- Page 1 BY-P06 12*4in1 10W RGBW waterproof par User manual Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions....................2-4 2. Technical Specifications...................4 3. How To Control The Unit................... 5-7 4. Trouble shooting....................7-8 5. Fixture Cleaning......................8 statement product well capability intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included guarantee,... - Page 3 blocked. Disconnect main power before replacement or servicing. Make sure there are no flammable materials close to the unit while operating as it is fire hazard. Use safety cable when fixes this unit. DO NOT handle the unit by taking its head only, but always by taking its base.
-
Page 4: Technical Specifications
service, please contact your nearest dealer. Installation: The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly fixed to avoid vibration and slipping while operating. And make sure that the structure to which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. -
Page 5: How To Control The Unit
Features Outstanding color macro effect ,fade and built in programs Dimmer: 0~100% smooth dimming 3. How To Control The Unit The DMX512 is widely used in intelligent lighting control,with a DMX 512 controller.connect several lights together,dmx in and dmx out, 3 pin XLR connectors: Pin 1: GND, Pin 2: Negative signal (-), Pin 3: Positive signal Display: [MENU] menu selection or return to previous menu. - Page 6 [DOWN] press [DOWN] through the menu list to decrease/change the value of the current function. [ENTER] confirm & quit out current function setting. Display panel operation instruction Show Function Value Instruction 8CH mode UP, DOWN A001 DMX address 001~512 increase or reduce the value 4CH mode,UP,DOWN increase or reduce d001 DMX address...
-
Page 7: Trouble Shooting
DMX channel´s functions and values (8 DMX channels): Channel Function Instruction Total Dimmer Total Dimmer- Dark to Bright Red Dimmer- Dark to Bright R Dimmer G Dimmer Green Dimmer- Dark to Bright B Dimmer Blue Dimmer- Dark to Bright W Dimmer White Dimmer- Dark to Bright Total Flash Strobe- Slow to Fast Total Strobe... -
Page 8: Fixture Cleaning
3. Check the power on LED. B. Not responding to DMX controller 1. DMX LED should be on. If not, check DMX connectors, cables to see if link properly. 2. If the DMX LED is on and no response to the channel, check the address settings and DMX polarity. - Page 9 Clean the external optics at least every 20 days. Clean the internal optics at least every 30/60 days.
