Data Recording
Figure 8.6 Data file summary page.
1. Start and Stop time and date for the recorded data.
2. Maximum (MAX) and Minimum (MIN) values show the highest and lowest
readings recorded in a data file.
3. Press F1 to return to previous page.

8.7 Clearing Data Memory

To clear ALL user data, scroll to the Clear Data Memory option in the Re-
cording menu and press F3 to execute the procedure. Press F1 to abort
the procedure and to return to the previous page. Back up important data to
your PC, as explained in Section 8.8, before clearing user data.
NOTE
When you clear memory, all Data Log files, Data Hold files, and the firmware file are removed.
Please backup all important data, as explained in Section 8.8, before clearing the memory.
Erasing the firmware file will not affect meter operation, but you'll need to obtain a new file if
you wish to reset the current firmware or to upgrade the firmware; see the firmware update in-
structions in Section 10.3.

8.8 Downloading and Backing Up Data Files to a PC

Recorded data is stored in plain text CSV (Comma Separated Values) files,
and can be easily opened in spreadsheet programs. See Figure 8.6 below for
an example of a data file opened in a spreadsheet.
To download and back up files, connect the RH600 to a PC using the supplied
USB cable. The RH600 USB port is located at the top of the meter, as shown
in Section 2.1. Once connected, go to Functions in the programming menu
and select Connect Computer; the PC will recognize the RH600 as an exter-
nal storage drive. Simply move files from the RH600 root directory to the PC
to download and back up files.
