VX6 User's Guide
Copyright © September 2008 by LXE Inc.
All Rights Reserved
E-EQ-VX6OGWW-H

Advertisement

Table of Contents
loading

Summary of Contents for LXE VX6

  • Page 1 VX6 User’s Guide Copyright © September 2008 by LXE Inc. All Rights Reserved E-EQ-VX6OGWW-H...
  • Page 2 Summit Data Communications, Inc. All rights reserved. Symbol, the Symbol logo and Spectrum24 are registered trademarks of Symbol Technologies, Inc. The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by LXE, Inc. is under license.
  • Page 3: Revision Notice

    Appendix B Regulatory Notices and Safety Information Note: A complete revision history is included in Appendix B, “Regulatory Notices and Safety Information”. Revision Notice VX6 User’s Guide Explanation Update approvals for 802.11 a/b/g radio. Remove Summit Declaration of Compliance for consistency.
  • Page 5: Table Of Contents

    The Half-Screen Display ... 9 VX6 Control Panel... 9 Microsoft Windows CE Control Panel... 9 PCMCIA, ATA and SD Slots ... 9 AppLock and the VX6 ... 10 Single Application AppLock ...10 Multi Application AppLock ...10 Using the Touchscreen ...10 Using the Keypad ...11...
  • Page 6 Step 1 - Mount Bottom Mounting Bracket To Vehicle..35 Mounting Dimensions ...35 Step 2 - Connect Rear Bracket to VX6 ... 36 Step 3 - Attach VX6 Assembly To Bottom Mounting Bracket..37 Completed Assembly...39 Install Stylus Tether and Sleeve ...40 Install/Remove Touchscreen Protective Film...41...
  • Page 7 Table of Contents Power Adapter Cable... 59 Fuse Replacement for the VX6 ... 60 Strain Relief Cable Clamps ... 61 PERATION Powering On/Off... 63 Display and Touchscreen... 64 Adjusting Screen Display ...64 Cleaning the Display ...64 Disabling the Touchscreen ...64 Disabling the Touchscreen Heater...64...
  • Page 8 Figure 16 Small and Large Virtual Keyboards ...18 Figure 17 Input Panel Properties...19 Figure 18 Connect Vehicle RAM Mount Bracket to Vehicle...27 Figure 19 VX6 RAM Bracket - Mounting Dimensions (Not To Scale) ...27 Figure 20 RAM Clamp Mount Components...28 Figure 21 Assembled RAM Clamp Mount ...28 Figure 22 RAM Clamp Mount - Mounting Dimensions (Not To Scale) ...29...
  • Page 9 Figure 46 Connect USB Device to Dongle Cable...49 Figure 47 Connect Ethernet Cable to Adapter Cable...49 Figure 48 Connect External Headset ...50 Figure 49 Connect Power Cable to VX6 ...51 Figure 50 Optional Power Configuration ...52 Figure 51 Vehicle Power Connection Cable (Fuse Not Shown)...53 Figure 52 Connecting the Power Cable to the Vehicle ...53...
  • Page 10 Table of Contents VX6 User’s Guide E-EQ-VX6OGWW-H...
  • Page 11: The Vx6 Vehicle Mount Computer

    Microsoft Windows CE icons that the Windows CE operating system supports. The keyboard is illuminated to facilitate use in dimly lit areas. The VX6 provides the power and functionality of a desktop computer in a vehicle mounted unit, with a wide range of options: •...
  • Page 12: Document Conventions

    • Available RAM Mount • Extended temperature version includes touchscreen heater Note: The “VX6 Reference Guide” contains VX6 technical information and advanced functions. Document Conventions This reference guide uses the following document conventions: ALL CAPS Menu|Choice “Quotes” < > ATTENTION...
  • Page 13: Environmental Specifications

