BluStream Multicast ACM500 User Manual page 46

Transmitter (Input) Commands
COMMAND DESCRIPTION
Set CEC INPUT:yyy ON or Off
Set TX Audio source to HDMI audio
Set TX Audio source to Analog
Set TX Audio source to Auto
Reboot Transmitter
Copy EDID Input yyy from Output xxx
Set Input: yyy EDID To EDID:zz
zz=00: HDMI 1080p@60Hz, Audio 2CH PCM
zz=01: HDMI 1080p@60Hz, Audio 5.1CH PCM/DTS/ DOLBY
zz=02: HDMI 1080p@60Hz, Audio 7.1CH PCM/DTS/DOLBY/HD
zz=03: HDMI 1080i@60Hz, Audio 2CH PCM
zz=04: HDMI 1080i@60Hz, Audio 5.1CH PCM/DTS/DOLBY
zz=05: HDMI 1080i@60Hz, Audio 7.1CH PCM/DTS/DOLBY/HD
zz=06: HDMI 1080p@60Hz/3D, Audio 2CH PCM
zz=07: HDMI 1080p@60Hz/3D, Audio 5.1CH PCM/DTS/DOLBY
zz=08: HDMI 1080p@60Hz/3D, Audio 7.1CH PCM/DTS/DOLBY/
HD
zz=09: HDMI 4K@30Hz 4:4:4, Audio 2CH PCM
zz=10: HDMI 4K@30Hz 4:4:4, Audio 5.1CH DTS/DOLBY
zz=11: HDMI 4K@30Hz 4:4:4, Audio 7.1CH DTS/DOLBY/HD
zz=12: DVI 1280x1024@60Hz, Audio None
zz=13: DVI 1920x1080@60Hz, Audio None
zz=14: DVI 1920x1200@60Hz, Audio None
zz=15: HDMI 4K@30Hz 4:4:4, Audio 7.1CH(Default)
zz=16: HDMI 4K@60Hz 4:2:0, Audio 2CH PCM
zz=17: HDMI 4K@60Hz 4:2:0, Audio 5.1CH DTS/DOLBY
zz=18: HDMI 4K@60Hz 4:2:0, Audio 7.1CH DTS/DOLBY/HD
Single Transmitter (input) status
46
COMMAND
INyyyCECON/OFF
INyyyAUDORG
INyyyAUDANA
INyyyAUDAUTO
INyyyRB
EDIDyyyCPxxx
EDIDyyyDFzz
INyyySTATUS
|
www.blustream.com.au www.blustream-us.com
ACM500
USER MANUAL
RESPONSE
Set input xxx cec mode ON/OFF
Set Audio source:xxx to audio select
hdmi
Set Audio source:xxx audio select
analog
Set Audio source:xxx audio select
auto
Set output xxx reboot and apply all
the new config
Copy outputxxx edid to input yyy
Set input yyy edid with default edid
zz
(See status example at end of docu-
ment)
|
