INSTRUCTION MANUAL
Automatic Spray Gun
Low Pressure Automatic Spray Gun
(High Volume Low Pressure)
This manual contains IMPORTANT WARNINGS and INSTRUCTIONS.
Equipment in this manual is exclusively for painting purposes.
Do not use for other purposes.
The operator shall be fully conversant with the requirements stated in this
instruction manual including important warnings, cautions and operation and
correct handling.
Read and understand the instruction manual, before use and retain for
reference.
Be sure to observe warnings and cautions in this instruction manual.
If not, it can cause paint ejection and serious bodily injury by drawing organic solvent.
Be sure to observe following
Indicates a potentially hazardous situation which, if not avoided, may result in serious injury or loss of life.
Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury or property
damage.
Indicates notes which we ask you to observe. The safety precautions in this instruction manual are the minimum
necessary conditions. Follow national and local regulations regarding fire prevention, electricity and safety as well as
your own company regulations.
Important specifications
■
Max. Pressure
Noise level WRA-101
WRA-200
LRA-200
Spray condition
Measuring point
Max. Temperature
Atmosphere
Air・Fluid
Main specifications
■
Type of
Model
feed
WRA-101-082PV
Pressure
WRA-200-122PV
LRA-200-122PV
※1. Air pressure means air pressure at gun inlet when air valve is opened and air flows．
WRA-101
marked items which are especially important.
０．６８ ＭＰａ / ６８．０ ｂａｒ / ９８ PSI
．
７８ ７ｄ Ｂ （Ａ）
．
８２ ４ｄ Ｂ （Ａ）
．
７６ ９ｄ Ｂ （Ａ）
Recommended
1m backwards from gun, １.６ m height
５℃～４０℃
５℃～４３℃
Nozzle
Air cap
※1 Air pressure
Set
orifice
MPa (bar /PSI)
Mark
φ mm (in)
Atomizing air
0.8 (0.031) E2P 0.26 (2.7/38)
1.2 (0.047) G2P 0.24 (2.4 /34) 0.26 (2.7/38)
1.2 (0.047) G2 0.14 (1.4 /20) 0.16 (1.6/23)
WRA-200
LRA-200
Recommended condition
Air pressure
Fluid output
inside air cap
ml/min
MPa
(bar /PSI)
Fan air
0.22 (2.2/31) 150
－
500
－
0.07(0.7 /10) 500
－ 1 －
和文取説は、裏面にあります
This Anest-iwata spray gun kit complies to ATEX
regulations 94/9/EC,
Protection level ：
Ⅱ2 G X，Suitable for use in Zones 1 and 2.
X marking ：
Any static electricity discharge from the spray gun
is to be diverted to the grounded the conductive
air hose as stipulated.
Air
Pattern width
consumption
mm(in)
l/min (cfm)
270 (9.5) 190 (7.5)
3-Rc1/8 (Air)
530 (18.7) 400 (15.7)
2-Rc1/8 (Fluid)
500 (17.7) 300 (11.8)
Air &fluid Mass
connection g (lbs)
290 (0.64)
310 (0.68)