    -22°F to 140°F (-30°C to 60°C) [non-condensing] -22°F to 140°F (-30°C to 60°C) [condensing] IP66 per IEC60529 Up to 90% non-condensing at 104°F (40°C) 100% Based on MIL Std 810F 15 kV 32.8 feet (10 meters) Direct line of sight only VX6 User’s Guide...
  • Page 14: Quick Start

    (e.g. antenna and/or barcode scanner) and a power source. Use this guide as you would any other source book -- reading portions to learn about the VX6, and then referring to it when you need more information about a particular subject. This guide takes you through installation and operation of the LXE VX6.
  • Page 15: Troubleshooting

    AppLock is installed and running on the mobile device. AppLock restricts User access to running programs. Changes or modifications require Administrator access. Refer to AppLock in the VX6 Reference Guide for setup and processing information. Tap File | Exit to close the RFTerm application.
  • Page 16: Components

    When the internal antenna option is ordered, the internal antenna is mounted on the inside of the Access Panel Cover. VX6 User’s Guide Figure 1 VX6 Components, Top View Figure 2 VX6 Components, Front View Components 1. Access Panel Cover (See...
  • Page 17: Figure 3 Vx6 Components, Bottom View

    COM1 / SCANNER Note: COM1 is configured with Pin 9 +5V. COM3 is labeled “COM2/3” and is configured with Pin 9 RI. Please see the VX6 Reference Guide for details. E-EQ-VX6OGWW-H CAUTION: For continues protection against risk of fire, IP66 THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.
  • Page 18: Figure 6 Vx6 Access Panel

    Note: The tethered access panel cover is not shown in the illustration above. VX6 User’s Guide CF ATA PCMCIA A PCMCIA B Figure 6 VX6 Access Panel Components 1. SD Memory Card Slot 2. Compact Flash ATA Hard Drive 3. PCMCIA Slots...
  • Page 19: The Half-Screen Display

    PCMCIA, ATA and SD Slots The VX6 has two PCMCIA slots. These slots are intended for use with Type I or II cards, such as LXE’s 802.11 radios. These slots are hot swappable per PCMCIA specifications. The Compact Flash (CF) slot contains the Compact Flash ATA hard drive. This drive contains the Operating System and the Documents and Settings.
  • Page 20: Applock And The Vx6

    AppLock. Multi Application AppLock A checkmark indicates applications currently active or available for Launching by the user. When Keyboard is selected, the VX6 default input method (Input Panel, Transcriber, or custom input method) is activated. Note: If “Keyboard”...
  • Page 21: Using The Keypad

    The previous application continues to run in the background. End-user key presses affect the application in focus only. See the VX6 Reference Guide for AppLock setup instruction. E-EQ-VX6OGWW-H VX6 User’s Guide...
  • Page 22: The Qwerty Keyboard

    The QWERTY Keyboard The VX6 has a QWERTY keyboard, available with a standard overlay, an IBM 3270 overlay or an IBM 5250 overlay. These keyboards have 101 keyboard functions, including a numeric keypad. Please refer to Appendix A, “Key Maps”, for keypress combinations.
  • Page 23: Key Maps

    The hidden keys supported by the VX6 are listed in Appendix A, “Key Maps”. Unused Key Functions There are several key functions on the keyboard that are not used on the VX6. These include: • <2nd> <F3> – The Resume/Suspend function is not used, as the VX6 does not support these power management modes.
  • Page 24: Keyboard Leds

    When CapsLock is off, the LED is dark. Press <2 > then <F1> to toggle CapsLock On and Off. The default value of CapsLock is “Off”. CapsLock after a reboot, please refer to the “VX6 Reference Guide”. VX6 User’s Guide CAPS BKSP ENTER <...
  • Page 25: Secondary Keys Led

    > key followed by the superscripted key. Figure 14 The Secondary Key > state is enabled until another key is pressed. The <2 > key) the Secondary Mode LED is > key is toggled on > keypress. VX6 User’s Guide...
  • Page 26: Control Keys

