2.6. Order Form
MODEL ELP
1
Vertical Type, Ø 18 mm , L= 20 mm, Open at Bottom.....02a
Vertical Type, Ø 18 mm , L= 20 mm, Closed at Bottom..02b
Vertical Type, Ø 19 mm , L= 31 mm, Open at Bottom.....03a
Vertical Type, Ø 19 mm , L= 31 mm, Closed at Bottom..03b
Vertical Type, Ø 24 mm , L= 41 mm, Open at Bottom.....04a
Vertical Type, Ø 24 mm , L= 41 mm, Closed at Bottom...04b
Vertical Type, Ø 24 mm , L= 85 mm, Open at Bottom......08a
Vertical Type, Ø 24 mm , L= 85 mm, Closed at Bottom..08b
Vertical Type, Ø 20 mm , L= 44 mm, NO............................11
CERTIFICATE
2
None..........................................................................0
CONNECTION
3
2 2
1/8 BSP......0001
1/2 BSP......0004
3/4 BSP......0005
1 BSP........0006
1/2 NPT......0203
4
MATERIAL
PP..........................................................................062
Delrin....................................................................063
5
CABLE LENGTH
30 cm (Std.)...........................................................001
6
CONTACT
NO Reed Relay.......................................................06
NC Reed Relay.......................................................07
ELECTRICAL CONNECTION
7
PVC Cable (Max. 60 °C)........................................80
PVC Cable (Max. 105 °C)......................................81
HOUSING
8
None.........................................................................0
Plastic , B05p........................................................002
9
OPTIONAL
None................................................................../ 0
E-GSM Device........................................./ E-GSM
SAMPLE
Order Form :
Please consider sample models when coding !
M8 x 1.25 mm²................0300
M8 x 1.55 mm²................0301
M10 x 1.25 mm²..............0302
M16 x 1,5 mm²................0306
ELP 31 - 0 - 0004 - 062 - 001 - 06 - 0 - 80 / 0
Plastic Level Switch ELP 31, 30 cm With Cable , NO Contact , PP
Horizontal Type, L= 80 mm, 1/2 NPT , PP.................31
Horizontal Type, L= 80 mm, 1/2 NPT , PVDF............33
Horizontal Type, L= 52 mm, M16 , PP.........................32
Horizontal Type, L= 52 mm, 1 BSP, PP....................32s
Horizontal Type, L= 40 mm, M10 , PP.........................26
Horizontal Type, L= 152 mm, 1/2 BSP , Delrin..........81
Horizontal Type, L= 152 mm, 1/2 BSP , PVDF..........82
Horizontal Type, L= 58 mm, 3/4 BSP , PP...............81p
Horizontal Type, L= 100 mm, 1/2 NPT , PP.............31L
Horizontal Type, L= 72 mm, M16 , PP.......................32L
Horizontal Type, L= 72 mm, 1 BSP, PP..................32sL
Horizontal Type, L= 100 mm, 1/2 NPT , PVDF........33L
Horizontal Type, L= 100 mm, M16 , PP....................34L
(EN10204-3-1) Material Certification ............................ 1
Special.............................................................................x
PVDF............................................................................064
Special.............................................................................x
Special.............................................................................x
NO / NC Reed Relay.....................................................08
Special.............................................................................x
Silicon Cable (Max.105 °C).........................................82
Polyamide Big Socket 01..........................................50
Special.............................................................................x
Aluminium , B22x........................................................750
Special.............................................................................x
Level Control Device......................................./ SK-P2
Level Relay , 24 VDC - 5 A............................/ ESR 24
Level Relay , 220 VAC - 8 A...................../ ESR 220
Special............................................................................/ x
10
