Steelcase Monarch Assembly Directions

Corner worksurface and reception return

Table of Contents

Download this manual

Steelcase, Inc.

Grand Rapids, MI 49501

U.S.A.

1-888-783-3522

Tools

Tape Measure

Assembly Directions

Corner Worksurface

and

Reception Return

Assembly

Monarch, Stafford

Power Driver with

Phillips or Square

Tip

1/8" Drill Bit

Printed in U.S.A.

Steelcase

Large

Phillips Head

Screwdriver

Level

REV

Y9501805 B

Page 1 of 5

Table of Contents

Need help?

Do you have a question about the Monarch and is the answer not in the manual?

Page 1 Steelcase Steelcase, Inc. ® Grand Rapids, MI 49501 U.S.A. 1-888-783-3522 Corner Worksurface Reception Return Assembly Monarch, Stafford Tools Power Driver with Large Phillips or Square Phillips Head Screwdriver Level Tape Measure 1/8" Drill Bit Assembly Directions Printed in U.S.A. Y9501805 B...
Page 2 Fig. A. Turn cam clockwise to draw bolt in tightly (Fig. B). Repeat for remaining minifix locations in back panels. MINIFIX BOLT Fig. A MINIFIX CAM Fig. B Assembly Directions Page Steelcase Y9501805 RE V B 2 of 5...
Page 3 Position wooden attachment cleat over joint formed by adjacent back panels. Install (6) 7/8" screws for each cleat. Adjust glides (arrows indicate locations) to level assembly as necessary. Assembly Directions Page Steelcase Y9501805 RE V B 3 of 5...
Page 4 BRACKET (4) angle brackets to underside of top so that they are snug against back panels. Make sure top is level, then attach angle brackets to back panels. ANGLE BRACKET Assembly Directions Page Steelcase Y9501805 REV B 4 of 5...
Page 5 Using (8) 1-1/2" screws, install wooden cleats flush with top edge of back and end panels. Position transaction top so that ends and back have 1-1/16" overhang. Install (8) 1-1/2" screws to secure. Assembly Directions Page Steelcase Y9501805 REV B 5 of 5...