    <F4> and <F5>keys are not used as the display brightness is adjusted via the buttons on the control panel. The 2 functions of the <F6>, and <F7> keys are not used as the VX6 has TFT LCD screen with no provision for contrast adjustments. The 2 functions of the <F8>...
  • Page 27: General Windows Ce Keyboard Shortcuts

    The QWERTY Keyboard General Windows CE Keyboard Shortcuts Use the keyboard shortcuts in the chart below to navigate with the VX6 keyboard. These are standard keyboard shortcuts for Windows CE applications. Press these keys … CTRL + C CTRL + X...
  • Page 28: Input Panel (Virtual Keyboard)

    <Shift> and <áü> keys can be used in combination for capitalized international characters. Note: When the virtual keyboard is displayed, the physical keyboard is still active. Therefore it is possible to input data from both keyboards. VX6 User’s Guide Figure 16 Small and Large Virtual Keyboards The QWERTY Keyboard E-EQ-VX6OGWW-H...
  • Page 29: Enabling The Input Panel

    The Input Panel is disabled by default. To enable the Input Panel, select Start | Settings | Control Panel |Input Panel icon. Make sure the “Allow applications to change the input panel state” checkbox is checked and warmboot the VX6. E-EQ-VX6OGWW-H Figure 17 Input Panel Properties VX6 User’s Guide...
  • Page 30: Power Supply

    Power Supply Vehicle power input for the VX6 is 12V to 80V DC and is accepted without the need to perform any manual adjustments within the VX6. See the section titled “Installation”, sub-section titled “Vehicle 12-80V DC Direct Connection”. An optional Uninterruptible Power Supply (UPS) battery pack is available for the vehicle power supply connection.
  • Page 31: Getting Help

    LXE Manuals CD or logon information for the ServicePass web pages. You can also get help from LXE by calling the telephone numbers listed on the LXE Manuals CD, in the file titled “Contacting LXE”. This information is also available on the LXE website.
  • Page 32 Power Cables Cable, Input Power, 12 FT, VX5 VX6 VX7 Adapter Cable, VX1 VX2 VX4 Power Cable to VX5 VX6 Power Supplies Power Supply, External, AC, W/US Power Cord VX5 VX6 Power Supply, External, AC, No Power Cord VX5 VX6 VX7...
  • Page 33 (above part is not RoHS compliant) 8310A333SCNRL12D9FLT (above part is not RoHS compliant) 8320A326SCNRPWRXLR8DA9F 8320A326SCNRPWRXLR8DA9F-R 8320A327SCNRPWRXLR12DA9F (above part is not RoHS compliant) 8320A332SCNRX8D9FLT (above part is not RoHS compliant) 8320A333SCNRX12D9FLT (above part is not RoHS compliant) 8510A326SCNRFZYDA9F 8510A326SCNRFZYDA9F-R 8520A326SCNRERDA9F-R VX6 User’s Guide...
  • Page 34 Bluetooth Scanner and Accessories LXE Bluetooth module with laser ring scanner, battery, two hand/wrist straps (large and small) LXE Bluetooth module with 1D/2D imager ring scanner, battery, two hand/wrist straps (large and small) Li-Ion Spare Battery for LXE Bluetooth Ring Scanner...
  • Page 35: Installation

    (5.64±.56 N/m). Note: Torquing tool is not supplied by LXE. Bolts, washers, and wrench needed when attaching the bottom mounting bracket to the vehicle are not supplied by LXE. Several types of mounting systems are provided for the VX6: •...
  • Page 36: Ram Mount System

    You will need a torquing tool capable of torquing to 50 inch pounds (5.64±.56 N/m). Torque all screws and bolts according to the following table: For these screws and bolts… 1/4 bolts VX6 User’s Guide Install Mounting Brackets The RAM mounting assembly consists of the following parts:...
  • Page 37: Procedure

    Determine the position for mounting the RAM ball base. Be sure to position the RAM ball base to allow access to the switches and ports on the bottom of the VX6. Attach the RAM ball base to the vehicle mounting surface using four 1/4 bolts (or equivalent) fasteners.
  • Page 38: Step 1B - Mount Vehicle Ram Clamp Mount

