Xycom XVME-113 User Manual page 57

Connector
Signal
Mnemonic Pin Number
SYSFAIL* 1C:10
SYSRESET* 1C:12
WRITE* 1A:14
+5V STDBY 1B:31
+5V 1A:32
1B:32
1C:32
2B:1,13,32
+12V 1C:31
-12V 1A:31
Table A-1. VMEbus Signal Identification (Continued)
and
SYSTEM FAIL: Open-collector driven signal that indicates that a failure
has occurred in the system. It may be generated by any module on the
VMEbus.
SYSTEM RESET: Open-collector driven signal which, when low, will
cause the system to be reset.
WRITE: Three-state driven signal that specifies the data transfer cycle in
progress to be either read or written. A high level indicates a read operation,
a low level indicates a write operation.
+5 VDC STANDBY: This line supplies +5 VDC to devices requiring
battery backup.
+5 VDC POWER: Used by system logic circuits.
+12 VDC POWER: Used by system logic circuits.
-12 VDC POWER: Used by system logic circuits.
XVME-113 RAM/ROM Memory Module
Signal Name and Description
October 1992
A-5
