How to Use the NuStep T5 Leg Stabilizer
Insert stability arm into left or right side of
seat mount tube on lower front of seat until
snap button pops into place.
Position cuff just back from knee.
Drop strap in between user's legs and wrap
strap around leg to secure. Strap does not
have to be overly tight. A pre-wrap towel
etc. may be used against bare skin.
Adjust leg alignment by pushing grip
forward/up, then slide cuff in or out to set
position. There are ten positions (1 – 10)
of adjustment.
Leg Stabilizer should swing approximately
45º during operation (as shown). If it is
biased swinging too high or too low outside
the 45º range, depress snap button to
adjust position up or down. There are
three positions (S–M–L) of adjustment.
Verify overall operation by having user start
~45º
stepping and making any adjustments.
NuStep, Inc. ● 5111 Venture Drive, Ann Arbor MI 48108 USA ● 800-322-4434
53510 T5 Leg Stabilizer Instruction, Rev A