    Be sure to position the RAM clamp mount to allow access to the switches and ports on the bottom of the VX6. Position the upper clamp piece with ball (A) on the beam. Place the bolts (B) through the holes in the upper clamp piece.
  • Page 39: Mounting Dimensions

    Install Mounting Brackets Mounting Dimensions Figure 22 RAM Clamp Mount - Mounting Dimensions (Not To Scale) E-EQ-VX6OGWW-H 2.56” (65.02 mm) 1.84” (46.74 mm) Varies depending on bolt length VX6 User’s Guide...
  • Page 40: Step 2 - Attach Ram Mount Ball To The Vx6

    Place the VX6 face down on a stable surface. Position the RAM ball bracket on the rear of the VX6, aligning the curved edge on the RAM mount bracket with the curved edge on the VX6. Attach with four 1/4-20x5/8 bolts, using one flat washer and one locking washer per bolt.
  • Page 41: Step 2 - Attach Vx6 Assembly To Ram Mount

    Slip the RAM arm over the ball on the vehicle RAM ball bracket. Insert the ball of the RAM mount bracket into the RAM arm. Adjust the VX6 to the desired position and tighten the knob on the RAM arm using the supplied RAM wrench.
  • Page 42: Completed Assembly

    Install Mounting Brackets Completed Assembly Figure 25 Completed RAM Mount Assembly Note: RAM ball base shown. VX6 User’s Guide E-EQ-VX6OGWW-H...
  • Page 43: U-Bracket Mount System

    The viewing angle can be adjusted through a wide range to provide the best viewing angle. E-EQ-VX6OGWW-H This bracket is mounted to the vehicle. The VX6 can be mounted to the bottom mounting bracket. The UPS battery pack may be mounted to the bottom mounting bracket.
  • Page 44: Torque Measurements

    You will need a torquing tool capable of torquing to 50 inch pounds (5.64±.56 N/m). Torque all screws and bolts according to the following table: For these screws and bolts… 1/4 bolts VX6 User’s Guide Install Mounting Brackets Torque to 50.0±5 in/lb (5.64±.56 N/m)
  • Page 45: Procedure

    IMPORTANT: Mount to the most rigid surface available. After the bottom bracket has been attached to a rigid surface, you are ready to assemble the VX6 bracket configuration. Mounting Dimensions Figure 28 VX6 Bracket - Mounting Dimensions (Not To Scale)
  • Page 46: Step 2 - Connect Rear Bracket To Vx6

    Place the VX6 face down on a stable surface. Align the rear bracket with the holes on the back of the VX6. Attach with four 1/4- 20x5/8 bolts, using one flat washer and one locking washer per bolt. Place the locking washer on the bolt before the flat washer.
  • Page 47: Step 3 - Attach Vx6 Assembly To Bottom Mounting Bracket

    Loosely tighten each bolt as it is inserted. Important: Loosen the hex bolts on both sides to adjust the viewing angle of the mounted VX6. Torque the hex bolts to 50±5 in lbf (5.64±.56 N m). Note: Test the torque on the bolts frequently during operation and re-tighten if necessary to 50±5 in lbf (5.64±.56 N m).
  • Page 48: Figure 31 Integrated Ups Battery Pack Mount

    UPS Battery Pack, then through the 1” aluminum spacer and into the mounting bracket. Connect all cables to the VX6. Secure the cables with the strain relief cable clamps, ensuring a slack loop remains between the cable clamp and the accessory connector.
  • Page 49: Completed Assembly

    Install Mounting Brackets Completed Assembly Figure 32 VX6 in Vehicle Bracket E-EQ-VX6OGWW-H VX6 User’s Guide...
  • Page 50: Install Stylus Tether And Sleeve

