1.3 System Features
The following table provides you with an overview of the main features of the 1029P-MT/MTR.
Please refer to Appendix C for additional specifications.
Motherboard
X11DPL-i
Chassis
SC113MFTS-605CBP/R608CBP
CPU
Dual Intel Xeon processor Scalabale Family up to 140W
Socket Type
Socket P
Memory
Eight DIMM slots to support up to 1TB of ECC, 3DS Registered DIMMs (RDIMM), Load Reduced DIMMs
(LRDIMM) or 512GB of ECC RDIMM/LRDIMM DDR4-2666 memory
Chipset
Intel C621 chipset
Expansion Slots (supported)
One PCI-Express 3.0 x8 slot (supported by CPU1)
Hard Drives
Eight 2.5" hot-swap hard drives
Power
1029P-MT: 600W single power supply (p/n PWS-605P-1H)
1029P-MTR: 600W redundant power supplies (p/n PWS-608P-1R)
Form Factor
1U rackmount
Dimensions
(WxHxD) 17.2 x 1.7 x 19.98 in. (437 x 43 x 508 mm)
System Features
9
Chapter 1: Introduction
