Cisco Client Configuration

Cisco Client Configuration
Prerequisites
• Network SSID or ESSID number of the Access Point
• WEP or LEAP Authentication Protocol Keys

Aironet Client Utility (ACU)

Access:
Note:
Note:
Profiles Tab
Firmware Tab
Status Tab
Statistics Tab
Survey Tab
E-EQ-MX3RFIDRG-A
Start | Aironet Client Utility or ACU Icon on Desktop
When making changes to profile parameters, the mobile device should be warmbooted
afterwards.

Figure 4-18 Cisco Aironet Client Utility

To configure WPA, please see "Cisco Configuration", later in this chapter.
See the following "Profiles Tab" section for default profile parameter
settings.
Displays the current firmware version and allows you to load new
firmware. Tap the Browse button to locate the new firmware file.
Immediately runs status on : signal strength and signal quality.
Select the Receive Stats or Transmit Stats. The data is displayed on the
screen.
Immediately runs signal strength and quality and link speed. An option
is available to Setup parameters for Active Mode reporting.
MX3-RFID Reference Guide
