5.3 Interpreting Each Pattern Number Definition

Table 3 describes each of the 32 different Patterns:
PATTERN NUMBER
00
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
6
Using Your 840 DVI Pattern Generator

Table 3: Pattern Number Definitions

DEFINITION
Black screen
75% saturated color bar
100% saturated color bar
Grayscale bar
Red screen
Green screen
Blue screen
Yellow screen
Cyan screen
Magenta screen
White screen
Gray screen
Red, green, blue ramps
White crosshatch on black background
Red crosshatch on green background
Red crosshatch on blue background
White squares
White dots
Active picture border
Centered round target and active picture border
Moving vertical line
Moving horizontal line
Aperture moving over colored background
Aperture moving over color bar background
Moving red ramp
Moving green ramp
Moving blue ramp
Bounce
Multiburst
0/100 Vertical Split
0/100 Horizontal Split
Chess board
