PCE-MFM 3000
G ( Gauss), mT ( milli Tesla ), USB/RS232
MAGNETIC FIELD METER
OPERATION MANUAL
PCE Americas Inc.
711 Commerce Way
Suite 8
Jupiter
FL-33458
USA
From outside US: +1
Tel: (561) 320-9162
Fax: (561) 320-9176
info@pce-americas.com
www.pce-instruments.com/english
Your
purchase
AC/DC MAGNETIC METER
marks a step forward for
you
into
the
precision measurement.
Although this METER is a
complex
and
instrument,
its
structure will allow many
years of use if proper
operating techniques are
developed. Please read the
following
instructions
carefully and always keep
this manual within easy
reach.
PCE Instruments UK Ltd.
Southpoint Business Park
Ensign way
Hampshire / Southampton
United Kingdom, SO31 4RF
From outside UK: +44
Tel: (0) 2380 98703 0
Fax: (0) 2380 98703 9
info@pce-instruments.co.uk
www.pce-instruments.com
of
this
field
of
delicate
durable
Unit 11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PCE-MFM 3000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PCE Instruments PCE-MFM 3000

Summary of Contents for PCE Instruments PCE-MFM 3000

  • Page 1 PCE Americas Inc. PCE Instruments UK Ltd. 711 Commerce Way Unit 11 Suite 8 Southpoint Business Park Jupiter Ensign way FL-33458 Hampshire / Southampton United Kingdom, SO31 4RF From outside US: +1 From outside UK: +44 Tel: (561) 320-9162 Tel: (0) 2380 98703 0...
  • Page 2 TABLE OF CONTENTS 1. FEATURES..............1 2. SPECIFICATIONS............2 3. FRONT PANEL DESCRIPTION........4 3-1 Display..............4 3-2 Power Button............4 3-3 Hold Button............4 3-4 REC Button............4 3-5 ZERO Button ............4 3-6 Mode Button ( DC, AC Button ), SET Button.... 4 3-7 Input socket............4 3-8 Probe Handle............
  • Page 3 1. FEATURES Wide range, general purpose magnetic measurement for industrial, mechanical, material, electrical, laboratory field usage Unit : G ( Gauss ), mT ( milli Tesla ) DC and AC magnetic field measurement DC Range : 300.00 mT/3000.0 mT AC Range : 150.00 mT/1500.0 mT Resolution : 0.01/0.1 mT, 0.1/1 G N pole/S pole indicator Use Hall sensor with automatic Temp.

  • Page 4: Specifications

    2. SPECIFICATIONS Circuit Custom one-chip of microprocessor LSI circuit. Display LCD size : 52 mm x 38 mm dual function LCD display. Measurement milli Tesla Unit Gauss Measurement Range 1 300.00 mT x 0.01 mT Range, DC Range 2 3,000.0 mT x 0.1 mT Range 1 3,000.0 G x 0.1 G Range 2 30,000 G x 1 G Measurement...
  • Page 5 Data Output RS 232/USB PC serial interface. * Connect the optional RS232 cable UPCB-02 will get the RS232 plug. * Connect the optional USB cable USB-01 will get the USB plug. Power Supply 006P DC 9V battery ( Alkaline or Heavy duty type ). DC 9V adapter input.

  • Page 6: Front Panel Description

    3. FRONT PANEL DESCRIPTION Fig. 1 3-1 Display 3-2 Power Button 3-3 Hold Button 3-4 REC Button ( Enter Button ) 3-5 ZERO Button 3-6 Mode Button ( DC, AC Button ), SET Button 3-7 Input socket 3-8 Probe Handle 3-9 Probe Sensing Head 3-10 Probe Plug 3-11 Probe Head Cover...

  • Page 7: Measuring Procedure

    4. MEASURING PROCEDURE 4-1 AC/DC magnetic field measurement 1) Power ON the meter by pressing the " Power Button " ( 3-2, Fig. 1 ) once. 2) Press the " Mode Button " ( 3-6, Fig. 1 ) once , the Display will show the following screen in sequence : Under mT unit Under G unit...
  • Page 8 3) Display indicator DC magnetic field measurement * The Display will show " N " or " S " indicator * North pole : Display will show " N " indicator * South pole : Display will show " S " indicator AC magnetic field measurement * Display will show "...
  • Page 9 6) Zero adjustment : When power ON the meter, due to the environment interference, the display may show certain values ( not zero value), it is normal. * Before the measurement, fix the probe at the exact position, press the " ZERO Button " ( 3-5, Fig. 1 ), in the same time the display will show the "...

  • Page 10: Advanced Setting

    b)Press the " REC Button " ( 3-4, Fig. 1 ) again, the " REC. MIN " symbol along with the minimum value will appear on the display. If intend to delete the minimum value, just press the " Hold Button " ( 3-3, Fig. 1 ) once, then the display will show the "...
  • Page 11 5-1 Auto power OFF management When the lower display show " PoFF " 1) Use the " REC Button " ( 3-4, Fig. 1 ) to enter will enter into the setting of " Auto power off management ". Press the " Mode Button " ( 3-6, Fig. 1 ) once in sequence to select upper text to "...

  • Page 12: Rs232 Pc Serial Interface

    5-3 For the further calibration usage, not available for the user When the lower display show " CLr " This setting just for the further calibration usage, not available for the end user. 6. RS232 PC SERIAL INTERFACE The instrument has RS232 PC serial interface via a 3.5 mm terminal ( 3-12, Fig.

  • Page 13: Battery Replacement

    Each digit indicates the following status : Start Word = 02 D12 & Annunciator for Display m tesla = E3 gauss = B5 Polarity 0 = Positive 1 = Negative Decimal Point(DP), position from right to the left, 0 = No DP, 1= 1 DP, 2 = 2 DP, 3 = 3 DP D8 to D1 Display reading, D8 = MSD, D1 = LSD For example :...

  • Page 14: System Reset

    8. SYSTEM RESET If the meter happen the troubles such as : CPU system is hold ( for example, the key button can not be operated... ). Then make the system RESET will fix the problem. The system RESET procedures will be either following method : During the power on, use a pin to press the "...
