- Page 1 Steelcase Steelcase, Inc. ® Grand Rapids, MI 49501 U.S.A. 1-888-783-3522 Modular Credenza Assembly Monarch, Churchill Tools 1/8" dia. Power Driver drill bit with Phillips or Square Tip Assembly Directions Printed in U.S.A. Y9501803 B Page 1 of 3...
- Page 2 Center pedestals on base assembly. It is recommended that a bar clamp be used to eliminate air gap between pedestals. Install each pedestal as shown in Step 1 (Remove drawers in lateral file to facilitate installation.). Assembly Directions Page Steelcase Y9501803 REV B 2 of 3...
- Page 3 Install top panel as shown mended that a bar clamp be used to in Step 3 above. eliminate air gap between pedestals. Install top panel as shown in Step 3 above. Assembly Directions Page Steelcase Y9501803 RE V B 3 of 3...
