# Feature
1 12V DC
2 OUTPUT DVI
Connector
1
3 SVGA Button
1
4 XGA Button
1
5 SXGA Button
1
6 UXGA Button
1
7 Wide (On) Button
8 PATTERN – Button
9 PATTERN + Button
10 PATTERN NUMBER
7-segment Display
11 ON LED
1 Illuminates when pressed
Your 840 DVI Pattern Generator

Table 1: 840 DVI Pattern Generator Features

Function
+12V DC connector for powering the unit
Connect to the DVI acceptor
Selects SVGA (800x600) when pressed. Selects 852x480 when pressed
together with the Wide (On) button. Selects 720x480 when pressed together
with the XGA button and the Wide (On) button
Selects XGA (1024x768) when pressed. Selects 1280x720 when pressed
together with the Wide (On) button. Selects 720x480 when pressed together
with the SVGA button and the Wide (On) button. Selects 1920x1080 when
pressed together with the SXGA button and the Wide (On) button
Selects SXGA (1280x1024) when pressed. Selects 1400x1050 when pressed
together with the UXGA button. Selects 1366x768 when pressed together with
the Wide (On) button. Selects 1920x1080 when pressed together with the
XGA button and the Wide (On) button. Selects 1920x540 when pressed
together with the UXGA button and the Wide (On) button
Selects UXGA (1600x1200) when pressed. Selects 1400x1050 when pressed
together with the SXGA button. Selects 960x540 when pressed together with
the Wide (On) button. Selects 1920x540 when pressed together with the
SXGA button and the Wide (On) button
Displays a wide image and provides 7 extra resolutions when pressed together
with one or two of these buttons: SVGA, XGA, SXGA and/or UXGA
Goes back to the previous pattern number
Advances to the next pattern number
Shows the pattern number (from 00 to 31)
Illuminates when receiving power

Table 2: Selecting the DVI Output Resolutions

To select: Press:
SVGA
SVGA
XGA
XGA
SXGA
SXGA
1400x1050
SXGA+ UXGA
UXGA
UXGA
852x480
SVGA + Wide (On)
1280x720
XGA + Wide (On)
1366x768
SXGA + Wide (On)
960x540
UXGA + Wide (On)
720x480
SVGA + XGA + Wide (On)
1920x1080
XGA + SXGA + Wide (On)
1920x540
SXGA + UXGA + Wide (On)
