Steelcase, Inc.
Grand Rapids, MI 49501
U.S.A.
1-888-783-3522

Secretarial Height Return Installation

Tools

Assembly Directions
Dearborn, Monarch, Churchill
1/8" Drill Bit
Power Driver with
Phillips or Square Tip
Printed in U.S.A.
Steelcase
®
REV
Y9501784 B
Page 1 of 3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Dearborn and is the answer not in the manual?

Questions and answers

Summary of Contents for Steelcase Dearborn

  • Page 1 Steelcase Steelcase, Inc. ® Grand Rapids, MI 49501 U.S.A. 1-888-783-3522 Secretarial Height Return Installation Dearborn, Monarch, Churchill Tools Power Driver with 1/8" Drill Bit Phillips or Square Tip Assembly Directions Printed in U.S.A. Y9501784 B Page 1 of 3...
  • Page 2 (see illus. in Step 4). Adjust leveling glides as needed. Note: Visuals may differ slightly for your application. Prodedures remain the same for all models listed. Assembly Directions Page Steelcase Y9501784 REV B 2 of 3...
  • Page 3 Using holes in Z-bracket as a guide, pilot drill (5) holes 1/8" dia. and 1/2" deep. Install (5) 7/8" screws. UNDERSIDE OF RETURN TOP UNDERSIDE OF DESK TOP 1-1/4" SCREW RETURN BACK PANEL Install (3) 1-1/4" screws. Assembly Directions Page Steelcase Y9501784 REV B 3 of 3...

This manual is also suitable for:

MonarchChurchill