    Install Stylus Tether and Sleeve The LXE stylus kit includes the stylus, tether and sleeves. The tether allows the stylus to be mounted to the VX6 and the sleeve provides storage for the stylus when not in use. How To Install Stylus Tether and Sleeves 1.
  • Page 51: Install/Remove Touchscreen Protective Film

    Install Mounting Brackets Install/Remove Touchscreen Protective Film LXE offers a replaceable touchscreen protective film to protect the touchscreen when the VX6 is used in an abrasive environment. How To Install Touchscreen Protective Film 1. Make sure both the touchscreen and protective film are clean and dry before installation.
  • Page 52: Ups Battery Pack Remote Mount

    The optional UPS battery pack must be mounted remotely when using the RAM mount system or a U-bracket designed for a previous model LXE computer. The remote mount can also be used with the VX6 U-bracket assembly if it is not convenient to mount the UPS battery pack to the U- bracket.
  • Page 53: Connect Antenna

    External Antenna Note: VX6’s are equipped with a radio and require an antenna. Some VX6’s may be equipped with a dual antenna option. For these VX6’s, an external antenna must be connected to each antenna connector.
  • Page 54: Internal Antenna

    9±1 inch pounds force (1.016±.11 N m). The screws must be fastened to 9 inch pounds each. The screws require a Phillips size 1 driver head. VX6 User’s Guide Figure 39 Internal Antenna Cables Connect Antenna...
  • Page 55: Connect Serial Barcode Scanner

    Use of a shielded cable is required to maintain FCC and CISPR22 emissions compliance. Power off the VX6 before connecting the scanner cable to the VX6. Seat the connector firmly over the pins and turn the thumbscrews in a clockwise direction.
  • Page 56: Figure 41 Vx6 With Generic Barcode Scanner Attached

    When you have finished using the scanner, remove it from the VX6 and store the scanner in a closed container or bag. Figure 41 VX6 with Generic Barcode Scanner Attached VX6 User’s Guide 1. Good Scan LED (or equivalent) 2. Trigger 3.
  • Page 57: Connect Serial Printer Or Pc

    Pin 9 of COM3 (labeled “COM2/3”) is configured to provide RI. To change Pin 9 of the port, please refer to the “VX6 Reference Guide”. The printer or PC cable requires a nine-pin D-shell female connector for the VX6. The printer or PC cable is attached to the connector labeled “COM2/3”.
  • Page 58: Ethernet And Usb Ports

    An Ethernet port and different types of external USB ports are available via a dongle cable attached to the port labeled “ETHERNET/USB”, located on the bottom of the VX6. Please refer to the illustrations below for the connectors available via dongle cable.
  • Page 59: Usb Mouse

    To remove the Ethernet cable, press the release tab on the cable end. USB Mouse The USB port may be used to connect a USB mouse to the VX6, however the mouse pointer may not always be visible. Please see “Touchscreen and USB Mouse” later in this manual for more details.
  • Page 60: Connect External Headset

    The audio jack accepts a headset with a 2.5mm plug, such as a mono headset with microphone or a stereo headset. Please refer to the VX6 Reference Guide for information on configuring the audio port for a mono headset with microphone or a stereo headset.
  • Page 61: Connect Power Cable And Optional Ups Battery Pack

    - or - to an AC adapter. (See the following section titled “External Power Supply”.). Several possibilities are available for routing the vehicle power to the VX6. See the following section titled “Vehicle 12-80VDC Direct Connection” for details. All plugs and receptacles are keyed and care must be used when connecting the cables.
  • Page 62: External Power Supply, Optional

    External Power Supply, Optional The LXE-approved AC Power Adapter is only intended for use in a 25ºC (77ºF) maximum ambient temperature environment. In North America, this unit is intended for use with a UL Listed ITE power supply with output rated 12 – 80 VDC, minimum 75W. Outside North America, this unit is intended for use with an IEC certified ITE power supply with output rated 12 –...
  • Page 63: Vehicle 12-80Vdc Power Connection

