21.3

Freewheel

21.4

Running gear assistance (directional travel, turning the operating table)

Instruction manual Operating table TruSystem 7000 – 1 730 263 – 11/2016
In Unlock (free movement), all operating table wheels can swivel
fully and the operating table can be moved in any direction.
1. Prepare the operating table according to the requirements on
page 87 if it is in the jacked-up position.
2. Press key [i52] until an audible signal sounds.
The signal will sound intermittently until the operating table
2)
jacks [36] are fully retracted and the additional wheel [17]
in the middle under the running gear is extended.
Indicator [i52] on the column keypad lights up. The
appropriate status pictograms are visible in the remote control
display.
Running gear assistance supports directional movement or the
turning of the operating table on the spot. Transverse movement of
the operating table is not possible.
1. Prepare the operating table according to the requirements on
page 87 if it is in the jacked-up position.
2. Press key [i54] until an audible signal sounds.
2)
From the operating table locked position
3)
From the setting for directional travel
Travel Behavior
3)
89
