UTILITY SOFTWARE

With the Prescan image displayed in the
Prescan window...
1. Click on the Scan button in the
Command window.
• The standard save dialog box for your operating
system will appear.
2. Enter the desired file name and
select the file destination.
3. Select the file type from the drop-
down list.
4. Click on Save.
• The final scan will begin.
• When scanning is complete, the scan will be
saved in the selected location. The software
will return to the Prescan window.
Multiple scans will be saved
using the selected file name and
numbered chronologically.
Example: File_Name01,
File_Name02, File_Name03...
UTILITY SOFTWARE – FILE FORMATS
With the Dimâge Scan Multi utility software, you can save the final scan in one of the following file formats.
JPEG
• The JPEG (Joint Photographic Experts Group) compression standard is capable of producing a high
compression ratio while maintaining image quality. JPEG is a widely supported image file format.
TIFF
• Tagged Image File Format (TIFF) files contain bit-mapped data. In addition to being a widely supported format,
TIFF is able to handle the color palette needed for professional-quality images and graphics.
WINDOWS® BMP (Windows only)
• The BMP graphic file format is for bit-mapped images. BMP images are supported by the Paint accessory and
can easily be opened on most PCs running Windows.
PICT (Macintosh operating system only)
• The PICT graphic file format uses a lossless compression scheme and is compatible with many Macintosh
applications.