    Note: Correct electrical polarity is required for safe and proper installation. Connecting the cable to the VX6 with the polarity reversed will cause the VX6’s fuse to be blown. See the E-EQ-VX6OGWW-H For proper and safe installation, the input power cable must be connected to a fused circuit on the vehicle.
  • Page 64: Figure 53 Vehicle Connection Wiring Color Codes

    “Vehicle Connection Wiring Color Codes” for additional wire color-coding specifics. How To: Connect Vehicle 12-80VDC Connection The VX6 must be turned off and the power cable must be UNPLUGGED from the VX6. While observing the fuse requirements specified above, connect the power cable as close as possible to the actual battery terminals of the vehicle.
  • Page 65: Figure 54 Direct Connection (No Ups Battery Pack)

    Connect the power cable to the vehicle’s electrical system as described in “Connect Vehicle 12-80VDC Connection”. Connect the power cable to the VX6 by aligning the water-tight connector pins to the power connector on the bottom of the VX6; push down on the water-tight connector and twist it to fasten securely.
  • Page 66: Figure 55 Integrated Mount Ups Battery Pack Connection

    Connect the output cable (labeled “To Computer”) from the UPS battery pack to the power connector on the bottom of the VX6 by aligning the water-tight connector to the power connector; push down on the water-tight connector and twist it to fasten securely.
  • Page 67: Figure 56 Remote Mount Ups Battery Pack Connection

    Vehicle 12-80VDC Power Connection How To: Connect VX6 to a Remotely Mounted UPS Battery Pack Figure 56 Remote Mount UPS Battery Pack Connection Connect the power cable to the vehicle’s electrical system as described in “Connect Vehicle 12-80VDC Connection”. Connect the power cable to the UPS battery pack by aligning the water-tight connector pins to the input connector (labeled “From Vehicle”);...
  • Page 68 Connect the output end of the extension cable to the power connector on the bottom of the VX6 by aligning the water-tight connector to the power connector; push down on the water-tight connector and twist it to fasten securely.
  • Page 69: Power Adapter Cable

    LXE offers an adapter cable (part no. 9000A077CBLPWRADPTR) to adapt certain VX1, VX2 or VX4 DC power supplies to the VX6. Please read and follow all cautions below to determine if your present power supply can be used with the VX6.
  • Page 70: Fuse Replacement For The Vx6

    Fuse Replacement for the VX6 The VX6 uses a 100V, 10A time delay (slow blow), high current interrupting rating fuse that is externally accessible and user replaceable. Should it need replacement, replace with same size, rating and type of fuse – Littlefuse 0234010 or Optifuse MSC-10A (5x20mm).
  • Page 71: Strain Relief Cable Clamps

    3. Using a Phillips screwdriver and the screw that was removed, refasten the clamp holding the cable to the VX6. Do not stretch the cable. Leave enough slack in the cable to allow it to be connected and disconnected easily when needed.
  • Page 72 Strain Relief Cable Clamps VX6 User’s Guide E-EQ-VX6OGWW-H...
  • Page 73: Operation

    Connect the VX6 to a power source, either AC or Vehicle. The power (on/off) button is located on the front of the VX6. The switch is sealed by a rubber membrane. The Status LED on the LXE VX6 is illuminated when the power is on: •...
  • Page 74: Display And Touchscreen

    Adjusting Screen Display The color TFT display is an active source of light. The VX6 display brightness can be adjusted via the brightness control keys located on the VX6 control panel. Pressing the brightness up button increases the display brightness incrementally until maximum brightness is achieved.
  • Page 75: Calibrating The Touchscreen

    95-key keyboard pointer or external mouse is moved or clicked. Please see “USB Mouse” earlier in this manual for more details. • When a USB mouse is first attached to the VX6, the mouse pointer may not be visible. However, moving or clicking the mouse causes the pointer to appear. •...
  • Page 76: Adjust Speaker Volume

