ACM500
USER MANUAL
New Project Set-up Wizard
On first log in of the ACM500, a Set-up Wizard for configuring all components of the Multicast system will be presented.
This has been designed to speed up new system configuration as all default / new Multicast Transmitters & Receivers
can be connected to the network switch at the same time, whilst not resulting in an IP conflict during the system
configuration. This results in a system in which all components are automatically and sequentially assigned a name
and IP address ready for basic system use.
The ACM500 Set-up Wizard can be cancelled by clicking 'Close'. Please be aware that the system will not be configured
at this point, but can be continued by visiting the 'Project' menu (see page 18). If a project file is already available (i.e.
replacing an ACM500 on an existing site), this can be imported by using the .json file by clicking 'Import Project'.
Click 'Next' to continue set-up:
If at this point the Network Switch is not configured for use with the Blustream Multicast system, click on the hyperlink
'network switch setup guides' to navigate to a centralised webpage containing common Network Switch Guides.
An example schematic diagram for the connections of the ACM500 can be accessed by clicking the hyperlink marked
'diagram'. This will ensure the ACM500 is connected correctly to the wider Multicast system before the Set-up Wizard
begins. Once the connections of the ACM500, are confirmed click 'Next'. The connections diagram is included on page
07 of this guide.
