- Page 1 User Manual Magnetic Stirrer PCE-MSR 150 User manuals in various languages (français, italiano, español, português, nederlands, türk, polski, русский, 中文) can be found by using our product search on: www.pce-instruments.com Last change: 9 January 2020 v1.0 © PCE Instruments...
-
Page 2: Table Of Contents
10.1 Switching on the device ....................8 10.2 Setting Time ........................8 10.3 Setting Speed ........................8 10.4 Pulse Mode Operation ...................... 9 11 Troubleshooting ..................9 12 Maintenance and cleaning ..............9 13 Contact ....................10 14 Disposal ....................10 © PCE Instruments... -
Page 3: Safety Notes
Please read this manual carefully and completely before you use the device for the first time. The device may only be used by qualified personnel and repaired by PCE Instruments personnel. Damage or injuries caused by non-observance of the manual are excluded from our liability and not covered by our warranty. - Page 4 We expressly point to our general guarantee terms which can be found in our general terms of business. If you have any questions please contact PCE Instruments. The contact details can be found at the end of this manual. © PCE Instruments...
-
Page 5: Introduction
Large & clear display shows critical parameters for easy reading • Small footprint saving valuable bench space Delivery contents 1 x Magnetic Stirring Bar 1 x Power Adaptor: 100‐240VAC 50/60Hz (Input), 24V 1.5A (Output) 1 x User Manual © PCE Instruments... -
Page 6: Device Description
Device description Front side Stainless steel top plate Start / stop button Digital display On / off button Rear Side Power Socket © PCE Instruments... -
Page 7: Installation
Connect one end of the power adaptor to the rear side of the stirrer and another end to the power supply as shown in the figure below. Push the power adaptor firmly for proper connection and turn ON the main switch. Make sure that input power source is according to stirrer requirement. © PCE Instruments... -
Page 8: User Interface And Display
Long pressing “Pulse” lets user select timings for pulse mode from 30 to 99 s Press “+” to increase values Increment Press “‐” to decrease values Decrement Press “Start/Stop” to Start or Start/Stop Stop any operation © PCE Instruments... - Page 9 © PCE Instruments...
-
Page 10: Operation
RPM respectively. When the equipment is used for the 1st time, the speed will be set to zero and shown as “0”. Once speed value is selected, single press “+/‐” will increase or decrease speed value by 10 RPM. Long press“+/‐” to quickly increase or decrease speed value. Speed value get saved after 5 blinks. © PCE Instruments... -
Page 11: Pulse Mode Operation
2. Check that power adaptor is working properly and it is properly connected at both ends. 3. If the problem still persists then contact PCE Instruments. 2. Problem : Err 2 Root Cause : Motor blockage/over load/fail, Encoder sensor fail Solution : 1. -
Page 12: Contact
For countries outside the EU, batteries and devices should be disposed of in accordance with your local waste regulations. If you have any questions, please contact PCE Instruments. © PCE Instruments... - Page 13 PCE Instruments contact information Germany France Spain PCE Deutschland GmbH PCE Instruments France EURL PCE Ibérica S.L. Im Langel 4 23, rue de Strasbourg Calle Mayor, 53 D-59872 Meschede 67250 SOULTZ-SOUS-FORETS 02500 Tobarra (Albacete) Deutschland France España Tel.: +49 (0) 2903 976 99 0 Téléphone: +33 (0) 972 3537 17...