    Windows CE Control Panel. The volume control adjusts the built in speaker’s volume. Note: The <F8> and <F9> keys on the VX6 keyboard have no function as Windows CE controls the sound volume. Microsoft Windows CE Event Sounds The VX6 includes a customized sound scheme.
  • Page 77: Laser Barcode Scanner Warnings

    Do not pour, spray, or spill any liquid on the scanner. The Barcode Scanner contains the circuitry, scanning motor and laser. Handle with appropriate care. Enter Data You can enter data into the VX6 through several different methods: • The tethered scanner connected to the COM1 serial port provides barcode data entry •...
  • Page 78: Keyboard Entry

    The keyboard is used to manually input data that is not collected otherwise. Almost any function that a full sized computer keyboard can provide is duplicated on the VX6 keyboard but it may take a few more keystrokes to accomplish a keyed task.
  • Page 79: Tethered Scanners

    Tethered Scanners The following section is directed toward a generic tethered scanner connected to the COM1 serial port on the VX6. Aiming the Barcode Scanner Aim the scanner away from you, direct it at the barcode and press the trigger to scan.
  • Page 80: Bluetooth Scanners

    Only LXE Bluetooth scanners and LXE Bluetooth printers are supported by LXE. See Accessories. Voice Data Data is entered into the VX6 by speaking into the headset’s microphone when prompted. Please contact your System Administrator if assistance is needed with the voice software. VX6 User’s Guide...
  • Page 81: Bluetooth Devices

    Icon Note: When an active paired device, not the VX6, enters Suspend Mode, is turned Off or leaves the VX6 Bluetooth scan range, the Bluetooth connection between the linked device and the VX6 is lost. There may be audible or visual signals as paired devices disconnect from the VX6.
  • Page 82 Bluetooth Devices VX6 User’s Guide E-EQ-VX6OGWW-H...
  • Page 83: Appendixa Key Maps

    The VX6 keyboard does not have a NumLock indicator. NumLock is always on. When the VX6 boots, the default condition of Caps (or CapsLock) is Off. The Caps (or CapsLock) condition can be set toggled with a <2nd>+<F1> key sequence. The CAPS LED is illuminated when CapsLock is On.
  • Page 84 Right Alt Right Ctrl ScrollLock NumLock Press <Ctrl> then <2 The NumLock toggle has no effect on the VX6 as NumLock is always On. VX6 User’s Guide Press These Keys and Then Shift Ctrl > then <F2> to produce Ctrl-Break.
  • Page 85 The VX6 Keypad To get this key E-EQ-VX6OGWW-H Press These Keys and Then Shift Ctrl CapsLock Press this key VX6 User’s Guide...
  • Page 86 - (alpha) + (numeric) + (alpha) * (numeric) * (alpha) : (colon) ; (semicolon) _ (underscore) , (comma) ‘ (apostrophe) ~ (tilde) VX6 User’s Guide Press These Keys and Then Shift Ctrl CapsLock The VX6 Keypad Press this key E-EQ-VX6OGWW-H...
  • Page 87 The VX6 Keypad To get this key “ & E-EQ-VX6OGWW-H Press These Keys and Then Shift Ctrl CapsLock Press this key VX6 User’s Guide...
  • Page 88: Ibm 3270 Keypad Overlay

    The 60-key keypad is available with an IBM 3270 overlay designed to allow the user to enter terminal emulator commands when running LXE’s RFTerm™ program. When running this program please refer to the following reference guide for equivalent keys and keypress sequences: •...
  • Page 89: Appendixb Regulatory Notices And Safety Information

    Warning: Changes or modifications to this device not expressly approved by LXE, Inc., could void the user’s authority to operate this equipment.
  • Page 90: Approvals

    A label on the exterior of the device should resemble one of the labels shown below (the label contains the LXE part number of the installed radio card). The labels shown below and affixed to the device, identify where the device may be used and where its use is restricted. Use of a device is prohibited in countries not listed below or otherwise identified by the label.
  • Page 91: Lithium Battery Safety Statement

