ENSIM SENSORS ELP Operating Manual page 4

Technical Specifications :
ELP 31 , ELP 33
Float Material
Wetted Parts Materi
Float Type
Working Temperature
Mechanical Connection
Max. Pressure
Min. Density
Electrical Connection
Number of Float
Number of Contact
Contact Current
Max. Contact Power
Max.Switching Voltage
ELP 31L , ELP 33L
Float Material
Wetted Parts Materi
Float Type
Working Temperature
Mechanical Connection
Max. Pressure
Min. Density
Electrical Connection
Number of Float
Number of Contact
Contact Current
Max. Contact Power
Max.Switching Voltage
97.5
10 20
59.5
7
2
1/2 NPT
ELP 31
PP
PP
P10
(-) 20 °C / (+) 80 °C
1/2" NPT
4 bar
0.75 (g/cm³)
Cable
1 Std.
1 x SPST - NO
1 A
10 W / VA
200 VDC / 140 VAC
107.5
10 20 79.5
7
2
1/2 NPT
ELP 31L
PP
PP
P10
(-) 20 °C / (+) 80 °C
1/2" NPT
4 bar
0.65 (g/cm³)
Cable
1 Std.
1 x SPST - NO
1 A
10 W / VA
200 VDC / 140 VAC
All dimensions are given in mm.
Closed
ELP 33
PVDF
PVDF
P10
(-) 30 °C / (+) 120 °C
1/2" NPT
2 bar
0.90 (g/cm³)
Cable
1 Std.
1 x SPST - NO
1 A
10 W / VA
200 VDC / 140 VAC
ELP 33L
PVDF
PVDF
P10
(-) 30 °C / (+) 120 °C
1/2" NPT
2 bar
0.75 (g/cm³)
Cable
1 Std.
1 x SPST - NO
1 A
10 W / VA
200 VDC / 140 VAC
4
Black
Blue
Single Contact NO
Closed
Black
Blue
Single Contact NO
