten securely.
Page 81: Figure 67 Remote Mount Ups Battery Pack Connection
Vehicle 12-80VDC Power Connection How To: Connect VX7 to a Remotely Mounted UPS Battery Pack Figure 67 Remote Mount UPS Battery Pack Connection Connect the power cable to the vehicle’s electrical system as described in “Connect Vehicle 12-80VDC Connection”. Connect the power cable to the UPS battery pack by aligning the water-tight connector pins to the input connector (labeled “From Vehicle”);...
Page 82 Connect the output end of the extension cable to the power connector on the bottom of the VX7 by aligning the water-tight connector to the power connector; push down on the water-tight connector and twist it to fasten securely.
Page 83: Power Adapter Cable
LXE offers an adapter cable (part no. 9000A077CBLPWRADPTR) to adapt certain VX1, VX2 or VX4 DC power supplies to the VX7. Please read and follow all cautions below to determine if your present power supply can be used with the VX7.
Page 84: Fuse Replacement For The Vx7
Fuse Replacement for the VX7 The VX7 uses a 100V, 10A time delay (slow blow), high current interrupting rating fuse that is externally accessible and user replaceable. Should it need replacement, replace with same size, rating and type of fuse – Littlefuse 0234010 or Optifuse MSC-10A (5x20mm).
Page 85: Strain Relief Cable Clamps
3. Using a Phillips screwdriver and the screw that was removed, refasten the clamp holding the cable to the VX7. Do not stretch the cable. Leave enough slack in the cable to allow it to be connected and disconnected easily when needed.
Page 86 Strain Relief Cable Clamps VX7 User’s Guide E-EQ-VX7OGWW-H...
Page 87: Operation
Connect the VX7 to a power source, either AC or Vehicle. The power (on/off) button is located on the front of the VX7. The switch is sealed by a rubber membrane. The Status LED on the LXE VX7 is illuminated when the power is on: •...
Page 88: Keyboard Backlight
Keyboard Backlight LXE keyboards feature LEDs that illuminate the individual keys. 95 Key Keyboard The backlight is manually controlled using the “backlight” key in the upper right hand corner of the keyboard. Pressing the backlight key cycles the backlight through the levels of backlight intensity: •...
Page 89: Display And Touchscreen
Some VX7’s provide the option to adjust the screen resolution. Please refer to the “VX7 Reference Guide” for more details. The color TFT display is an active source of light. The VX7 display brightness can be adjusted via the brightness control keys located on the VX7 control panel. Pressing the brightness up button increases the display brightness incrementally until maximum brightness is achieved.
Page 90: Calibrating The Touchscreen
95-key keyboard pointer or external mouse is moved or clicked. Please see “USB Mouse” earlier in this manual for more details. • When a USB mouse is first attached to the VX7, the mouse pointer may not be visible. However, moving or clicking the mouse causes the pointer to appear. •...
Page 91: Adjust Speaker Volume
Windows CE Control Panel. The volume control adjusts the built in speaker’s volume. Note: The <F8> and <F9> keys on the 60-key LXE keyboard have no function as Windows CE controls the sound volume. Microsoft Windows CE Event Sounds The VX7 includes a customized sound scheme.
Page 92: Laser Barcode Scanner Warnings
Do not pour, spray, or spill any liquid on the scanner. The Barcode Scanner contains the circuitry, scanning motor and laser. Handle with appropriate care. Enter Data You can enter data into the VX7 through several different methods: • The tethered scanner connected to the COM1 serial port provides barcode data entry •...
Page 93: Keyboard Entry
The keyboard is used to manually input data that is not collected otherwise. Almost any function that a full sized computer keyboard can provide is duplicated on the LXE keyboard but it may take a few more keystrokes to accomplish a keyed task.
Page 94: Tethered Barcode Scanner
Tethered Barcode Scanner The following section is directed toward a generic tethered scanner connected to the COM1 serial port on the VX7. Aiming the Barcode Scanner Aim the scanner away from you, direct it at the barcode and press the trigger to scan.
Page 95: Bluetooth Scanners
Only LXE Bluetooth scanners and LXE Bluetooth printers are supported by LXE. See Accessories. Voice Data Data is entered into the VX7 by speaking into the headset’s microphone when prompted. Please contact your System Administrator if assistance is needed with the voice software. E-EQ-VX7OGWW-H...
Page 96: Bluetooth Devices
Icon Note: When an active paired device, not the VX7, enters Suspend Mode, is turned Off or leaves the VX7 Bluetooth scan range, the Bluetooth connection between the linked device and the VX7 is lost. There may be audible or visual signals as paired devices disconnect from the VX7.
Page 97: Appendixa Key Maps
Lock Shift Ctrl The key map table that follows lists the commands used for the VX7. Note that since the VX7 uses a Microsoft Windows CE operating system, no DOS Terminal Emulation keypress sequences are provided. Key Map 101-Key Equivalencies There are ten hidden keys on the 95-key keyboard.
Page 98: 60-Key Standard Keypad
CAPS CTRL SHIFT The key map table that follows lists the commands used for the VX7. Note that since the VX7 uses a Microsoft Windows CE operating system, no DOS Terminal Emulation keypress sequences are provided. Key Map 101-Key Equivalencies When using a sequence of keys that includes the <2...
Page 99 Press <Ctrl> then <2 E-EQ-VX7OGWW-H Press These Keys and Then Shift Ctrl > then <F2> to produce Ctrl-Break. Press this key CapsLock Ins/BkSp Up Arrow Down Arrow Right Arrow Left Arrow Ins/BkSp Left Arrow Right Arrow Up Arrow Down Arrow VX7 User’s Guide...
Page 100 To get this key VX7 User’s Guide Press These Keys and Then Shift Ctrl CapsLock 60-key Standard Keypad Press this key E-EQ-VX7OGWW-H...
Page 101 4 (numeric) 5 (numeric) 6 (numeric) 7 (numeric) 8 (numeric) 9 (numeric) 0 (numeric) DOT (numeric) < > / (numeric) / (alpha) - (numeric) - (alpha) E-EQ-VX7OGWW-H Press These Keys and Then Shift Ctrl CapsLock Press this key VX7 User’s Guide...
Page 102 + (numeric) + (alpha) * (numeric) * (alpha) : (colon) ; (semicolon) _ (underscore) , (comma) ‘ (apostrophe) ~ (tilde) “ & VX7 User’s Guide Press These Keys and Then Shift Ctrl CapsLock 60-key Standard Keypad Press this key E-EQ-VX7OGWW-H...
Page 103: Ibm 3270 Keypad Overlay
The 60-key keypad is available with an IBM 3270 overlay designed to allow the user to enter terminal emulator commands when running LXE’s RFTerm™ program. When running this program please refer to the following reference guide for equivalent keys and keypress sequences: •...
Page 104 60-key Standard Keypad VX7 User’s Guide E-EQ-VX7OGWW-H...
