7.4

Performing measurements

7.4.1

Measurement with manual sample supply

Carry out a measurement with manual sample supply as follows:
1. Insert the sample intake cannula and the purging cannula into the sample.
2. Using the menu command Method / New create a new method or load an existing
method.
To do so open via the menu command Method / Load the database window Method
selection, highlight the desired method and confirm the selection by clicking the button
[OK].
3. In the window System state select the manual sample supply by clicking the button
[manual].
 This is followed by the initialization of the analyzer.
4. In the window System state check the following entries:
−
Visual bank - OK
− where applicable, CLD - OK
−
Gas flow - OK
− Temperature - OK
Note:
If one of the entries is incorrect (shown in red), carry out a fault finding exercise in ac-
cordance with the notes in section "Fault removal" p. 104.
5. Start the measurement.
−
Click on [Start measurement] or open the menu command Measurement / Start
Measurement.
The window Measurement start opens.
−
Enter the sample ID and, if applicable, a name for the analysis table. You can also
enter the dilution, sample type, unit and remarks.
− With [Start ] open the window Measurement.
−
Start the measurement by clicking the button [Start F2] and follow the instructions
of the control and analysis software.

At the end of the measurement the results appear in the analysis report or in
the selected analysis table.
7.4.2

Measurement with sampler

IMPORTANT
After transport or prolonged storage of the analyzer the sampler must be readjusted during
recommissioning.
1. Using the menu command Method / New create a new method or load an existing
method.
To do so open via the menu command Method / Load the database window Method
selection, highlight the desired method and confirm the selection by clicking the button
[OK].
