- Page 1 Package Contents UniFi AC AP Mesh Pro Mounting Bracket Pole Clamps (Qty. 2) Carriage Bolts (Qty. 4) Flange Nuts (Qty. 4) Screws (Qty. 4) Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD...
-
Page 2: Installation Requirements
AC ground of the PoE. We recommend that you protect your networks from harmful outdoor environments and destructive ESD events with industrial-grade, shielded Ethernet cable from Ubiquiti. For more details, visit ui.com/toughcable Surge protection should be used for all outdoor installations. We recommend that you use two Ethernet Surge Protectors, model ETH-SP, one near the UAP-AC-M- PRO and the other at the entry point to the building. -
Page 3: System Requirements
IMPORTANT: The UAP-AC-M-PRO requires the UniFi Controller v5.4 or higher, available at: ui.com/download/unifi System Requirements Linux, Mac OS X, or Microsoft Windows 7/8/10 Java Runtime Environment 1.6 (1.8 or newer recommended) Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD... - Page 4 Web Browser: Google Chrome (Other browsers may have limited functionality) UniFi Controller software v5.4 or newer (available at: ui.com/download/unifi) Wireless Adoption Requirements The UAP-AC-M-PRO supports wireless adoption into your UniFi Wi-Fi network. This feature requires a currently managed UniFi AP operating with the following configuration: The UniFi AP must be running firmware 3.7.7 or newer At least one SSID enabled and operating on 5 GHz band...
- Page 5 Secondary The Secondary port is a Gigabit Ethernet port used for bridging. Reset The Reset button serves two functions for the UniFi AP: Restart Press and release the Reset button quickly. Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD...
-
Page 6: Hardware Installation
LAN and DHCP server. Power can be provided by one of the following: Gigabit PoE Adapter (included) Ubiquiti UniFi Switch with PoE 802.3af/802.3at PoE+ compliant switch Hardware Installation The UAP-AC-M-PRO can be mounted on a pole or mast, or on a wall. Perform the steps for the appropriate installation. - Page 7 Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD...
- Page 8 Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD...
- Page 9 Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD...
- Page 10 Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD...
- Page 11 Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD...
-
Page 12: Wall Mount
Wall Mount Note: Secure the Mounting Bracket directly to a stud or other structurally stable surface using appropriate fasteners. Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD... - Page 13 Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD...
- Page 14 Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD...
- Page 15 Note: Screws shown not included. Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD...
- Page 16 Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD...
-
Page 17: Connecting Ethernet
Connecting Ethernet Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD... - Page 18 Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD...
-
Page 19: Connecting Power
Connecting Power Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD... - Page 20 Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD...
-
Page 21: Software Installation
Optional Wireless Adoption “Wireless Adoption Requirements” before proceeding. 1. Ensure the UAP-AC-M-PRO is powered on, and then launch the UniFi Controller software. 2. Go to the Devices page, and the UAP-AC-M-PRO will show up as Pending Approval (Wireless). 3. Click Adopt. For information on configuring and using the UniFi Controller software, refer to the User Guide located on our website: ui.com/download/unifi... -
Page 22: Mobile App Installation
Controller software, refer to the User Guide. Mobile App Installation Ubiquiti also offers the UniFi app, which is available from the App Store® (iOS) or Google Play™ Store (Android). You can use it to provision a UniFi AP for basic functionality without configuring a UniFi Controller. - Page 23 UAP-AC-M-PRO Dimensions 343.2 x 181.2 x 60.2 mm (13.51 x 7.13 x 2.37") Weight 633 g (1.40 lb) Networking Interface (2) 10/100/1000 Ethernet Ports Buttons Reset Power Method 802.3af PoE Power Supply 48V, 0.5A PoE Gigabit Adapter (Included) Supported Voltage Range 44VDC to 57VDC Max.
-
Page 24: Safety Notices
UAP-AC-M-PRO Mounting Wall/Pole (Pole Kit Included) Operating Temperature -40 to 70° C (-40 to 158° F) Operating Humidity 5 - 95% Noncondensing Certifications CE, FCC, IC Safety Notices 1. Read, follow, and keep these instructions. 2. Heed all warnings. 3. Only use attachments/accessories specified by the manufacturer. WARNING: Do not use this product in location that can be submerged by water. -
Page 25: Limited Warranty
wire. b. The equipment requires the use of the ground wire as a part of the safety certification, modification or misuse can provide a shock hazard that can result in serious injury or death. c. Contact a qualified electrician or the manufacturer if there are questions about the installation prior to connecting the equipment. - Page 26 communications. Operations of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. This radio transmitter has been approved by FCC. ISED Canada CAN ICES-3(A)/NMB-3(A) This device complies with ISED Canada licence-exempt RSS standard(s).
- Page 27 Radiation Exposure Statement This equipment complies with radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20 cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
-
Page 28: Weee Compliance Statement
CE marking on this product represents the product is in compliance with all directives that are applicable to it. Country List BFWA (Broadband Fixed Wireless Access) members noted in blue Note: This device meets Max. TX power limit per ETSI regulations. The following apply to products that operate in the 5 GHz frequency range: Note: This device is restricted to indoor use only when operating in the 5150 - 5350 MHz... -
Page 29: Declaration Of Conformity
Declaration of Conformity Online Resources © 2020 Ubiquiti Inc. All rights reserved. Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD...
