SuperServer 1029P-MT/MTR User's Manual

1.1 Overview

This chapter provides a brief outline of the functions and features of the 1029P-MT/MTR
SuperServer. The 1029P-MT/MTR
SC113MFTS-605CBP/R608CBP chassis.
In addition to the motherboard and chassis, several important parts that are included with
the system are listed below.
Description
Air Shroud
Heatsink
Fans
Riser Card
Hard Drive Carriers (hot-swap)
Hard Drive Backplane
Outer rail (quick)
Inner Rail (front)
Inner Rail (extension)

1.2 Unpacking the System

Inspect the box the SuperServer 1029P-MT/MTR was shipped in and note if it was damaged
in any way. If any equipment appears damaged, please file a damage claim with the carrier
who delivered it.
Decide on a suitable location for the rack unit that will hold the server. It should be situated
in a clean, dust-free area that is well ventilated. Avoid areas where heat, electrical noise and
electromagnetic fields are generated. It will also require a grounded AC power outlet nearby.
Be sure to read the precautions and considerations noted in Appendix B.
Chapter 1
Introduction
is based on the X11DPL-i motherboard and the
Main Parts List
8
Part Number Quantity
MCP-310-19015-0N 1
SNK-P0067PD 2
FAN-0154L4 4
RSC-RR1U-E8 1
MCP-220-00047-0B 8
BPN-SAS3-113A-N2 1
MCP-290-00102-0N 1 set
MCP-290-00107-0N 1 set
MCP-290-00110-0N 1 set
