- Page 1 GNV32CBO In order to continue serving our customers and providing the best products, our product information including our user manuals may receive updates from time to time. Please check our website for the latest user manuals and product materials. ver.1.0 6/19/19...
-
Page 3: Table Of Contents
Table of Contents Section 1: Safety Precautions ............. 4 Section 2: Box Contents .............. 5 Section 3: Product Overview ............6 3.1 – Monitor Buttons ............... 6 3.2 – Monitor Ports ..............6 Section 4: Stand Installation ............7 Section 5: Mount Installation ............8 Section 6: Connectivity Options .......... -
Page 4: Section 1: Safety Precautions
VIOTEK shall not be held responsible for injury or damage of products or persons ®... -
Page 5: Section 2: Box Contents
Section 2: Box Contents Monitor x 1 Stand Stem x 1 Stand Base x 1 NO. 1 Screws x 4 NO. 2 Screws x 4 Cable Clip DP Cable x 1 (for Stand Installation) (for Wall Mounting) Power Cable x 1 Screwdriver x 1 User Manual x 1 (AC 100-240V, 50/60Hz) -
Page 6: Section 3: Product Overview
Section 3: Product Overview 3.1 – Monitor Buttons M Menu Button: Press to display the OSD menu or enter sub-menus. Down Button: Press to move down in the menus. Up Button: Press to move up in the menus. E Exit Button: Press to exit. Power Button: Press to turn the monitor on/off. -
Page 7: Section 4: Stand Installation
Section 4: Stand Installation Keep the foam underneath the monitor before attaching the stand. 1. Open the package and take out the monitor with foam still attached. Gently place it on a desktop or table. 2. Take out the stem, cable clip, and base. Use the included screwdriver and one screw to fasten base to the stem. -
Page 8: Section 5: Mount Installation
Section 5: Mount Installation 1. Open the package and take out the product with foam still attached. Gently place it on a desktop or table. Remove the extra parts and the foam covering the monitor. If the monitor is already attached to the stand, remove the stand. Button 2. -
Page 9: Section 6: Connectivity Options
Section 6: Connectivity Options 6.1 – Connecting the Power Cable Connect the included power cable to the power connector, and then plug the other end into an wall outlet. Power Cable 6.2 – Connecting Your Headhones Plug in your headphones, or any 3.5mm-compatible external audio device, to receive audio signals from your monitor. -
Page 10: Hdmi Connectivity
6.3 – HDMI Connectivity In order for the monitor to receive HDMI signals from the computer, use an HDMI cable (not included) to connect the monitor to the computer. HDMI Cable (not included) HDMI OUTPUT 6.4 – DVI Connectivity In order for the monitor to receive DVI signals from the computer, use a DVI cable (not included) to connect the monitor to the computer. -
Page 11: Section 7: Basic Operation
Section 7: Basic Operation 1. Insert one end of the DP cable into your PC’s graphics card. A DVI cable or an HDMI cable may also be used. DVI and HDMI cables not included. 2. Connect the other end of the cable to the corresponding connector on your monitor. -
Page 12: Section 9: Osd
Section 9: OSD The On-Screen Display (OSD) Menu may be used to adjust your monitor’s settings and appears on screen after turning on the monitor and pressing the M button. When using the monitor for the first time, settings will automatically adjust to optimal settings according to your computer’s configuration and parts etc. -
Page 13: Osd Menu Functions
9.1 – OSD Menu Functions Main Menu Sub-Menu Options Description BRIGHTNESS Brightness 0~100 Adjust display brightness Contrast 0~100 Adjust display contrast Standard, Game, Set visual mode RTS, FPS, Movie, Text Turn on DCR function Turn off DCR function IMAGE Aspect Wide, Auto, 4:3 Set aspect ratio COLOR TEMP. -
Page 14: Section 10: Eco Modes And Gameplus
Section 10: LED Effects and Gameplus 1. Press any one of the buttons (M, , , E, ) to activate the navigation window. 2. Press ) to switch Gameplus modes. Choose the crosshair icon best suited for your game. These game icons are primarily designed to optimize your aim during shooting games, though they can be used for other scenarios. -
Page 15: Section 11: Troubleshooting
Section 11: Troubleshooting The screen is blank • Press the power button to turn the monitor on. • Confirm the brightness and contrast settings are set normally. • Check if the indicator light is flashing. If so, there is no signal from your video source. -
Page 16: Section 12: Specifications
• Check cable connectors for curved or damaged pins. Replace cables if needed. Color difference (colors are not optimized) • Adjust RGB color or reset color temperature settings. Section 12: Specifications Item Detail Model Number GNV32CBO Screen Size 31.5” Curvature 1500R Viewing Angle ≥178°(H); ≥178°(V) -
Page 17: Section 13: One-Year Limited Hardware Warranty
Warranty services are provided by Viotek Warranty Pro (“WP”). If a hardware defect arises and a valid claim is received within the Warranty Period, at its option and to the extent permitted by law, WP will: (1) repair the hardware defect by using new or refurbished parts that are equivalent to new in performance and reliability;... - Page 18 FCC RELATED INFORMATION: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
- Page 20 COPYRIGHT © 2019 VIOTEK. ALL RIGHTS RESERVED.