    Pila de litio adentro. Peligro de explosión si la pila se reemplaza incorrectamente. Reemplace solamente con el mismo tipo o equivalente recomendado por el fabricante. (ES) Oppassen: Bevat Lithium-batterij. Incorrrecte plaatsing van batterij kan leiden tot explosiegevaar. Alleen vervangen door hetzelfde of door fabrikant aanbevolen gelijkwaardig type. (NL) E-EQ-VX6OGWW-H VX6 User’s Guide...
  • Page 92 Lithium Battery Safety Statement (GR) (JP) Dikkat: (TR) Legend: Chinese Danish Dutch English Finnish French German Greek VX6 User’s Guide (KR) (CN) Italian Japanese Korean Norwegian Portuguese Spanish Swedish Turkish Approvals E-EQ-VX6OGWW-H...
  • Page 93 Approvals A/C Power Supply Safety Statement – VX6 Output Rated 12 – 80 VDC, Minimum 75W. The LXE-approved AC Power Adapter is only intended for use in a 25ºC (77ºF) maximum ambient temperature environment. Optional A/C Power Supply: Outside North America, this unit is intended for use with an IEC certified ITE power supply with output rated as stated at the top of this page.
  • Page 94: Vehicle Power Supply Connection Safety Statement

    Danish – DK; English – US; Finnish – FI; French- - FR; German – DE; Greek – GR; Italian – IT; Norwegian – NO; Portuguese – PT; Spanish – ES; Swedish – SE; Turkish – TR. Updated 02/10/2004 VX6 User’s Guide Approvals E-EQ-VX6OGWW-H...
  • Page 95: Revision History

    Safety Information E-EQ-VX6OGWW-H Explanation Updated LXE logo and date. Updated accessories listing. Added internal antenna to VX6 option listing. Added note on internal antenna. Revised to include “External Antenna”, “Remote Vehicle Antenna Mount” and “internal Antenna” sections. Added new section.
  • Page 96 Updated specific references to Microsoft Windows CE .NET to generic references to Microsoft Windows CE to reflect the availability of either Windows CE .NET or CE 5.0 operating systems on the VX6. Added Bluetooth information and instruction. Revised Accessories listing.
  • Page 97 Revision History Revision G: May 2008 Section Accessories NumLock and the VX6 Appendix A – Key maps Revision H: September 2008 Section Appendix B Regulatory Notices and Safety Information E-EQ-VX6OGWW-H Explanation Revised accessories listing. Revised section. Revised NumLock information. Explanation Update approvals for 802.11 a/b/g radio.
  • Page 98 Revision History VX6 User’s Guide E-EQ-VX6OGWW-H...
  • Page 99: Index

    Barcode scanner data entry...74 Battery, Backup, Lithium ...20 Beam, Long Range Scanner ...75 Bluetooth printers and scanners...78 Bottom Mounting Bracket ...27, 28, 35, 43 and the VX6 ...38 Bracket and VX6...42 Footprint Dimensions...36 How To ...27, 28, 35, 43 Mounting Positions ...33 Tools Required...25...
  • Page 100 Laser Aperture ...48 Laser barcode scanner warnings...73 LED indicators...14 LEDs 2nd ...15 Caps-Lock, CAPS ...14 Secondary Keys ...15 VX6 User’s Guide Manuals ...21 Maximum overcurrent protection ...54 Measurement,Torque...26, 34 Mounting Bracket and VX6...42 Mounting Dimensions ...36 Mounting Positions...33 Mouse 95-key keyboard ...70...
  • Page 101 Adapting VX1/2/4 Power Supply ...61 External Power Supply ...54 View Display ...69 Voice data...77 Volume Control Windows CE Icon...72 VX6 Reference Guide ...2 Warning Laser light ...73 Windows CE Control Panel ...9 Help Screens ...9 Power Management ...72 Windows CE online Help...9 Wiring Color Codes...56...
  • Page 102 Index VX6 User’s Guide E-EQ-VX6OGWW-H...
