Summary of Contents for Freescale Semiconductor EVBCRTOUCH
- Page 1 Quick Start Guide EVBCRTOUCH Xtrinsic CRTouch Capacitive and Resistive Touch-Sensing Platform Evaluation Board READY PLAY SOLUTIONS Xtrinsic...
-
Page 2: Evaluation Board
Quick Start Guide Get to Know the EVBCRTOUCH Evaluation Board USB2SER CRTouch Four Capacitive Electrodes Power On/Off Communication Four- and Five-Wire Ports Connectors... - Page 3 READY PLAY SOLUTIONS Xtrinsic CRTouch EVBCRTOUCH The Xtrinsic capacitive and resistive touch-sensing platform (CRTouch) enables resistive touch screens to handle two-touch gesture recognition and allows the addition of up to four capacitive electrodes to your system, all packaged on a 5 x 5 mm 32-pin QFN.
- Page 4 Quick Start Guide Step-by-Step Installation Instructions In this quick start guide, you will learn how to set up the EVBCRTOUCH board. Unpack and Verify Connect the USB Cable Package Contents and the Resistive Screen Ensure the EVBCRTOUCH touch- Connect your computer to the...
- Page 5 COM port assigned to the evaluation board on your computer. Press the resistive screen and then click on the Read button. If the X and Y coordinates registers are updated in the CRTOUCH Settings window, you are ready to use the EVBCRTOUCH evaluation board.
- Page 6 Quick Start Guide EVBCRTOUCH Jumper Options The following is a list of all jumper options. The default installed jumper settings are shown in blue. Jumper Option Settings Description CRT REG. Supplied from an internal 3.3V regulator from INT REG-CRT REG...
-
Page 7: System Requirements
READY PLAY SOLUTIONS EVBCRTOUCH Switch/Button Options The following is a list of the switch/button options on the evaluation board. Switch Option Description Power On/Off On/Off switch Reset Reset signal UART baud rate auto detection. Configure a new baud rate, Baud Rate Detect from 9600 bps to 115200 bps. -
Page 8: Warranty
Freescale and the Freescale logo are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. Xtrinsic and Ready Play are trademarks of Freescale Semiconductor, Inc. All other product or service names are the property of their respective owners.
