4.6. Electrostatic Discharge

Static electricity occurs naturally and it may damage the module. Therefore, applying proper ESD
countermeasures and handling methods is imperative. For example, wear anti-static gloves during the
development, production, assembly and testing of the module; add ESD protection components to the
ESD sensitive interfaces and points in the product design.
Table 18: Electrostatics Discharge Characteristics (25 ° C, 45 % Relative Humidity; Unit: kV)
Tested Interfaces
VBAT、GND
ANT_BT、ANT_WIFI
Other Interfaces
FC800L_Hardware_Design
Contact Discharge
2
5
2
Wi-Fi&Bluetooth Module Series
Air Discharge
12
10
2
Unit
kV
kV
kV
