Quick Steps

1. Connect the probe to the port at the bottom of the meter (Section 4.1).
2. Remove the probe's protective cap and mount it in the process under test
using the threaded connector (0.5 inch) or hold it in ambient air (Section
4.2).
3. Short press F2 (orange colored function button) to power the meter, the
Home page will appear (Section 6).
4. View the three displayed readings. Press the left or right arrow button to
view the readings in a concise text format. Press the left or right arrow to
return to the Home page.
5. Press F2 (HOLD), to freeze readings. Press F1
readings. Press F3
6. Press F1
(Section 6). When the first graph is shown, the graph icon moves above
F3. Press F3 to step through the graph pages. Press F2 to set the interval
of time between captured readings. Press F1
page.
7. Press F3
8. Long press F2, until the progress bar reaches 100%, to power off.
#NAS100113; r. AA/87024/87024; en-US
, while readings are held, to save them.
to view real-time readings plotted on a set of four graphs
to open the Programming menu (Section 7).
to release the held
to return to the Home
